[PA UNIT]

REF ORDER
NO. NO.
C61 4030004740 S.CERAMIC
C62 4030005140 S.CERAMIC
C63 4510006650 S.ELECTROLYTIC ECEV1EA100SR
C68 4030011740 S.CERAMIC
C69 4030011740 S.CERAMIC
C70 4030005050 S.CERAMIC
C71 4030011550 S.CERAMIC
C72 4030014460 S.CERAMIC
C73 4030011760 S.CERAMIC
C74 4030011760 S.CERAMIC
C75 4030011760 S.CERAMIC
C76 4030011760 S.CERAMIC
RL1 6330001600 RELAY
J3 6510022000 S.CONNECTOR
J6 6510007020 CONNECTOR
J7 6510007020 CONNECTOR
F1 5210000130 FUSE
F2 5220000230 HOLDER
F3 5220000230 HOLDER
WS1 8600036630 E.OTHER
WS2 8600036640 E.OTHER
EP1 6910000610 BEAD
EP2 6910000610 BEAD
EP9 6910000630 BEAD
EP10 6910000630 BEAD
EP11 0910052036 PCB
EP15 9045810001 TUBE
EP16 9045810001 TUBE
EP18 9045810001 TUBE
EP21 0910052522 PCB

[FILTER UNIT]

