Signal Encoding and Pilot Tone

In addition to controlling the limiter, the DSP also en-
codes the digitized audio from the A/D converter and
adds an ultrasonic pilot tone to control the squelch in
the receiver. A pilot tone squelch system provides a reli-
able method of keeping a receiver output muted (audio
mute) even in the presence of significant interference.
When the system is operating in the hybrid mode, a dif-
ferent pilot tone frequency is generated for each carrier
frequency to prevent inadvertent squelch problems in
multi-channel sytems.

Microprocessor Control

A microprocessor monitors user command inputs from
the control panel buttons and numerous other internal
signals. It works intimately with the DSP to ensure the
audio is encoded according to the selected Compatibil-
ity Mode and that the correct pilot tone is added to the
encoded signal.

Compatibility Modes

SM transmitters are designed to operate with Lec-
trosonics Digital Hybrid receivers and will yield the
best performance when doing so, however, due to the
flexibility of digital signal processing, the transmitter
can also operate in various compatibility modes for use
with Lectrosonics 200 Series, Lectrosonics 100 Series,
IFB and certain non-Lectrosonics receivers. Contact
the Lectrosonics sales department for more information
about non-Lectrosonics receivers.

Control Panel

The control panel includes four membrane switches and
an LCD screen to adjust the operational settings. Multi-
color LEDs are used to indicate audio signal levels for
accurate gain adjustment and for battery status.

Wide-Band Deviation

±75 kHz deviation improves the signal to noise ratio and
audio dynamic range of a wireless system dramatically,
compared to other designs that use ±30 kHz to 40 kHz
deviation. Wide deviation combined with a high powered
transmitters makes a significant improvement in signal
to noise ratio and operating range.

Variable Power Output

This advanced feature allows the operator to optimize
the transmitter for maximum battery life, or for maximum
operating range. Power output is selected using the
LCD in a setup mode while the RF output of the trans-
mitter is turned off.
Rio Rancho, NM
Super-Minature Belt Pack Transmitter

Battery Options and Operating Time

Switching power supplies convert regulated battery
voltages to operate various circuit stages with maxi-
mum efficiency. With the variety of alkaline, lithium and
rechargeable NiMH batteries available today in the AA
format, there are many choices to maximize operating
time or minimize cost as needed for any application.
The firmware "remembers" the power status when a
battery fails, so the transmitter will be turned on auto-
matically when the battery is replaced and the previous
settings will be enabled.

Frequency Blocks

Lectrosonics established a "block" numbering system
years ago to organize the range of frequencies avail-
able from the low end at 470 MHz band to the upper
end at 952 MHz. Each block (except 944) includes 256
frequencies in 100 kHz steps, which is the maximum
switching range of the transmitters. Block 944 is a spe-
cial band between 944 and 952 MHz.

Circulator/Isolator

The RF output circuit includes a one way circulator/iso-
lator using a magnetically polarized ferrite. This device
greatly reduces RF intermodulation produced when
multiple transmitters are used in close proximity to one
another (several feet apart). The isolator also provides
additional RF output stage protection against static
shock.
