64
Legend IP
Installation Manual
7. Securely fasten the arm to the mounting surface with the appropriate fasteners (Figure 35). Again,
ensure that it is level.
Figure 35. Fastening the arm to the mounting surface
8. If needed, seal all mounting holes so that no moisture can leak into the mounting surface.
9. Push inside the arm or pull taut any looped cables that are extending out of the access area.
10. Reattach the cover (Figure 36).
Figure 36. Reattaching the access cover
Note:
Adhere to minimum load
requirements. See Table 1
on page 9.
