Idc10   Erial   P Ort  ; Block   D Iagram   - MikroTik RouterBoard 1200 User Manual

Hide thumbs Also See for RouterBoard 1200:
Table of Contents

Advertisement

Enlarged version
IDC10   s erial   p ort
J402   i s   a   I DC10   t ype   s erial   p ort   c onnector.
DTR
4
CTS
8
TXD
3
RTS
7
RXD
2
DSR
6
DCD
1
GND
5

Pins   1 ,4,6   a re   c onnected   t ogether.   P in   9   a nd   p in   1 0   a re   n ot   c onnected
Block   d iagram
RouterBOARD 1200 Series User's Manual


11
