Summary of Contents for Advantech CPC-2520
- Page 1 CPC-2520 VGA/LCD module for Mini Biscuit PC User’s Manual...
-
Page 2: Copyright Notice
Acknowledgements AMI is a trademark of American Megatrends, Inc. Cyrix is a trademark of Cyrix Corporation. IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Corporation. -
Page 3: Product Warranty
Product warranty Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for one year from the date of purchase. This warranty does not apply to any products that have been repaired or altered by persons other than repair personnel autho- rized by Advantech, or which have been subject to misuse, abuse, accident or improper installation. -
Page 4: Packing List
If any of these items are missing or damaged, contact your distributor or sales representative immediately. Technical support and sales assistance If you have any technical questions about the CPC-2520 or any other Advantech products, please visit our support website at: http://support.advantech.com.tw... -
Page 5: Table Of Contents
Contents Chapter 1 General Information ......... 1 Introduction ..............2 Specifications ..............3 General ................3 Mechanical and environmental ........3 Board layout: dimensions ..........4 Chapter 2 Installation ..........5 Jumpers and connectors ..........6 Board layout: jumper/connector locations ....7 Safety precautions ............ - Page 6 Chapter 4 PCI SVGA Setup ........21 Introduction ..............22 4.1.1 Chipset ..............22 4.1.2 Display memory ..........22 4.1.3 Display types ............22 Installation of SVGA driver ........23 4.2.1 Installation for Windows 3.1 ......24 4.2.2 Installation for Windows 95 ....... 26 4.2.3 Installation for Windows NT ......
- Page 7 Tables Table 2-1: Jumpers and connectors ............6 Table 2-2: LCD display connector (CN2) ..........11 Table 2-3: VGA display connector (CN3) ..........12 Table 2-4: VGA display connector (CN3) ..........13 Table 3-1: Connections to Sharp LM64183P, LM64P89 ......16 Table 3-2: Connections to PLANAR EL ...........
-
Page 8: Chapter 1 General Information
General Information This chapter provides background information for the CPC-2520. Sections include: • Card specifications • Board layout... -
Page 9: Introduction
1024 x 768 at 64 K colors. CRT and panel displays can be used simultaneously. The CPC-2520 can be set in one of three configurations: on a CRT, on a flat panel display, or on both simultaneously. The system is initially set to simultaneous display mode. -
Page 10: Specifications
Specifications General • Flat panel VGA interface • Chipset: C&T 69000 VGA controller with Windows accelerator • Display memory: 2 MB SDRAM in built-in chip • Display output: 50-pin FPC connector for flat panel interface 12-pin FPC connector for VGA interface •... -
Page 11: Board Layout: Dimensions
Board layout: dimensions CPC-2520 User's Manual... -
Page 12: Chapter 2 Installation
Installation This chapter explains the setup proce- dures of CPC-2520 hardware, including instructions on setting jumpers andcon- necting peripherals, switches andindica- tors. Be sure to read all safety precautions before you begin the installation proce- dure. -
Page 13: Jumpers And Connectors
Table 2-1: Jumpers and connectors Number Function LCD panel type setting Reserved for VGA testing LCD display connector VGA display connector PCI bus CPC-2520 User's Manual... -
Page 14: Board Layout: Jumper/Connector Locations
Board layout: jumper/connector locations Chapter 2 Installation... -
Page 15: Safety Precautions
Use a grounding wrist strap at all times. Place all electronic components on a static-dissipative surface or in a static-shielded bag when they are not in the chassis. CPC-2520 User's Manual... -
Page 16: Jumper Settings
Jumper settings You configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To close a jumper you connect the pins with the clip. -
Page 17: Lcd Panel Select (Sw1)
1024 x 600 TFT (large BIOS only) Display connectors (CN2, CN3) The CPC-2520 PCI SVGA interface can drive conventional CRT display and is capable of driving a wide range of flat display, including electroluminescent (EL), gas plasma, passive LCD, and active LCD displays. -
Page 18: Lcd Display Connector (Cn2)
