Develop ineo+ 654 Product Manual page 9

Product Guide ineo
SADDLE KIT SD-512
Max. No. of Folded Sheets
Max. No. of Sheets for Centre Stapling
Dimensions (WxDxH) (mm) 239 x 579 x 534
POST INSERTER PI-505
Dimensions (WxDxH) (mm) 511 x 635 x 220
+
654/754
Paper Size A4 lengthwise / A3+
Centre Staple: 52 to 90 g/m²
Half-Fold: 52 to 209 g/m²
Paper Weight
(more than 91 g/m² sheet can be used only as a cover sheet)
Tri-Fold: 52 to 90 g/m²
1 to 5 sheets: 35 sets
6 to 10 sheets: 25 sets
11 to 20 sheets: 15 sets
Stacking Capacity
Tri-Fold (1 sheet): 50 sets
Tri-Fold (2 sheets): 40 sets
Tri-Fold (3 sheets): 30 sets
Half-Fold: 5 sheets or Thick (91 to 209 g/m²) 1 sheet
Tri-Fold: 3 sheets
20 sheets (52 to 90 g/m²) or 19 sheets (90 g/m²) + 1 sheet Thick
Paper (209 g/m²)
Staples SK-602, one staple cartridge is packed to the Saddle Kit
Weight (kg) 25.5
Function Pre-printed page insertion, manual stapling, half fold and punching
Upper Tray: A5 lengthwise up to A4 (B5)
Paper Size
Lower Tray: A5 lengthwise up to A3+ (311 x 457 mm)
Paper Weight 60 – 209 g/m²
Capacity Max. stack capacity 200 sheets 80 g/ m²
Weight (kg) 10,5
Remark Cannot be used together with JS-602
9
Option for FS-535
Option for FS-535
