Crystal Image Technologies KVM-8-2K User Manual

Dedicated kvm switch and rackmount screen technology
Hide thumbs

Advertisement

Quick Links

Download this manual
dedicated KVM switch and rackmount screen technology
User Manual
KVM-8-2K
751
2K KVM
UM-CV-2KKVM-Q120V1
www.rackmountsales.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the KVM-8-2K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Crystal Image Technologies KVM-8-2K

Summary of Contents for Crystal Image Technologies KVM-8-2K

  • Page 1 KVM switch and rackmount screen technology User Manual KVM-8-2K 2K KVM UM-CV-2KKVM-Q120V1 www.rackmountsales.com...

  • Page 2: Legal Information

    Legal Information First English printing, January 2020 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.

  • Page 3: Before Installation

    Contents KVM-8-2K < Part. 1 > 2K KVM Package Contents KVM port connection Specifi cations < Part. 2 > 2K KVM Usage KVM Button KVM Hotkey Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface.

  • Page 4: Package Contents

    2K KVM unit x 1 • Mounting set w/ bracket & screws x 1 • Power adapter w/ power cord ( for KVM ) x 1 KVM-8-2K Video Keyboard Mouse IP console, remote console, daisy-chain and OSD menu are NOT available for this model.

  • Page 5: Kvm Port Connection

    < 1.2 > KVM port connection 2K KVM DVI-D HDMI KVM-DK-6 KVM cable KVM-HK-6 KVM cable USB-A USB-A Video Keyboard Mouse Local Console KVM port x 8 1 x HDMI 1.4 ( HDMI + USB-B ) 2 x USB-A ( KB / MS ) 2K KVM Cable KVM-DK-6 : 6 feet DVI-D KVM cable ( Server end : DVI-D + USB-A )

  • Page 6: Specifications

    < 1.3 > Specifi cations 2K KVM KVM-8-2K KVM Port ▀ Number of ports : Connector : HDMI 1.4 + USB-B ( Video + KB / MS ) Resolution : 16 : 9 - max. 2560 x 1440@60Hz 16 : 10 - max. 1920 x 1200@60Hz 4 : 3 - max.

  • Page 7: Kvm Button

    < Part 2 > Usage 2K KVM Usage < 2.1 > KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 8 ports PC port LEDs...

  • Page 8: Kvm Hotkey

    < 2.2 > KVM Hotkey 2K KVM Usage Hotkey Function Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock + Port no. Switch to specifi c port Scroll Lock + Scroll Lock + Auto scan for powered on PC Scroll Lock + Scroll Lock +...