LCD display connector (CN2) LCD display connector on CPC-2520 is a 50-pin FPC connector. The CPC-2520 supports up to 36 bits LCD panel. Table 2-2: LCD display connector (CN2) Signal Signal ENAVEE ENAVDD SHIFT CLK SHIFT CLK- ENABKL Note: The model number of the CN2 socket is IL-FPR-50S-HF (JAE Co., Ltd.) -
Page 19: Vga Display Connector (Cn3)
VGA display connector (CN3) VGA display connector on CPC-2520 is a 12-pin FPC connector, these VGA signals can be connected to client's system board through a FPC cable. Client can design this cable by referring to Cable layout diagram in chapter of design guide. -
Page 20: Table 2-3: Vga Display Connector (Cn3)
The VGA connector is a 15-pin D-SUB connector. User can follow a transfer table to layout these VGA signals to a standard 15-pin D-SUB connector. Table 2-4: VGA display connector (CN3) Pin Signal Pin Signal Signal Pin Signal 2, 3 +V GREEN 11 GREEN BLUE... -
Page 21: Fpc Cable Installation
FPC cable installation CPC-2520 User's Manual... -
Page 22: Chapter 3 Software Configuration
Software Configuration This chapter details the software configu- ration information. It shows you how to configure the card to match your applica- tion requirements. Sections include: • Introduction • Connections for five standard LCDs... -
Page 23: Introduction
Introduction The CPC-2520 VGA BIOS are located in a 128 Kbyte, 32-pin (JEDEC spec.) Flash ROM device, designated U1. To set different types of LCD panels please choose Panel type from the DIP Switch. Connections for five standard LCDs Connections to Sharp LM64183P, LM64P89... -
Page 24: Table 3-2: Connections To Planar El
Connections to PLANAR EL (640 x 480 AD4 EL) Table 3-2: Connections to PLANAR EL PLANAR 640 x 480 AD4 CPC-2520 CN2 Name Name VCLK SHIFT CLK- /BLANK SELFTST COLMAP ENABLE RESERVED /LOWPOW 31,32 RESERVED Chapter 3 Software Configuration... -
Page 25: Connections To Toshiba Ltm10C042 (640 X 480 Tft Color Lcd)
Connections to Toshiba LTM10C042 (640 x 480 TFT color LCD) Table 3-3: Connections to Toshiba LTM10C042 LTM10C042 CPC-2520 CN2 Name Name SHIFT CLK ENAB External power 31, 32 External power CPC-2520 User's Manual... -
Page 26: Connections To Sharp Lm64C142 (640 X 480 Dstn Color Lcd)
Connections to Sharp LM64C142 (640 x 480 DSTN color LCD) Table 3-4: Connections to Sharp LM64C142 LM64C142 CPC-2520 CN2 Name Name CN1-1 CN1-2 CN1-3 SHIFT CLK CN1-4 DISP External power (+5 V) CN1-5 External power (+5 V) CN1-6 CN1-7 External power... -
Page 27: Connections To Toshiba Ltm12C275A (800 X 600 Tft Color Lcd)
Connections to Toshiba LTM12C275A (800 x 600 TFT color LCD) Table 3-5: Connections to Toshiba LTM12C275A LTM12C275A CPC-2520 CN2 Name Name NCLK SHIFT CLK ENAB External power (+5 V) External power (+5 V) CPC-2520 User's Manual... -
Page 28: Chapter 4 Pci Svga Setup
PCI SVGA Setup • Introduction • Installation of SVGA driver for - Windows 3.1 - Windows 95 - Windows NT • Further information... -
Page 29: Introduction
4.1.3 Display types CRT and panel displays can be used simultaneously. The CPC-2520 can be set in one of three configurations: on a CRT, on a flat panel display, or on both simultaneously. The system is initially set to simultaneous display mode. The utility disks includes three *.COM files in the subdirectory Utility\vga\ which... -
Page 30: Installation Of Svga Driver
Complete the following steps to install the SVGA driver. Follow the procedures in the flow chart that apply to the operating system that you are using within your CPC-2520. Important: The following windows illustrations are examples only. You must follow the flow chart instructions and pay attention to the instructions which then appear on your screen. -
Page 31: Installation For Windows 3.1
Select "File" in D:\VGA\Win31\Setup.exe Program Manager. c. Click "Run" and type: "A:\VGA\ Win31\Setup.exe". a. Choose the language you want to use during installation. a. Select the highlighted item. b. Press "ENTER". a. Press "ENTER" to install all resolutions. CPC-2520 User's Manual... - Page 32 a. Type the path of the operating system. a. When installation is completed, reboot the system. b. You will see the "ChipsCPL" icon in ChipsCPL the control panel. a. Double click "ChipsCPL". b. Adjust screen size, color and refresh rate to your preferences.
