- Page 1 KVM switch and rackmount screen technology Cat5-IP08 / 16 / 32 Combo Cat6 2-console KVM Cat5-08R / 16R / 32R Combo Cat6 KVM Cat5-08 / 16 / 32...
-
Page 2: Table Of Contents
Contents < Part 1 > Combo Cat6 2-console KVM Cat5-IP08 /-IP16 /-IP32 Package contents KVM port & Cat6 dongle connection IP & Local console connection IP console setting KVM Cascade IP Multi-port connection to remote PDU P.6 - 7 Specifi cations <... -
Page 3: Part 1 > Combo Cat6 2-Console Kvm
Part 2. Combo Cat6 2-console KVM < 2.1 > Package Content Combo Cat6 2-console KVM Cat5-08R/16R/32R U-802 / U-1602 / U-3202 • Combo KVM unit x 1 • Mounting set w/ bracket & screws x 1 KVM unit • Power cord ( for KVM ) x 1 X 1 set Receiver box Receiver’s power adapter... - Page 4 Combo Cat6 2-console KVM Local console x 1 Local Remote console x 1 Console Cat5-08R Remote Cascade Local Console Cat5-16R Remote Cascade Local Console Cat5-32R Remote Cascade P.10 UM-CV-UKVM-Q411V3 www.austin-hughes.com...
-
Page 5: Kvm Port & Cat6 Dongle Connection
< 2.2 > KVM port & Cat6 dongle connection Combo Cat6 2-console KVM USB Servers DVI-USB dongle CAT 5 / 6 cable max. 40 meters DVI-D Cat6 KVM port PS/2 Servers USB Servers PS/2 VGA-USB dongle VGA-PS/2 dongle CAT 5 / 6 cable max. -
Page 6: Remote & Local Console Connection
< 2.3 > Remote & Local console connection Combo Cat6 2-console KVM Local console Remote Cat6 Console Remote Receiver USB console CAT 5 / 6 cable max. 150m P.12 UM-CV-UKVM-Q411V3 www.austin-hughes.com... - Page 7 How to use a receiver to connect a remote console Combo Cat6 2-console KVM Receiver Local Computer Monitor Remote I/O Front Power Rear Local Remote Mouse Button Button KVM switch The receiver provides a hotkey function for remote console. Please refer to P.23 Monitor Remote Console...
-
Page 8: Kvm Cascade
< 2.4 > KVM Cascade Combo Cat6 2-console KVM ■ Cascade up to 8 levels, 256 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of Cat5-08 / -16 / -32 When multiple combo Cat6 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g. -
Page 9: Specifi Cations
< 2.5 > Specifi cations Combo Cat6 2-console KVM -08R -16R -32R KVM Port ▀ Number of ports: 8, 16 or 32 Connector: RJ-45 Connectivity: DVI-D / VGA connector dongle up to 40 meters (132 feet) via Cat6 / Cat5 cable Local Console ▀... -
Page 10: Part 4. Usage
Part 4. Usage Combo Cat6 KVM Usage 4.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 8 ports Bank no. -
Page 11: Password
4.2 Password Combo Cat6 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”... -
Page 12: Kvm Osd
4.3 KVM OSD Combo Cat6 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter Complete / Switch to selected port... -
Page 13: Kvm Hotkey & Remote Console Hotkey
4.4 KVM Hotkey & Remote Console Hotkey Combo Cat6 KVM Usage Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock +... -
Page 14: Dc Power 12V, 24V, 48V Input
Combo Cat6 KVM Usage 4.5 DC Power 12V, 24V, 48V Input Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA...
