Ucc/Ean 128, Tci 50 - Microcom 224 Operator's Manual

Bar Codes
^D176
Rotation
Planet Code String
EXAMPLE:
^D176
3 <------------------------------------ Rotation parameter
1234567890123 <---------------- Planet Code data
^D57
1,832,2000,0,0,08,2,1,,0,0
1,400,400,1,49,,,4,12,3 <------- Placement information
^D56
^D2
.
^D3
8.1.23

UCC/EAN 128, TCI 50

UCC/EAN 128 symbologies are actually code 128 bar codes that have specific data format
guidelines for multiple data subfields. The subfields are identified by application identifiers
that are specified in the "UCC/EAN Application Identifier Standard" available from the
Uniform Code Council, Inc.®.
Data strings can contain one or more substrings appended onto one line. Each substring
can consist of a 2, 3 or 4 digit Application Identifier immediately followed by a data string
meeting the formatting requirements for that specific Application Identifier.
The following table is a list of the supported Application Identifiers and their specific data
format requirements.
Use the legend below when interpreting the data format requirements listed in the table
below:
a alphabetic character
n numeric number
an alphanumeric character
a3 3 alphabetic characters (fixed length)
n3 3 numeric characters (fixed length)
an3 3 alphanumeric characters (fixed length)
a..3 3 alphabetic characters (variable length)
n..3 3 numeric characters (variable length)
an..3 3 alphanumeric characters (variable length)
(*) Indicates only year and month, DD must be filled with "00"
(**) Plus one digit for length indication
(***) Plus one digit for decimal point indication
AI
00
01
10
8-22
Content
SCC-18
SCC-14
Batch or Lot Number
224/424 Operator's Manual - 880027-0141
Chapter 8
Format
n2+n18
n2+n14
n2+an..20
