Page 1: User Manual
V5821-A7 & V5822-A7 Series Vandal Resistant Electronic Day/Night & Day/Night Minidome Camera User Manual... -
Page 2: Table Of Contents
CONTENTS CHAPTER I DESCRIPTION ................1 CHAPTER II MAIN FEATURES ..............4 CHAPTER III INSTALLATION..............5 3.1 SURFACE MOUNTING ................. 5 3.2 WALL MOUNTING (WITH 86 BOX)............ 8 3.3 RECESSED MOUNTING..............10 3.4 HANDLING PRECAUTIONS.............. 12 3.5 INSTALLATION PRECAUTIONS............13 CHAPTER IV OPERATION INSTRUCTION.......... - Page 3 4.4.3 CONTRAST ................. 24 4.4.4 SHARP..................24 4.4.5 HUE ....................25 4.4.6 C-GAIN ..................25 4.4.7 NR ....................25 4.4.8 MONITOR..................25 4.5 WHITE BALANCE ................26 4.6 ASSIST FUNCTION ................28 4.6.1 ALARM ..................28 4.6.2 MOTION DET................28 4.6.3 PRIVACY ..................
-
Page 4: Chapter I Description
CHAPTER I DESCRIPTION Thank you very much for purchasing our product. Infinova’s V5821-A7 & V5822-A7 series high-performance minidome cameras feature a high resolution 1/3" SONY Exview HAD II CCD sensor and advanced Effio-E DSP. These cameras provide 700 TV lines of resolution, improved color rendering and digital noise reduction, which ensure excellent video under extremely difficult illumination conditions. - Page 5 2.5-6mm vari-focal lens V5821-A7004SE Analog minidome camera, 1/3 inch CCD, Vandal-resistant, 3-axis, Electronic day/night, 700TVL, NTSC, 12VDC/24VAC, Surface mount, 3.3-12mm vari-focal lens V5821-A7014SE Analog minidome camera, 1/3 inch CCD, Vandal-resistant, 3-axis, Electronic day/night, 700TVL, PAL, 12VDC/24VAC, Surface mount, 3.3-12mm vari-focal lens V5821-A7004RE Analog minidome camera, 1/3 inch CCD, Vandal-resistant, 3-axis, Electronic day/night,...
- Page 6 V5822-A7004SE Analog minidome camera, 1/3 inch CCD, Vandal-resistant, 3-axis, Day/night, 700TVL, NTSC, 12VDC/24VAC, Surface mount, 3.3-12mm vari-focal lens V5822-A7014SE Analog minidome camera, 1/3 inch CCD, Vandal-resistant, 3-axis, Day/night, 700TVL, PAL, 12VDC/24VAC, Surface mount, 3.3-12mm vari-focal lens V5822-A7004RE Analog minidome camera, 1/3 inch CCD, Vandal-resistant, 3-axis, Day/night, 700TVL, NTSC, 12VDC/24VAC, Recessed mount, 3.3-12mm vari-focal lens...
-
Page 7: Chapter Ii Main Features
CHAPTER II MAIN FEATURES 1/3" SONY Exview HAD II CCD sensor Resolution: 700TVL Electronic day/night functionality (V5821-A7 series) Automatic day/night functionality with ICR filter, settable AUTO/ DAY/ NIGHT mode (V5822-A7 series) Supports OSD menu display function 2D digital noise reduction Highlight Compensation (HLC) Motion detection Privacy mask... -
Page 8: Chapter Iii Installation
CHAPTER III INSTALLATION 3.1 Surface Mounting Step 1: Prepare mounting holes If the minidome camera’s pigtail is dragged out from the top of upper housing, drill mounting holes at the desired position. See the figure below for the size and location of mounting holes. (Unit: mm) Figure 3-1 Step 2: Install upper housing... - Page 9 Figure 3-2 Step 3: Adjust viewing angle Check whether the cables are properly and firmly connected before powering on. The dome camera will perform a self-test for about 30 seconds after power-on. Then loosen the locking screw to adjust the camera angle according to your surveillance need.
- Page 10 Step 5: Install dome bubble Install the bubble flange to upper housing. In this process, the shielding cover may block the camera. Thus, before securing the bubble, user should adjust the shielding cover to a proper position. Then, fasten the screws. With all the procedures finished, user should further confirm whether each part of the device is properly and firmly connected Figure 3-4...
-
Page 11: Wall Mounting (With 86 Box)
3.2 Wall Mounting (with 86 box) Step 1: Install the adapter Fix the adapter to an 86 box with two M3.5 countersunk head screws. Figure 3-6 Step 2: Install upper housing Arrange the cables properly. Loosen the three mum-head screws in bubble flange and take off the bubble. For ease of installation, upper housing and dome bubble are connected with a safety lanyard. - Page 12 Step 3: Adjust viewing angle Check whether the cables are properly and firmly connected before powering on. The dome camera will perform a self-test for about 30 seconds after power-on. Then loosen the locking screw to adjust the camera angle according to your surveillance need.
