< 3.2 > KVM port connection
KVM-USB/VGA-6 / -10 / -15
■
6 / 10 / 15 ft USB KVM cable
■
Support USB server
USB Servers
UM-CV-751-USBKVM-Q113V1
16 15
8 7
- 6 / 10 / 15 USB KVM cable
support USB server
DB-15 USB KVM port
14 13 12
6 5 4
P.12
USB Hub DB-15 KVM
USB Servers
11 10 9
3 2 1
