Page 1: User Manual
KVM switch and rackmount screen technology User Manual USB Hub DB-15 2-console KVM KVM-IP8H / IP16H USB Hub DB-15 2-console KVM KVM-8RH / KVM-16RH USB Hub DB-15 KVM KVM-08H / KVM-16H UM-CV-751-USBKVM-Q113V1 www.rackmountsales.com... -
Page 2: Legal Information
Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment. -
Page 3: Table Of Contents
Contents < Part 1 > USB Hub DB-15 2-console KVM KVM-IP8H KVM-IP16H Package contents KVM port connection IP & Local console connection IP console setting Built-in USB hub usage & connection Specifi cations < Part 2 > USB Hub DB-15 2-console KVM... -
Page 4: Before Installation
Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. -
Page 5: Part 1 > Usb Hub
Part 3. USB Hub DB-15 KVM < 3.1 > Package Contents USB Hub DB-15 KVM KVM-S8H / KVM-S16H KVM unit KVM-S8H or KVM-S16H KVM unit x 1 • • Mounting set w/ bracket & screws x 1 • Power cord ( for KVM ) x 1 KVM-S8H Power Local Console... -
Page 6: Kvm Port Connection
< 3.2 > KVM port connection USB Hub DB-15 KVM KVM-USB/VGA-6 / -10 / -15 USB Servers ■ 6 / 10 / 15 ft USB KVM cable ■ Support USB server DB-15 USB KVM port - 6 / 10 / 15 USB KVM cable support USB server USB Servers P.12... -
Page 7: Built-In Usb Hub Usage & Connection
< 3.3 > Built-in USB Hub Usage & Connection USB Hub DB-15 KVM 2 x USB 2.0 ( USB hub for device connection ) Flash Disk Hard disk storage Keyboard / Mouse Scanner Printer Camera P.13 UM-CV-751-USBKVM-Q113V1 www.rackmountsales.com... -
Page 8: Specifi Cations
< 3.4 > Specifi cations USB Hub DB-15 KVM KVM-S8H KVM-S16H ▀ KVM Port Number of ports: 8 or 16 Connector: DB-15 combo connector Connectivity: Combo 2-in-1 VGA + USB KVM cable, 6, 10 or 15 feet ▀ Local Console Graphic connector: 1 x DB-15 Resolution:... -
Page 9: Part 4. Usage
Part 4. Usage USB Hub DB-15 KVM Usage 4.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 8 ports Bank no. -
Page 10: Password
4.2 Password USB Hub DB-15 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”... -
Page 11: Kvm Osd
4.3 KVM OSD USB Hub DB-15 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter Complete / Switch to selected port... -
Page 12: Kvm Hotkey & Remote Console Hotkey
4.4 KVM Hotkey & Remote Console Hotkey USB Hub DB-15 KVM Usage Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port... -
Page 13: Dc Power 12V, 24V, 48V Input
4.5 DC Power 12V, 24V, 48V Input USB Hub DB-15 KVM Usage Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA... - Page 14 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. UM-CV-751-USBKVM-Q113V1 www.rackmountsales.com...
