Signal Connections Cont.
2.5
Optional BNC Adaptor Cable
A 5-BNC-to-HD-15 adapter cable is available. The functions of the cables are described
below.
R, B, and G: Red, Green, and Blue input connectors to establish color.
These are used for RS-343 analog signals.
HS/CS: Separate horizontal/composite sync signal from the video
source.
VS: Separate vertical sync signal from the video source.
BNC Adapter Cable
This table describes the signal types you can use with the connectors:
BNC Signal Type
Sync-on-Green
(optional)
Composite Sync
Separate Horizontal
and Vertical Sync.
8.4' DiamondVue User Guide
Description
Use the three video connectors.
Horizontal and vertical syncs
are supplied on the green video
line.
Use the three video connectors
plus the horizontal sync/
composite sync input.
Use the three video connectors
plus the horizontal sync/
composite sync and vertical
sync input.
6
HS/
R
G
B
CS
X
X
X
X
X
X
X
X
X
X
X
VS
X
150.028