REF ORDER
NO. NO.
D1 1160000070 S.DIODE
D2 1790000980 S.DIODE
D3 1790000980 S.DIODE
L1 6140001990 COIL
L2 6140002000 COIL
L3 6140001780 COIL
L4 6140001790 COIL
L5 6140001800 COIL
L6 6140001800 COIL
L7 6140003500 COIL
L8 6140003500 COIL
L9 6110002910 COIL
L10 6110002920 COIL
L11 6110002890 COIL
L12 6110002900 COIL
L13 6140003490 COIL
L14 6140002520 COIL
L15 6200002040 S.COIL
L16 6200005050 S.COIL
L17 6200005050 S.COIL
L18 6200005050 S.COIL
L19 6200005050 S.COIL
L20 6200005010 S.COIL
L21 6200005010 S.COIL
L22 6200002040 S.COIL
L23 6200002040 S.COIL
L24 6140001810 COIL
L25 6110001680 COIL
DESCRIPTION
C2012 JB 1H 472K-T-A
[EUR], [ITA], [FRA], [ESP]
C3216 JB 1E 104K-T-A
[EUR], [ITA], [FRA], [ESP]
[EUR], [ITA], [FRA], [ESP]
GRM42-2 CH 201J 500PT
GRM42-2 CH 201J 500PT
C2012 CH 1H 331J-T-A
GRM42-6 CH 680J 500PT
GRM42-6 CH 820J 500PT
GRM44-1 SL 682J 200PT
GRM44-1 SL 682J 200PT
GRM44-1 SL 682J 200PT
GRM44-1 SL 682J 200PT
ALD 112
16FMN-BMTTR-TBT
TMP-J01X-V6
TMP-J01X-V6
FGB 4A
S-N5054 #01
S-N5054 #01
SX2242 J01 14 15 16 17PA
SX2242 J12 13PA
FSOH050RN01
FSOH050RN01
FSOH070RN
FSOH070RN
B 5380F
IRRAX 0.8 (d) L=20 mm
IRRAX 0.8 (d) L=20 mm
IRRAX 0.8 (d) L=20 mm
B 5477B
DESCRIPTION
DAN202K T146
MA742 (TX)
MA742 (TX)
LR-226 (T68-2)
LR-227 (T68-2)
LR-214 (T50-2)
LR-215 (T50-2)
LR-216 (T50-2)
LR-216 (T50-2)
LR-392
LR-392
LA-480
LA-481
LA-478
LA-479
LR-391
LR-290 (TR6X3X2 7A3)
NL 252018T-101J
NL 252018T-330J
NL 252018T-330J
NL 252018T-330J
NL 252018T-330J
NL 252018T-100J
NL 252018T-100J
NL 252018T-101J
NL 252018T-101J
LR-217 (T50-10)
LA-254
[FILTER UNIT]
REF ORDER
NO. NO.
L100 6200005050 S.COIL
L101 6200005050 S.COIL
L102 6200005010 S.COIL
L103 6200005050 S.COIL
L104 6200005010 S.COIL
L105 6200005050 S.COIL
R1 7540000100 ABSORBER
R2 7030003590 S.RESISTOR
R3 7030008190 S.RESISTOR
R4 7030003560 S.RESISTOR
R5 7030003560 S.RESISTOR
R6 7030003560 S.RESISTOR
R7 7030003400 S.RESISTOR
R8 7030003640 S.RESISTOR
R9 7030003640 S.RESISTOR
R20 7030003580 S.RESISTOR
C1 4030008920 S.CERAMIC
C2 4030008920 S.CERAMIC
C3 4030008920 S.CERAMIC
C4 4030008920 S.CERAMIC
C5 4030008920 S.CERAMIC
C6 4030008920 S.CERAMIC
C7 4030008920 S.CERAMIC
C8 4030008920 S.CERAMIC
C9 4030006880 S.CERAMIC
C10 4030006880 S.CERAMIC
C11 4030006880 S.CERAMIC
C12 4030006880 S.CERAMIC
C13 4030006880 S.CERAMIC
C14 4030007130 S.CERAMIC
C15 4030007010 S.CERAMIC
C16 4030007130 S.CERAMIC
C17 4610001340 TRIMMER
C18 4030007160 S.CERAMIC
C19 4030006870 S.CERAMIC
C20 4030011340 S.CERAMIC
C21 4030011340 S.CERAMIC
C22 4010007510 CERAMIC
C23 4010005880 CERAMIC
C24 4010005880 CERAMIC
C25 4010007510 CERAMIC
C26 4030012480 S.CERAMIC
C27 4010007510 CERAMIC
C28 4010005870 CERAMIC
C29 4010005850 CERAMIC
C30 4010005360 CERAMIC
C31 4010005870 CERAMIC
C32 4010005930 CERAMIC
C33 4010005750 CERAMIC
C34 4010005870 CERAMIC
C35 4010005870 CERAMIC
C36 4010005870 CERAMIC
C37 4010005850 CERAMIC
C38 4030012480 S.CERAMIC
C39 4010005820 CERAMIC
C40 4010005370 CERAMIC
C41 4010005880 CERAMIC
C43 4010005760 CERAMIC
C44 4010005880 CERAMIC
C45 4010005830 CERAMIC
C46 4010005860 CERAMIC
C47 4010005780 CERAMIC
C48 4030014460 S.CERAMIC
C49 4010005830 CERAMIC
C50 4030011180 S.CERAMIC
C51 4030014460 S.CERAMIC
C52 4030011730 S.CERAMIC
C53 4010005750 CERAMIC
C54 4010005850 CERAMIC
C55 4030011240 S.CERAMIC
C56 4010005780 CERAMIC
C58 4030011230 S.CERAMIC
C60 4010005620 CERAMIC
C61 4030014460 S.CERAMIC
C63 4030006870 S.CERAMIC
C64 4010007590 CERAMIC
C65 4010007590 CERAMIC
C66 4010007590 CERAMIC
6 - 13
DESCRIPTION
NL 252018T-330J
NL 252018T-330J
NL 252018T-100J
NL 252018T-330J
NL 252018T-100J
NL 252018T-330J
SRYH-350L
ERJ3GEYJ 183 V (18 kΩ)
ERJ12YJ330U (33 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 101J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 101J-T-A
ECR-LA010 A12
C1608 CH 1H 181J-T-A
C1608 JB 1H 222K-T-A
C1608 CH 1H 471J-T-A
C1608 CH 1H 471J-T-A
HM17SJ SL 821J 500V
HM95SJ SL 271J 500V
HM95SJ SL 271J 500V
HM17SJ SL 821J 500V
GRM42-6 CH 121J 500PT
HM17SJ SL 821J 500V
HM95SJ SL 221J 500V
HM95SJ SL 181J 500V
HM11SJ SL 301J 500V
HM95SJ SL 221J 500V
HM11SJ SL 391J 500V
HM60SJ SL 680J 500V
HM95SJ SL 221J 500V
HM95SJ SL 221J 500V
HM95SJ SL 221J 500V
HM95SJ SL 181J 500V
GRM42-6 CH 121J 500PT
HM74SJ SL 121J 500V
HM11SJ SL 331J 500V
HM95SJ SL 271J 500V
HM60SJ SL 750J 500V
HM95SJ SL 271J 500V
HM74SJ SL 151J 500V
HM95SJ SL 201J 500V
HM60SJ SL 101J 500V
GRM42-6 CH 820J 500PT
HM74SJ SL 151J 500V
GRM42-6 CH 220J 500PT
GRM42-6 CH 820J 500PT
GRM42-6 CH 101J 500PT
HM60SJ SL 680J 500V
HM95SJ SL 181J 500V
GRM42-6 CH 470J 500PT
HM60SJ SL 101J 500V
GRM42-6 CH 390J 500PT
HM60SJ SL 120J 500V
GRM42-6 CH 820J 500PT
C1608 JB 1H 222K-T-A
HM15SJ SL 681J 500V
HM15SJ SL 681J 500V
HM15SJ SL 681J 500V
S.=Surface mount