-
Page 13: Recessed Mounting
3.3 Recessed Mounting Step 1: Drill mounting holes Determine the mounting center and drill an Ø112.0mm circle in the ceiling. Then, draw an Ø120.0mm concentric circle and drill three Ø4.0mm through-holes evenly distributed in this circle. Figure 3-9 Step 2: Install the adapter Place the adapter into the ceiling via Ø112.0mm hole. - Page 14 Step 3: Install camera assembly Connect the cables properly, then put the camera assembly into the ceiling and fix with three M4 screws. Figure 3-11 Step 3: Adjust viewing angle Check whether the cables are properly and firmly connected before powering on.
-
Page 15: Handling Precautions
3. If any abnormality occurs, make sure to unplug the unit and contact Infinova or your local dealer. 4. This camera possesses AGC circuit. Therefore, when the camera is used under lower luminance, the sensibility will strengthen automatically and make the image very rough in vision. -
Page 16: Installation Precautions
real color. It is normal. 6. If the subject is with high luminance (like lamp), vertical stripes will occur on the monitor (tailing shadow) or the surrounding image becomes vague (flowering). It is special phenomenon of CCD, not error. 7. The camera power supply can be 12VDC or 24VAC. 24VAC power supply must be isolated power. -
Page 17: Chapter Iv Operation Instruction
CHAPTER IV OPERATION INSTRUCTION Menu overview Menu setting: This camera uses a 5-direction button to control menu. The button operation is as follows: 1. Press the button to access main menu. -
Page 18: Camera Set
2. Deflect the button up and down to move through the items or select the value of an item. 3. Deflect the button right to access its submenu. 4. In a submenu, select “RETURN” and deflect the button right or left to return to the previous menu. -
Page 19: Phase
By adjusting the vertical phase, the LL mode can reduce monitor sync interruption caused by multiple camera switching. In LL mode, select a suitable PHASE value for video synchronization. Note: LL mode was locked at 24VAC. If DC power supply is introduced, camera will switch to INT mode automatically. -
Page 20: Cam-Lens Set
to a desired position, then deflect the button up and down to select characters. POSI LINE: Set title vertical position, 0~12 adjustable. POSI ROW: Set title horizontal position, 0~16 adjustable. TITLE CLEAR: Clear the camera title. Select “YES” to clear the current title. 4.2 CAM-LENS SET 4.2.1 TYPE DC drive lens is used in this series camera, so this setting should be DC only. -
Page 21: Exposure
4.3 EXPOSURE This setting is mainly for AE, BACK LIGHT, DAY/NIGHT, FLK, ATR. Note: for V5821-A7 series & V5822-A7 series, the default of DAY/NIGHT is different. For V5821-A7 series, default as: DAY; for V5822-A7 series, default as: AUTO…. --AUTO MENU-- SHUT MODE PRI-IRIS SHUT MAX... - Page 22 SHUT MODE: Set shutter mode. Options: PRI-IRIS, PRI-SHUT. It is recommended to select PRI-IRIS when the camera is in Indoor applications and PRI-SHUT for Outdoor applications. If it set to PRI-IRIS, shutter speed will be 1/60s (NTSC) or 1/50s (PAL). At this point, the video brightness is up to iris size.
-
Page 23: Back Light
NTSC: 1/60-CRS, 1/100-FL, 1/250, 1/500, 1/1000, 1/2000, 1/10000, 1/100000. Options: -6dB, 0, 06dB, 12dB, 18dB, 36dB. AGC GAIN: 4.3.2 BACK LIGHT Function: Set backlight compensation. Options: OFF, , BLC. HLC mode can constrain the bright part of video image and highlight the dark part of video image, so that it is easy to view the dark part image. -
Page 24: Day/Night
MODE can be set to BLC-EFLC (default) or AUTO. BLC-EFLC mode is to modulate the peripheral image brightness according to the video brightness of the detected BLC area. If BLC-EFLC is selected, a BLC area will appear in the screen. The BLC area size can be configured by setting the values of TOP, BOTTOM, LEFT and RIGHT. - Page 25 BURST CUT: B/W image without color synchronization burst; ON means B/W image with color synchronization burst. OFF means DAY-NIGHT: Set switchover threshold value from Color to B/W mode. The larger the value is, at a higher light the switching from day to night performs.
