- Page 1 COLD WATER WASHER COLD WATER WASHER Model Nos. ELS145, 145R & ELS160R Part Nos. 7320612, 7320617 & 7320622 0108 OPERATING & MAINTENANCE INSTRUCTIONS...
-
Page 2: Specifications
Weight Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machines data plate PARTS &... -
Page 3: Table Of Contents
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the dote of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended. -
Page 4: Safety Precautions
Never operate the machine with the covers removed. Do not, attempt any electrical or mechanical repair. If you have a problem with your machine contact your local dealer or Clarke Customer Services Dept., tel: 020 8988 7400 Never supply any liquid other than water to the water inlet. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: THIS MACHINE MUST BE EARTHED. This product is provided with a standard 13 amp, 230 volt (50Hz). BS 1363 plug, for connection to a standard, domestic electrical supply. Should the plug need changing at any time, ensure that a plug of identical specification is used. IMPORTANT: The wires in the mains lead should be wired up in accordance with the following colour code: Green &... -
Page 6: Assembly And Preparation For Use
ASSEMBLY AND PREPARATION The machine is supplied fully assembled except as detailed below. Fig.1 Attach the cable and hose storage brackets by sliding them into place on either side of the handle assembly, as shown in Fig.1. Model ELS145 &145R The lance is in two sections, Fig.2 the high pressure hose being... -
Page 7: Operation
ALL Models The low pressure water inlet, shown in Fig. 3, carries a 3/4” BSP thread. A 3/4” BSP adapter with a 1/2” hose connector is provided, so that a suitable hose (not supplied), may be attached. You may use a either a worm drive clip (not supplied), or a snap-on type connector, commonly available from most hardware or DIY stores, to attach the hose, the other end of which should be connected to your water supply. - Page 8 Hold the trigger in that position whilst switching the pump ON, and allow the pump to run for a few moments to develop full pressure You may release the trigger once full pressure is developed. In doing so the pump will stop, and will start again as soon as the trigger is pressed once more. NOTE: For the reasons given above, it is recommended that you ALWAYS set the jet to its LOW PRESSURE setting before switching ON.
-
Page 9: Chemical Injection Facility
Fig.10 15:1...Min-approx. 1000:1. Use ONLY those detergents specifically designed for use with Power Washers. We recommend the use of CLARKE Traffic Film Remover, which is a powerful low foaming agent for car cleaning, patio cleaning etc., or CLARKE Wash & Wax, both available from your CLARKE dealer. -
Page 10: Maintenance
MAINTENANCE WARNING: Ensure the plug is removed from the socket before carrying out any adjustment, servicing or maintenance. AFTER EACH USE When using chemical detergents, always ensure the system is thoroughly flushed out after use as described above. Ensure the hoses and power cable are coiled and properly stowed. DO NOT allow them to be left casually, in a heap. -
Page 11: Troubleshooting
3. No water due to clogged 3. Clean water filter inlet filter Oil leak Worn seals Contact your CLARKE Dealer 1. Plug is not connected 1. Check plug and lead and Motor does not start have them replaced by a properly. -
Page 12: Parts List And Diagram
PARTS DIAGRAM - ELS145... - Page 13 PARTS LIST - ELS145 KIT NO. KIT ITEM DESCRIPTION PART NO. KTRI93635 Front Cover MPVR92126 KTRI93502 Lower Front Cover MPVR92120 Screw VTVT80745 KTRI93503 Axle LAFN92146 Wheel RTRT91967 Locking Washer VTRS60945 End Cap MPVR91970 KTRI93504 Motor Cover MPVR92355 Screw VTVT67350 KTRI93505 Rear Cover MPVR92122 Screw...
- Page 14 PUMP AND MOTOR PARTS - ELS145...
- Page 15 50-51 PARTS & SERVICE CONTACTS For Spare Parts and Service, please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 e-mail as follows: PARTS: Parts@clarkeinternational.com...
- Page 16 PARTS DIAGRAM - ELS145R - 160R...
- Page 17 PARTS LIST - ELS145R - 160R KIT NO: ITEM DESCRIPTION PART NO: Screw VTVT90541 Screw (ELS145R) VTVT29810 Washer VTRS63242 Screw (ELS145R) VTRS00512 Screw VTVT80745 Screw VTVT01573 Clamp MPVR60495 Screw VTVT67350 Screw VTVT62978 KTRI93635 Front Cove MPVR92126 KTRI93502 Lower Front Cover MPVR92120 Screw VTVT80745...
- Page 18 PUMP AND MOTOR PARTS - ELS145R & ELS160R...
- Page 19 PUMP AND MOTOR PARTS LIST - ELS145R & 160R Please note that parts are available in kit form only ELS45R Part No. Description Item Nos: KTRI94076 MANIFOLD KIT 8-45, 48 KTRI93529 CONTROL BOARD KIT 76, 82-84, 95-99 KTRI93583 CONTROL BOARD KIT 72-81, 90-94, 100-107, 109-110 KTRI82810 QUICK RELEASE COUPLING...
- Page 20 ELS145 LANCE ELS145R & 160R LANCE PARTS LIST Item Description Part No. Frame FPELS14001 Cover FPELS14002 ON/OFF switch box compl. FPELS14003 Motor w/Pump Assy. (ELS145) FPELS14004 Motor w/Pump Assy. (ELS160R) FPELS15004 Hydraulic cut out FPELS14005 High Press. Hose w/Gun assy. (ELS145) FPELS14006 High Press.
-
Page 21: Accessories
ACCESSORIES A range of accessories designed for use with your washer are available from your CLARKE dealer, as follows: ELS145/145R Part No. Rotary Brush ............7310010 Turbo Nozzle ............7310000 Car Brush ............. 7310020 Water Sandblaster ..........7310015 Drain Cleaner ............. 7310025 Foam Lance with Detergent Bottle ....
