dedicated KVM switch and rackmount screen technology

User Manual

Combo DB-15
2-console KVM
KVM-IP8 / KVM-IP16
Combo DB-15
2-console KVM
KVM-08R / KVM-16R
Combo DB-15 KVM
KVM-S8 / KVM-S16
751
UM-CV-751-SKVM-Q113V1
www.rackmountsales.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KVM-IP8 and is the answer not in the manual?

Questions and answers

Related Manuals for Crystal Image Technologies KVM-IP8

Summary of Contents for Crystal Image Technologies KVM-IP8

  • Page 1: User Manual

    KVM switch and rackmount screen technology User Manual Combo DB-15 2-console KVM KVM-IP8 / KVM-IP16 Combo DB-15 2-console KVM KVM-08R / KVM-16R Combo DB-15 KVM KVM-S8 / KVM-S16 UM-CV-751-SKVM-Q113V1 www.rackmountsales.com...

  • Page 2: Legal Information

    Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.

  • Page 3: Table Of Contents

    Contents < Part 1 > Combo DB-15 2-console KVM KVM-IP8 KVM-IP16 Package contents KVM port connection IP & Local console connection IP console setting KVM Cascade Specifi cations < Part 2 > Combo DB-15 2-console KVM KVM-08R KVM-16R Package contents KVM port connection Remote &...

  • Page 4: Before Installation

    Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.

  • Page 5: Part 1 > Combo

    Part 3. Combo DB-15 KVM < 3.1 > Package Contents Combo DB-15 KVM KVM-S8 / KVM-S16 KVM unit KVM-S8 or KVM-S16 KVM unit x 1 • • Mounting set w/ bracket & screws x 1 • Power cord ( for KVM ) x 1 KVM-S8 Local Console Power...

  • Page 6: Kvm Port Connection

    < 3.2 > KVM port connection Combo DB-15 KVM KVM-COMBO-6 / -10 / -15 USB Servers ■ 6 / 10 / 15 ft Combo KVM cable ■ Support PS/2 or USB server DB-15 Combo KVM port - 6 / 10 / 15 Combo KVM cable support PS/2 or USB server PS/2 Servers P.12...

  • Page 7: Kvm Cascade

    < 3.3 > KVM Cascade Combo DB-15 KVM ■ Cascade up to 8 levels, 128 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of KVM-S8 / CV-S16. When multiple combo DB-15 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g.

  • Page 8: Specifi Cations

    < 3.4 > Specifi cations Combo DB-15 KVM KVM-S8 KVM-S16 ▀ KVM Port Number of ports: 8 or 16 Connector: DB-15 combo connector Connectivity: Combo 4-in-1 KVM cable, up to 6, 10 & 15 feet ▀ Local Console Graphic connector: 1 x DB-15 VGA Resolution: Up to 1600 x 1200...

  • Page 9: Part 4. Usage

    Part 4. Usage Combo DB-15 KVM Usage 4.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 8 ports Bank no.

  • Page 10: Password

    4.2 Password Combo DB-15 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”...

  • Page 11: Kvm Osd

    4.3 KVM OSD Combo DB-15 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter Complete / Switch to selected port...

  • Page 12: Kvm Hotkey & Remote Console Hotkey

    4.4 KVM Hotkey & Remote Console Hotkey Combo DB-15 KVM Usage Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock +...

  • Page 13: Dc Power 12V, 24V, 48V Input

    4.5 DC Power 12V, 24V, 48V Input Combo DB-15 KVM Usage Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA...
  • Page 14 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. UM-CV-751-SKVM-Q113V1 www.rackmountsales.com...
