Sun Microsystems Netra X4200 M2 Service Manual page 162

TABLE D-7
Segment
Backside
Signal
Segment
Power
Segment
146 Netra X4200 M2 Server Service Manual • May 2007
Serial Attached SCSI Connector Pinouts (Continued)
Pin Number Pin Name
S8 Gnd
S9
S10
S11 Gnd
S12
S13
S14 Gnd
P1 3.3 V
P2 3.3 V
P3 3.3 V
P4 Gnd
P5 Gnd
P6 Gnd
P7 5.0 V
P8 5.0 V
P9 5.0 V
P10 Gnd
P11 Reserved
P12 Gnd
P13 12.0 V
P14 12.0 V
P15 12.0 V
Description
Second mate ground
Not used
Not used
Second mate ground
Not used
Not used
Second mate ground
Not used
Not used
Not used
First mate ground
Second mate ground
Second mate ground
Pre-charge, second mate
Third mate 5 V
Third mate 5 V
Second mate ground
Not used
First mate ground
Pre-charge, second mate
Third mate 12 V
Third mate 12 V
