Summary of Contents for Clarke HLS130
- Page 1 WARNING: Do not use the machine without reading this manual HOT WASHER MODEL NO: HLS130 PART NO: 7320525 OPERATION & MAINTENANCE INSTRUCTIONS GC0413...
- Page 2 This guarantee does not effect your statutory rights. LIST OF CONTENTS The following items should be supplied in the carton. If any parts are missing or damaged, please see your Clarke dealer where you purchased the machine. 1 x Hot Washer 1 x High Pressure Hose...
-
Page 3: General Safety Rules
13. WARNING:Always disconnect from the electrical power supply and remove the plug from the socket before carrying out user maintenance. 14. ONLY use original spare parts from the Clarke service department. 15. WARNING: High pressure hoses, fittings and couplings are important for the safety of the ma chine . -
Page 4: Safety Symbols
SAFETY SYMBOLS Total Stop System WARNING: Do not discharge the water spray at persons or animals. Keep clear of nozzle. WARNING: Never direct spray toward any electrical device or electrical outlet. Detergent Tank WARNING: Risk of hot sur faces. Avoid Water Input hot exhaust components. -
Page 5: Elecrical Connections
ELECRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 1ph 50Hz. -
Page 6: Parts Identification
PARTS IDENTIFICATION Spray Gun and Lance 11 Electric Motor High Pressure Hose 12 Braked Castor Water Outlet 13 Exhaust Water Inlet 14 Boiler Power Cable 15 High Pressure Pump Detergent Pickup Hose 16 Fuel Tank Filler Cap On/OFF Switch 17 Detergent Tank Temperature Regulator 18 Transformer Pressure Gauge... -
Page 7: Before Use
BEFORE USE CHECKING THE OIL WARNING: TO CARRY OUT THIS CHECK, PLACE THE PRESSURE WASHER ON LEVEL GROUND WHILE SWITCHED OFF. WARNING: TAKE CARE NOT TO TOUCH ANY HOT PARTS WHEN CHECKING THE OIL LEVEL. 1. Remove the cover from the pressure washer by removing the securing thumbscrew from the front and then the rear of the... -
Page 8: Filling With Fuel
CLARKE Wash & Wax, both available from your CLARKE dealer. The use of unsuitable cleaning agents may adversly affect the safety of the machine. Do not exceed the correct operating temperature. -
Page 9: Connecting The Mains Water Supply
CONNECTING THE MAINS WATER SUPPLY The pressure washer must never be connected to the drinking water supply without using a system separator (also known as a backflow preventer) available from most hardware stores. Always follow the regulations of your local water supplier. CAUTION: WATER THAT HAS FLOWED THROUGH A SYSTEM SEPARATOR IS CONSIDERED NON-DRINKABLE. -
Page 10: Connecting The High Pressure Hose
CONNECTING THE HIGH PRESSURE HOSE 1. Screw the high pressure hose onto the gun assembly. 2. Use a spanner to tighten the connector. 3. Screw the other end of the hose on to the pressure washer outlet. • Tighten the connector hand tight only;- do not use a spanner. -
Page 11: Operation
OPERATION 1. The pressure washer should always be located on a firm level surface where it is not exposed to extreme weather conditions such as strong wind, freezing or rain. 2. It is recommended that where possible a partition be erected between the wash area and the pressure washer to prevent accidental spraying of the pressure washer. -
Page 12: Geting Started
GETING STARTED 1. Ensure that the water supply is correctly connected and turned on. WARNING: FAILURE TO TURN ON THE WATER FULLY COULD CAUSE DAMAGE TO THE PRESSURE WASHER. 2. Set the start switch (C) to ‘I’. 3. Release the trigger lock. 4. -
Page 13: Using Detergent
USING DETERGENT WARNING: IF OPERATING THE MACHINE WITH DETERGENT INCLUDING CLARKE CLEANING PRODUCTS, TAKE CARE NOT TO SET THE MACHINE TO OPERATING TEMPERATURES OF GREATER THAN 100 The detergent is applied by twisting... -
Page 14: After Use
AFTER USE 1. Set the start switch (C) to ‘O’. 2. Turn the water supply off at the tap. • NEVER turn the water off with the pressure washer running. 3. Release the pressure in the pump and hose by squeezing the trigger for a few seconds until no more water comes out of the nozzle. -
Page 15: Maintenance
• The pressure washer requires regular checks to be carried out at the following intervals. Please only use the correct spare parts as supplied by your Clarke dealer. DAILY (BEFORE EACH USE) CHECK THE OIL LEVEL OF THE PUMP 1. - Page 16 CLEANING THE COMBUSTION HEAD & CHECKING THE ELECTRODES It is recommended that the burner and electrodes be serviced yearly, or as needed depending upon the pressure washers' usage. Please contact the CLARKE International Service Dept. LIMESCALE Periodically the heating coil should be checked for limescale buildup, dependant upon the hardness of the local water supply.
