Solutions for Demanding Applications
VarTech Systems Inc.
Industrial CRT and Flat Panel Displays
VT084 DiamondVue Series
8.4" Flat Panel Series LCD Monitors
Model Numbers:
VT084C · VT084P · VT084PSS · VT084W
VT084CXGA · VT084PXGA · VT084WXGA
VT084P3 · VT084RDD
User's Guide
Read these instructions completely before attempting to operate your new Color Display.
8.4' DiamondVue User Guide
150.028
Advertisement
Table of Contents
Troubleshooting
Related Manuals for VarTech Systems DiamondVue VT084C
Summary of Contents for VarTech Systems DiamondVue VT084C
- Page 1 Industrial CRT and Flat Panel Displays VT084 DiamondVue Series 8.4” Flat Panel Series LCD Monitors Model Numbers: VT084C · VT084P · VT084PSS · VT084W VT084CXGA · VT084PXGA · VT084WXGA VT084P3 · VT084RDD User’s Guide Read these instructions completely before attempting to operate your new Color Display.
-
Page 2: Table Of Contents
Section 7 Mounting Instructions Section 3 Chassis Mount Procedure Panel Mount Procedure Getting Started 3.1 Adjusting the Display VT084C Chassis Mount Drawing 3.2 Definition of OSD VT084P Panel Mount Drawing 3.3 Adjustment Procedure 8-10 VT084W Wall Mount Drawing VT084RDD Mechanical Drawing... -
Page 3: Introduction
Section INTRODUCTION INTRODUCTION About LCD Monitors What you gain by using an LCD monitor in your industrial controls LCDs are the future of display technology. Although CRTS have dropped in cost significantly, they do not offer the performance, reliability, and mounting options available with LCDs. -
Page 4: Product Safety Precautions
Product Safety Precautions Ensure that sufficient space is available around the display to provide the ⇒ circulation necessary for cooling. Ensure that the ambient air temperature will not exceed the specified ⇒ maximum temperature. Do not attempt to service this display yourself. The rear chassis has a seal so ⇒... -
Page 5: Display Setup
Section DISPLAY SETUP DISPLAY SETUP VT084 Series Display Features The VT084 is capable of displaying 256K colors in a continuous spectrum. The high contrast ⇒ LCD enhances the image with no geometric distortion. The VT084 Series directly accepts an analog 5 wire RGB with separate H/V. ⇒... -
Page 6: Unpacking The Display
Your LCD monitor package will consist of the components listed below. Open shipping container and lay all components on a flat clean surface. What is included with your display VT084P, VT084C, VT084W LCD Monitor ⇒ 5 ft Video Cable. ⇒... - Page 7 Signal Connections Cont. You can use an HD-15 connector cable or a BNC adapter cable to connect the flat panel monitor to the host computer. The HD-15 video cable (supplied in the kit) you use with this monitor is equipped with a conventional HD-15 connector at each end. Note: The following figure is the view looking into the pin end of the male connector or solder term end of the female connector.
- Page 8 Signal Connections Cont. Optional BNC Adaptor Cable A 5-BNC-to-HD-15 adapter cable is available. The functions of the cables are described below. R, B, and G: Red, Green, and Blue input connectors to establish color. ⇒ These are used for RS-343 analog signals. HS/CS: Separate horizontal/composite sync signal from the video ⇒...
-
Page 9: Getting Started
Fig. 1 from left to right. If you press the “MENU” the new settings are saved and the OSM appear and your setting will be stored in the unit’s non volatile memory. Vartech Systems Menu Select www.vartechsystems.com... -
Page 10: Adjustment Procedure
Adjustment Procedure OSD Display Menu Press Menu and the automatic adjustment will be the first item to appear on the OSD. Hit Select and then press the Up/Down button to navigate to Geometry. Press Select again and the display will automatically adjust the geometry. Automatic Press the Up/Down button to Color Balance. - Page 11 Adjustment Procedure Cont. OSD Display Menu Color temperature adjustments allows the user to adjust for desired white balance. This can be achieved by adjusting the Color Temperature control or adjusting the individual Red, Green or Blue controls. Press Menu. Press the Up button to the eight icon which is Color . Hit Select and then press the Up/Down button to select the Color Temperature.
- Page 12 Adjustment Procedure Cont. OSD Display Menu The advanced control allows for several advanced adjustments. Factory Preset Sharpness Advanced OSD Horz. Pos OSD Vert. Pos The Vartech display has a number of standard settings installed at the factory for your convenience. If you make a number of adjustments and then want to default to the standard settings, proceed as follows.
-
Page 13: Touch Screen
Installation All Vartech Systems displays configured with a touch screen are supplied with a CDROM which includes user manuals, application software, and drivers for various operating systems. Insert the supplied CDROM into a CDROM drive and follow the installation instructions that will appear on the screen. -
Page 14: Troubleshooting Tips
• No S-Video or NTSC Check for proper connections. • operation Check the setup instructions for proper input selection. If these tips do not solve your problem, contact VarTech Systems Customer Service support. 8.4’ DiamondVue User Guide 150.028... -
Page 15: Troubleshooting Tips
Troubleshooting Cont. Trouble Troubleshooting Tip • Screen is blank. Screen saver activated. • Video Cable problem. Check for proper installation • Change video cable • Faulty video display. Needs Service • Image is dim, even with brightness Video cable problem. •... -
Page 16: Cleaning & Maintenance
Section CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE Cleaning Occasionally clean the display panel and cabinet with a soft cloth dampened (not soaked) with a mild (non-abrasive) glass cleaner. Keep turning a fresh side of the cloth toward the screen surface to avoid scratching it with accumulated grit. -
Page 17: Mounting Instructions
ATTENTION: Mounting nuts must be tightened to a torque of 24 inch-pounds to provide panel seal and avoid potential damage. Vartech Systems assumes no responsibility for water or chemical damage to the monitor or other equipment within the enclosure due to improper installation. - Page 18 Active Matrix Color Thin Film Transistor (TFT) Resolution Capabilities Pixel Pitch 0.297mm Active Display Area: 6.7” x 5.1” / 170mm x 130mm VT084C, VT084P, VT084PSS, VT084W 640 x 480 Pixel Format VT084CXGA, VT084PXGA, VT084WXGA 640 x 480, 800 x 600, 1024 x 768 Viewing Angle (Left/Right) 65/65º...
- Page 19 VARTECH SYSTEMS INC. HEADQUARTERS 11529 Sun Belt Ct. Baton Rouge, Louisiana 70809 Toll-Free: 800.223.8050 International Phone: 001.225.298.0300 Fax: 225.297.2440 E-mail: sales@vartechsystems.com 150-028-005 www.vartechsystems.com 9.9.04 8.4’ DiamondVue User Guide 150.028...