-
Page 33: Installation For Windows 95
Press "Advanced Properties". a. Choose the "Adapter" label. b. Press the "Change..." button. a. Press the "Have Disk" button. a. Insert the utility disk into the floppy disk drive. b. Type "A:\VGA\ Win95\Setup\exe". c. Press "OK". D:\VGA\Win95\ CPC-2520 User's Manual... - Page 34 a. Select the highlighted item. 69000 b. Click the "OK" button. a. C&T69000/69030 appears in the adapter label. b. Click the "Apply" button. a. Press "Yes" to reboot. a. Repeat Step 1 on the previous page of this manual. The "CHIPS" label appears in "Display".
- Page 35 Press "OK" to exit. a. Press "Yes" to set the monitor type. a. Select "Standard", "Super VGA 800 x 600", or "XGA". b. Press the "OK" button. a. Choose "Restart" to reboot. E N D CPC-2520 User's Manual...
-
Page 36: Installation For Windows Nt
4.2.3 Installation for Windows NT a. Select "Start", "Settings", "Control Panel". b. Double click the "Display" icon. a. Choose the "Settings" label. b. Press the "Display Type" button. a. Press the "Change..." button. a. Click the "Have Disk..." button. Chapter 4 Award BIOS Setup... - Page 37 Insert the utility disc into the floppy disk drive. b. Type "A:\VGA\NT40\" in the blank. c. Press the "OK" button. D:\VGA\NT40\ a. Select the highlighted item. b. Press the "OK" button. a. Press "Yes" to proceed. a. Press "OK" to reboot. CPC-2520 User's Manual...
- Page 38 a. Repeat Step 1 in this manual, to select the "Settings" label. b. Adjust resolution and color. c. Click "Test" to see the result. d. Click "OK" to save the settings. E N D Chapter 4 Award BIOS Setup...
-
Page 39: Further Information
Further information For further information about PCI/SVGA installation in your CPC-2520, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: C&T website: www.chips.com Advantech websites: www.advantech.com support.advantech.com.tw Confirm Password: CPC-2520 User's Manual... -
Page 40: Chapter 5 Board Diagrams
Board Diagrams This chapter contains diagrams of the CPC-2245/CPC-2520 carrier boards It includes the FPC cable, SODIMM socket, and mechanical diagrams. -
Page 41: Pcb Layout: Sodimm/Screw Hole Locations
PCB layout: SODIMM/screw hole locations CPC-2520 User's Manual... -
Page 42: Board Layout: Connectors (Top View)
Board layout: connectors (top view) Top view Chapter 5 Board Diagrams... -
Page 43: Fpc/Ffc Layout: Cn2: 50-Pin Fpc Connector
FPC/FFC layout: CN2: 50-pin FPC connector FPC/FFC cable layout: CN3: 12-pin FPC connector CPC-2520 User's Manual... -
Page 44: Height Limitations: Side View
Height limitations: side view At least 3 mm clearance is needed between the carrier board's surface and the bottom of the CPC-2245. Some suggested suppli- ers are listed below. Component suppliers Table 5-1: Component suppliers Location Model number Supplier CN2 50-pin FPC connector IL-FPR-50S-HF CN3 12-pin FPC connector IL-FPR-12S-HF... - Page 45 CPC-2520 User's Manual...