-
Page 26: Flk
4.3.4 FLK Function: Set Flickerless Function. When NTSC camera works in 50Hz power environment or PAL camera works in 60Hz power environment, activating the FLK function can prevent video from flicker. Options: ON, OFF. Default as: OFF. 4.3.5 ATR Function: Enable or disable image brightness adjustment. Options: ON, OFF. -
Page 27: Mirror
4.4.1 MIRROR Function: Current image mirror. Options: ON, OFF. Default as: OFF. Enable mirror function to horizontal mirror the image. 4.4.2 BRIGHT Function: Adjust image brightness. Options: 01~32. Default as: 07. The image becomes brighter as the brightness level goes up. 4.4.3 CONTRAST Function: Adjust image contrast. -
Page 28: Hue
4.4.5 HUE Function: Adjust image hue. Options: 01~32. Default as: 17. 4.4.6 C-GAIN Function: Adjust color gain. Options: 01~32. Default as: 17. Image color becomes dense along with the increase of level. 4.4.7 NR Function: Enable or disable noise reduction function. Options: ON, OFF. -
Page 29: White Balance
Options: CRT, LCD. Default as: LCD. Note: This function is unavailable if ATR is set to ON. The camera should connect CRT monitor if it is set to “CRT” and connect LCD monitor if set to “LCD”. When it is set to “LCD”, deflect the button right to enter its submenu. - Page 30 Default as: ATW. ATW: Auto Tracking White Balance mode. The built-in sensor can perceive the current color temperature and use specific arithmetic to process video image, seeking to present an image looking exactly like the real object. The color temperature range is 1800K~10500K. If the color temperature of the monitored object is beyond the range above, go to MANUAL mode, or else there will be a chromatic aberration.
-
Page 31: Assist Function
BLUE: blue gain, available in MANUAL mode only. Options: 01~32. Default as: 07. PUSHLOCK: Similar to ATW, but the processing speed is higher. 4.6 ASSIST FUNCTION This setting is mainly for ALARM, MOTION DETECTION, PRIVACY, LUM NEGATIVE. 4.6.1 ALARM Function: Set alarm output mode. Options: OFF, MD-OUT. -
Page 32: Privacy
--MOTION MENU-- AREA ENABLE LEFT RIGHT BOTTOM SENSE RETURN EXIT AREA: Select motion detection areas, up to 4 areas can be set. ENABLE: Enable or disable motion detection areas display. Options: ON, OFF. If it is set to ON, motion detection areas will display in the menu. The area size and sensitivity can be configured. -
Page 33: Lum Negative
AREA: Select privacy masks, up to 4 masks can be set. ENABLE: Enable or disable privacy masks display. Options: ON, OFF. If it is set to ON, privacy masks will display in the menu. The mask size can be configured. Note: Two coordinates (LEFT, TOP), (RIGHT, BOTTOM) determine a mask. -
Page 34: Blemish
4.7 BLEMISH Function: Configure blemish correction mode. DBC: Dynamic compensation mode. Options: ON, OFF. If it is set to ON, the camera will continuously compensate the blemish. DBC MODE is used to set the sensitivity of dynamic compensation. Options: STANDARD, H-SENSE, L-SENSE. SBC: Static compensation mode. -
Page 35: Appendix I Specifications
APPENDIX I SPECIFICATIONS Model V5821-A7 Series V5822-A7 Series Image Sensor 1/3" SONY Exview HAD II CCD Video Type NTSC/PAL Effective Pixels NTSC: 976 (H) × 494(V), 480K; PAL: 976(H) × 582(V), 570K Scanning System 2:1 interlace Resolution 700TVL Day/Night Electronic Day/Night Functionality Color mode: 0.1 lux @ F1.2 0.1 lux @ F1.2 (30IRE, AGC... - Page 36 Model V5821-A7 Series V5822-A7 Series Backlight HLC/ BLC/ OFF Compensation Flickerless Mode ON/ OFF Privacy Mask 4 programmable masks Motion Detection 4 programmable areas Picture Adjustment Mirror, Bright, Contrast, Sharp, Hue, C-Gain Noise Reduction Alarm Available, MD-OUT/ OFF Sync. System Internal/Line Lock Video Output 1.0 Vp-p (75 Ohm), BNC connector...
-
Page 37: Appendix Ii Cable Diameter Calculation And Lightning & Surge Protection
APPENDIX II CABLE DIAMETER CALCULATION AND LIGHTNING & SURGE PROTECTION Relation between 24VAC Cable Diameter and Transmission Distance In general, the maximum allowable voltage loss rate is 10% for AC-powered devices. The table below shows the relationship between transmission power and maximum transmission distance under a certain specified cable diameter, on condition that the 24VAC voltage loss rate is below 10%. - Page 38 Lightning & Surge Protection The product adopts multi-level anti-lightning and anti-surge technology integrated with gas discharge tube, power resistor and TVS tube. The powerful lightning and surge protection barrier effectively avoids product damage caused by various pulse signals with power below 4kV, including instantaneous lightning, surge and static.
- Page 40 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V1.4 1401...
