Product Guide ineo
Z-FOLD UNIT ZU-606
Dimensions (WxDxH) (mm) 169 x 1028 x 660
PUNCH KIT PK-521 for
Europe/Sweden
Dimensions (WxDxH) (mm) 146.2 x 639.2 x 233.8
+
654/754
Hole Punching
Punch Method On-line, page by page, 2 / 4 hole switching type
Hole Diameter 6.5 mm ± 0,5 mm
2 holes: A3, B4, A4 C/L, B5 C/L, A5 C/L
Paper Size
4 holes: A3, B4, A4 C, B5 C
Paper Weight 60 – 90 g/m²
Folding
Type Z-fold
Paper Size A3, B4
Paper Weight 60 – 90 g/m²
Weight (kg) 45
Although punching is included, PK-521 can be attached to FS-535 in
addition. This will allow also punching for paper, fed in via the Page
Remark
Inserter PI-505
On-line, page by page, 2 / 4 holes switching type for European
Punch Method
version, 4 holes fixed for Swedish version
Hole Diameter 6.5 mm ± 0,5 mm
2 holes:A3, B4, A4 C / L, B5 C / L, A5 C / L
Paper Size
4 holes: A3, B4, A4 L, B5 L
Paper Weight 60 – 256 g/m²
Weight (kg) 4.5
Punch mode cannot be used together with the folding mode, stitch
Remark
and fold mode or 3-folding mode
10
Option for FS-535
Option for FS-535
