38 Legend IP
Installation Manual
New protocols have continued to be added since the earliest analog Legend domes. Table 9 gives the switch
assignments for the currently available protocols. Be aware that some protocols have moved from what setting
they are on.
Table 9. Equivalent values for the settings of the rotary switches
Setting
0 Digiplex (RS-422) at 4800 baud
1 Impac (RS-485) at 9600 baud
2 For future use
3 For future use
4 For future use
5 ASCII at 9600 baud
6 For future use
7 Ultrak at 9600 baud (even parity)
8 Pelco P at 4800 baud
9 Pelco D autobaud at 2400, 4800, and 9600
A Tyco/AD (RS-422) at 4800 baud
B For future use
C For future use
D For future use
E For future use
F For future use
Protocol switch
Value
Camera site address switches
100s switch 10s switch
Setting Value Setting
0 000 0
1 100 1
2 200 2
3 300 3
4 400 4
5 500 5
6 600 6
7 700 7
8 800 8
9 900 9
A 1000
B 1100
C 1200
D 1300
E 1400
F 1500
1s switch
Value Setting Value
00 0
10 1
20 2
30 3
40 4
50 5
60 6
70 7
80 8
90 9
0
1
2
3
4
5
6
7
8
9
