9. Fixture Cleaning
The cleaning of internal must be carried out periodically. Cleaning frequency
depends on the environment in which the fixture operates: damp, smoky or
particularly dirty surrounding can cause greater accumulation of dirt.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external at least every 20 days.
Innovation, Quality, Performance
LED-HC101 II
毅丰
2014.05.10
受控正本
LED-HC101 II
User Manual
Please read the instructions carefully before use