-
Page 17: Consumables Etc
It will also restrict air flow through the coil, further aggravating the soot build up. Contact your CLARKE dealer or CLARKE International Service Dept on: 020 8988 7400 if de-sooting is required. DE-COMMISSIONING PRODUCT Should the product become completely unserviceable and require disposal, draw off the oil into an approved container and dispose of the product and the oil according to local regulations. -
Page 18: Troubleshooting
65 degrees. Damaged or warn out Contact Clarke Service nozzle components. Department for replacement Coil is covered in limescale. Contact Clarke Service Department for advice on de-scaling. The burner does Dirty burner nozzle. Contact Clarke Service not turn on. -
Page 19: Product Specifications
Reduce water temperature. Water in the oil. Worn out piston rings/failed Contact Clarke Service gaskets. Department. Oil leaking from Worn out o-rings or gaskets. Contact Clarke Service the head. Department. Motor suddenly Thermal protection has Switch off the machine and stops. - Page 20 PARTS LIST - FRAME & BODY POS DESCRIPTION CODE POS DESCRIPTION CODE Machine Cover AR3160731 10 Detergent Tank AR3163900 Front Hose Carrier AR3160100 11 Braked Caster AR3164410 Screw AR2100300 12 Bracket AR3163910 Rear Hose Carrier AR3160110 13 Fuel Tank AR3161550 Wheel AR3164380 14 Wheel Retaining Clip AR3162010...
-
Page 21: Parts List - Water Pump Assembly
PARTS LIST - WATER PUMP ASSEMBLY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 22 PARTS LIST - WATER PUMP ASSEMBLY POS DESCRIPTION CODE POS DESCRIPTION CODE Bolt AR680570 O-ring AR480480 Washer AR1381550 28 Plate AR1260091 Oil Level Glass AR1260250 29 Piston AR1260070 Securing Ring AR1260430 30 AR1260080 Plate AR1780690 31 Screw AR1260750 O-Ring AR1140450 32 Cover AR1329010 Plug...
-
Page 23: Parts Diagram - Valve Assembly
PARTS DIAGRAM - VALVE ASSEMBLY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 24 PARTS DIAGRAM - VALVE ASSEMBLY POS DESCRIPTION CODE POS DESCRIPTION CODE Screw AR1540560 20 O-ring AR390080 AR1980470 21 Valve Body AR1540510 Insert AR1980390 22 O-ring AR1140450 Wobble Plate AR1980220 23 O-ring AR1540630 Spring AR1271070 24 Suction Fitting AR1540280 Piston AR1080041 25 O-ring AR880270 AR1080070 26...
-
Page 25: Parts Diagram - Connecting Hoses
PARTS DIAGRAM - CONNECTING HOSES POS DESCRIPTION CODE POS DESCRIPTION CODE Pressure Gauge AR3161040 15 Fitting AR3160510 Fitting AR3164070 16 Pump Outlet Pipe AR3164400 Pipe AR3163500 17 Delivery Pipe AR3161310 Fitting AR3161110 18 Elbow Fitting AR3161190 Pressure Switch AR3162890 19 Fitting AR3161260 Detergent Hose... - Page 26 PARTS DIAGRAM - FAN & FUEL PUMP POS DESCRIPTION CODE POS DESCRIPTION CODE Cover Plate AR3161900 10 Boiler Housing AR3161460 AR3161810 11 Connecting Pipe AR3161620 Motor Assembly AR3161530 12 Tubing Clamp AR3162060 Coupling AR3160300 13 Fuel Filter AR3161520 Fitting AR3160330 14 Fuel Pickup Pipe AR3161610 Plug-in Cable...
-
Page 27: Parts Diagram - Controls Box
PARTS DIAGRAM - CONTROLS BOX POS DESCRIPTION CODE POS DESCRIPTION CODE Temp Control Knob AR3161960 7 Thermostat AR50720 On/Off Switch AR3160850 8 Fuse Holder AR3163720 Control Housing AR3161990 9 Fuse AR3160920 Display Panel AR3162080 10 Control Box AR3160930 Cover Plate AR3160940 11 Cable Gland AR3160860... -
Page 28: Parts Diagram - Boiler
PARTS DIAGRAM - BOILER POS DESCRIPTION CODE POS DESCRIPTION CODE Cable Protector AR3162370 12 Top Cover AR3161790 Fitting AR3161100 13 Cover with Flue AR3161780 O-Ring AR3162030 14 Coil AR3161750 Glass AR3161860 15 Support Ring AR3161430 Fitting AR3161230 16 Bottom Plate AR3161830 Plate AR3161840 17... - Page 29 PARTS DIAGRAM - SPRAY GUN & LANCE POS DESCRIPTION CODE POS DESCRIPTION CODE AR41089 Lance AR40826 High Pressure Hose AR3160160 4 Nozzle AR3082 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 30: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 31 DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
