Infinova V5822IR-A3 SERIES User Manual

Vandal resistant ir fixed minidome camera

Advertisement

Quick Links

V5822IR-A3 SERIES
VANDAL RESISTANT IR FIXED
MINIDOME CAMERA

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V5822IR-A3 SERIES and is the answer not in the manual?

Questions and answers

Summary of Contents for Infinova V5822IR-A3 SERIES

  • Page 1: User Manual

    V5822IR-A3 SERIES VANDAL RESISTANT IR FIXED MINIDOME CAMERA User Manual...
  • Page 2: Table Of Contents

    CONTENTS CHAPTER I DESCRIPTION ................1 CHAPTER II MAIN FEATURES ..............2 CHAPTER III INSTALLATION..............3 3.1 SURFACE MOUNTING ................. 3 3.2 WALL MOUNTING (WITH 86 BOX)............ 6 3.3 HANDLING PRECAUTIONS..............8 3.4 INSTALLATION PRECAUTIONS............8 CHAPTER IV CAMERA FUNCTION SETTING ........9 APPENDIX I SPECIFICATIONS ..............
  • Page 3: Chapter I Description

    CHAPTER I DESCRIPTION Thank you very much for purchasing our product. Infinova’s V5822IR-A3 series high resolution IR minidome cameras feature a high sensitivity 1/3" SONY Super HAD II CCD sensor. Advanced Digital Signal Processing (DSP) provides 520 TV lines of resolution and authentic images.
  • Page 4: Chapter Ii Main Features

    CHAPTER II MAIN FEATURES 1/3" SONY high resolution Super HAD II CCD sensor Resolution: 520 TVL IR-Cut Removable (ICR) Filter for Day/Night switching Built-in IR illuminators, 850nm wavelength, 25 meters radiant distance Adjustable power consumption of IR illuminators Super imaging performance at nighttime Auto Electronic Shutter (AES), Auto Gain Control (AGC), Backlight Compensation (BLC) Aspherical, auto-iris, vari-focal lens with IR correction...
  • Page 5: Chapter Iii Installation

    CHAPTER III INSTALLATION 3.1 Surface Mounting Step 1: Prepare mounting holes If the minidome camera’s pigtail is dragged out from the top of upper housing, drill mounting holes at the desired position. See the figure below for the size and location of mounting holes. Ø30.0 Cable hole Ø92.0...
  • Page 6 Figure 3-2 Step 3: Adjust viewing angle Check whether the cables are properly and firmly connected before powering on. The dome camera will perform a self-test for about 30 seconds after power-on. Then loosen the locking screw to adjust the camera angle according to your surveillance need.
  • Page 7 Step 5: Install dome bubble Install the bubble flange to upper housing. In this process, the shielding cover may block the camera. Thus, before securing the bubble, user should adjust the shielding cover to a proper position. Then, fasten the screws. With all the procedures finished, user should further confirm whether each part of the device is properly and firmly connected Figure 3-4...
  • Page 8: Wall Mounting (With 86 Box)

    3.2 Wall Mounting (with 86 box) Step 1: Install the adapter Fix the adapter to an 86 box with two M3.5 countersunk head screws. Figure 3-6 Step 2: Install upper housing Arrange the cables properly. Loosen the three mum-head screws in bubble flange and take off the bubble. For ease of installation, upper housing and dome bubble are connected with a safety lanyard.
  • Page 9 Step 3: Adjust viewing angle Check whether the cables are properly and firmly connected before powering on. The dome camera will perform a self-test for about 30 seconds after power-on. Then loosen the locking screw to adjust the camera angle according to your surveillance need.
  • Page 10: Handling Precautions

    3. If any abnormality occurs, make sure to unplug the unit and contact Infinova or your local dealer. 4. This camera possesses AGC circuit. Therefore, when the camera is used under lower luminance, the sensibility will strengthen automatically and make the image very rough in vision.
  • Page 11: Chapter Iv Camera Function Setting

    CHAPTER IV CAMERA FUNCTION SETTING In the upper housing, a 6-position DIP switch is used to adjust AGC, AES, BLC, etc. And another button is used to compensate the blemish. See the figure below for the location of the DIP switch and Blemish correction button. DIP switch Blemish correction button...
  • Page 12 BLC -- Backlight Compensation Function When the background of view is pretty bright and objects on front cannot be seen clearly, it needs to use back light compensation function. BLC: Activate BLC function, and then the workstations of AGC, AES, and IRIS confirm the entire view to distinguish the bright background area and the dark front objects.
  • Page 13 Blemish correction instruction: Pressing Blemish correction button, it can compensate the blemish in CCD, which is caused by long-time work. Note: In order to offer Black Burst to camera, it needs to cover the lens while compensating the blemish.
  • Page 14: Appendix I Specifications

    APPENDIX I SPECIFICATIONS Model V5822IR-A3 Image Sensor 1/3" SONY Super HAD II CCD Video System NTSC; PAL Scanning System 2:1interlace scanning Effective Pixels (H×V) NTSC: 768×494, 380K; PAL: 752×582, 440K Resolution 520 TVL Color mode: 0.2 lux @ F1.2 (30 IRE, AGC HIGH); Sensitivity B/W mode: 0 lux (IR ON) Infrared Wavelength...
  • Page 15 Power Consumption 12VDC: 4.5W; 24VAC: 5W Operating Temperature 14° F ~ 122° F (-10° C ~ 50° C) Storage Temperature -4° F ~ 140° F (-20° C ~ 60° C) Operating Humidity 0~90% RH (non-condensing) Unit Dimensions (Hר) 3.7"×5.2" (93mm×132mm) Box Dimensions 6.9"×6.9"×6.3"...
  • Page 16: Appendix Ii Cable Diameter Calculation And

    APPENDIX II CABLE DIAMETER CALCULATION AND LIGHTNING & SURGE PROTECTION Relation between 24VAC Cable Diameter and Transmission Distance In general, the maximum allowable voltage loss rate is 10% for AC-powered devices. The table below shows the relationship between transmission power and maximum transmission distance under a certain specified cable diameter, on condition that the 24VAC voltage loss rate is below 10%.
  • Page 17 Lightning & Surge Protection The product adopts multi-level anti-lightning and anti-surge technology integrated with gas discharge tube, power resistor and TVS tube. The powerful lightning and surge protection barrier effectively avoids product damage caused by various pulse signals with power below 4kV, including instantaneous lightning, surge and static.
  • Page 18 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V1.2 1205...
