E-Z-GO Cushman Service & Parts Manual page 31

THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
G** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
91 71641-G01
92 71641-G02
93 16705-G1
94 23726-G4
95 00891-G2
96 15058-G6
97
98 74149-G01
99 16816-G2
100 74126-G01
101 74126-G02
102 00427-G4
103 00427-G6
104 00560-G1
105 11098-G5
106
107 74111-G01
108 01006-G02
109 70364-G01
110 00426-G8
111 00560-G1
112 11098-G5
113
114
115 35434-G01
116 35430-G13
117 35430-G14
118
119 12109-G01
120 73317-G01
1 2 3 4 5
SILL PLATE (PASSENGER SIDE) ......................................................................
SILL PLATE (DRIVER SIDE)...............................................................................
SCREW, 1/4 - 20 X 1" LG (STAINLESS STEEL) ................................................
SPACER, 5/16"....................................................................................................
LOCK NUT, 1/4 - 20 (STAINLESS STEEL) .........................................................
RIVET, 3/16" X 15/16" LG (ALUMINUM) .............................................................
VALANCE PANEL ...............................................................................................
RATCHET FASTENER, 1/4" X 3/4" LG ...............................................................
VERTICAL FRAME SUPPORT (PASSENGER SIDE) ........................................
VERTICAL FRAME SUPPORT (DRIVER SIDE).................................................
BOLT, 3/8 - 16 X 1 1/2" LG (SHUTTLE 4) ...........................................................
BOLT, 3/8 - 16 X 1 3/4" LG (SHUTTLE 6) ...........................................................
WASHER, 3/8" ....................................................................................................
LOCK NUT, 3/8 - 16 ............................................................................................
SEAT BACK SUPPORT ......................................................................................
SELF TAPPING SCREW, 3/8 - 16 X 1 1/2" LG ...................................................
SPACER ..............................................................................................................
BOLT, 3/8 - 16 X 1" LG ........................................................................................
WASHER, 3/8" ....................................................................................................
LOCK NUT, 3/8 - 16 ............................................................................................
LABEL (SHUTTLE) .............................................................................................
LABEL (6)............................................................................................................
LABEL (4)............................................................................................................
LABEL (F-R)........................................................................................................
LABEL (F-R) (EC) ...............................................................................................
Service Parts Manual
DESCRIPTION
BODY
QTY.
1
1
6
6
6
4
1
4
1
1
2
2
4
2
2
4
2
2
4
2
2
2
2
1
1
Page C-12
