- Page 1 KVM switch and rackmount screen technology User Manual Combo Cat6 2-console KVM Cat5-IP08 / Cat5-IP16 / Cat5-IP32 Combo Cat6 2-console KVM Cat5-08R / Cat5-16R / Cat5-32R Combo Cat6 KVM Cat5-08 / Cat5-16R / Cat5-32R UM-CV-751-KVM-Q113V1 www.rackmountsales.com...
- Page 3 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 4: Table Of Contents
KVM port & Cat6 dongle connection IP & Local console connection IP console setting KVM Cascade Specifi cations < Part 2 > Combo Cat6 2-console KVM Cat5-08R Cat5-16R Cat5-32R Package contents KVM port & Cat6 dongle connection Remote & Local console connection P.9 - 10... - Page 5 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 6: Package Contents
Part 3. Combo Cat6 KVM < 3.1 > Package Contents Combo Cat6 KVM Cat5-08 / Cat5-16 / Cat5-32 KVM unit Cat5-08 or Cat5-16 or Cat5-32 KVM unit x 1 • • Mounting set w/ bracket & screws x 1 • Power cord ( for KVM ) x 1 Cat5-08 Local Console... -
Page 7: Kvm Port & Cat6 Dongle Connection
< 3.2 > KVM port & Cat6 dongle connection Combo Cat6 KVM USB Servers DVI-USB dongle CAT 5 / 6 cable max. 40 meters DVI-D Cat6 KVM port PS/2 Servers USB Servers PS/2 VGA-USB dongle VGA-PS/2 dongle CAT 5 / 6 cable max. -
Page 8: Kvm Cascade
< 3.3 > KVM Cascade Combo Cat6 KVM ■ Cascade up to 8 levels, 256 servers ■ Cascading multiple KVM with CBC-6 cascade cable. Cascaded KVMs from level 2 to 8 must be the models of Cat5-08 / Cat5-16 / Cat5-32. When multiple combo Cat6 KVMs cascade together, the master KVM at level 1 will take all control of other slave KVM switches (e.g. -
Page 9: Specifi Cations
< 3.4 > Specifi cations Combo Cat6 KVM Cat5-08 Cat5-16 Cat5-32 KVM Port ▀ Number of ports: 8, 16 or 32 Connector: RJ-45 Connectivity: DVI-D / VGA connector dongle up to 40 meters (132 feet) via Cat6 / Cat5 cable Local Console ▀... -
Page 10: Part 4. Usage
Part 4. Usage Combo Cat6 KVM Usage 4.1 KVM Button Power ON ■ Turn off all servers and KVM switches ■ Make sure all cables / connectors are properly connected ■ Recommend Power ON sequence is monitor, KVM switch fi nally computer Front Panel - Port LED Indications 8 ports Bank no. -
Page 11: Password
4.2 Password Combo Cat6 KVM Usage The password is enabled by default, the default password is “00000000” eight zeros (Do not use “0” on number pad) ■ Enable password Scroll Lock + Scroll Lock + U Press the KVM hotkey Scroll Lock + Scroll Lock + P Logout the KVM by pressing the hotkey In SUPERVISOR level, enter “00000000”... -
Page 12: Kvm Osd
4.3 KVM OSD Combo Cat6 KVM Usage OSD Menu OSD operation next to the system name The PC is powered on next to the system name The PC is selected Access F1 MAIN MENU Logout the OSD menu Previous menu Cancel / Quit Enter Complete / Switch to selected port... -
Page 13: Kvm Hotkey & Remote Console Hotkey
4.4 KVM Hotkey & Remote Console Hotkey Combo Cat6 KVM Usage Local Console Hotkey Function Scroll Lock + Scroll Lock + Space Bar Calling OSD menu Right-button mouse + Esc Calling OSD menu Scroll Lock + Scroll Lock + Switch to previous port Scroll Lock + Scroll Lock + Switch to next port Scroll Lock + Scroll Lock +... -
Page 14: Dc Power 12V, 24V, 48V Input
4.5 DC Power 12V, 24V, 48V Input Combo Cat6 KVM Usage Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA... - Page 16 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. UM-CV-751-KVM-Q113V1 www.rackmountsales.com...
