Solutions for Demanding Applications
VarTech Systems Inc.
Industrial CRT and Flat Panel Displays
VT064 Series
6.4" Flat Panel Series LCD Monitors
Model Numbers:
VT064P · VT064P-SS
VT064PHB
User's Guide
Read these instructions completely before attempting to operate your new Color Display.
VT064 DiamondVue User Guide
150-025
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for VarTech Systems VT064P
Summary of Contents for VarTech Systems VT064P
- Page 1 VarTech Systems Inc. Industrial CRT and Flat Panel Displays VT064 Series 6.4” Flat Panel Series LCD Monitors Model Numbers: VT064P · VT064P-SS VT064PHB User’s Guide Read these instructions completely before attempting to operate your new Color Display. VT064 DiamondVue User Guide...
-
Page 2: Table Of Contents
Table Of Contents Page Page Section 1 Section 4 Introduction Touch screen 1.1 About LCD Monitors 4.1 Introduction 1.2 Product Safety Precautions 4.2 Installation Section 2 Section 5 Display Setup Troubleshooting Tips 12-13 Display Features 2.1 Unpacking The Display Section 6 2.2 Included Parts Cleaning &... -
Page 3: Introduction
Section INTRODUCTION INTRODUCTION About LCD Monitors What you gain by using an LCD monitor in your industrial controls LCDs are the future of display technology. Although CRTS have dropped in cost significantly, they do not offer the performance, reliability, and mounting options available with LCDs. -
Page 4: Product Safety Precautions
Product Safety Precautions Ensure that sufficient space is available around the display to provide the circulation ⇒ necessary for cooling. Ensure that the ambient air temperature will not exceed the specified maximum ⇒ temperature. Do not attempt to service this display yourself. The rear chassis has a seal so that non ⇒... -
Page 5: Display Setup
Section DISPLAY SETUP DISPLAY SETUP VT064 Series Display Features The VT064 is capable of displaying 256K colors in a continuous spectrum. The high contrast ⇒ LCD enhances the image with no geometric distortion. The VT064 Series directly accepts an analog 5 wire RGB with separate H/V. ⇒... -
Page 6: Signal Connections
Your LCD monitor package will consist of the components listed below. Open shipping container and lay all components on a flat clean surface. What is included with your display VT064P, or VT064C LCD Monitor ⇒ 5 ft Video Cable. ⇒... - Page 7 Signal Connections Cont. You can use an HD-15 connector cable or a BNC adapter cable to connect the flat panel monitor to the host computer. The HD-15 video cable (supplied in the kit) you use with this monitor is equipped with a conventional HD-15 connector at each end. Note: The following figure is the view looking into the pin end of the male connector or solder term end of the female connector.
-
Page 8: Signal Connections
Signal Connections Cont. Optional BNC Adaptor Cable A 5BNC-to-HD15 adapter cable is available. The functions of the cables are described below. R, B, and G: Red, Green, and Blue input connectors to establish color. ⇒ These are used for RS-343 analog signals. HS/CS: Separate horizontal/composite sync signal from the video ⇒... -
Page 9: Getting Started
Fig. 1 from left to right. If you press the “MENU” the new settings are saved and the OSM appear and your setting will be stored in the unit’s non volatile memory. Vartech Systems Menu Select www.vartechsystems.com... -
Page 10: Adjustment Procedure
Adjustment Procedure Adjustment Procedure Feature Adjustment Instructions Press Menu and the automatic adjustment will be the first item to appear on the OSD. Hit Select and then press the Up/Down button to navigate to Geometry. Automatic Press Select again and the display will automatically adjust the geometry. Adjustment Press the Up/Down button to Color Balance. - Page 11 Adjustment Procedure Cont. Adjustment Procedure Cont. Feature Adjustment Color temperature adjustments allows the user to adjust for desired white balance. This can be achieved by adjusting the Color Temperature control or adjusting the individual Red, Green or Blue controls. Press Menu. Press the Up button to the eight icon which is Color Hit Select and then press the Up/Down button to select the Color Temperature.
-
Page 12: Adjustment Procedure
Adjustment Procedure Cont. Adjustment Procedure Cont. Feature Adjustment Instructions The advanced control allows for several advanced adjustments. Factory Preset ♦ Advanced Sharpness ♦ OSD Horz. Pos ♦ OSD Vert. Pos ♦ The Vartech display has a number of standard settings installed at the factory for your convenience. -
Page 13: Touch Screen
Installation All Vartech Systems displays configured with a touch screen are supplied with a CDROM which includes user manuals, application software, and drivers for various operating systems. Insert the supplied CDROM into a CDROM drive and follow the installation instructions that will appear on the screen. -
Page 14: Troubleshooting Tips
No S-Video or NTSC operation Check for proper connections. ⇒ Check the setup instructions for proper input selection. ⇒ If these tips do not solve your problem, contact Vartech Systems Customer Service support. VT064 DiamondVue User Guide 150-025... -
Page 15: Troubleshooting Tips
Troubleshooting Cont. Trouble Troubleshooting Tip Screen is blank. Screen saver activated. Video Cable problem. Check for proper installation Change video cable . Faulty video display. Needs Service. Image is dim, even with Video cable problem. Check for proper installation of cables brightness and contrast Faulty video source. - Page 16 Section CLEANING AND MAINTANENCE CLEANING AND MAINTANENCE Cleaning Occasionally clean the display panel and cabinet with a soft cloth dampened (not soaked) with a mild (non-abrasive) glass cleaner. Keep turning a fresh side of the cloth toward the screen surface to avoid scratching it with accumulated grit.
-
Page 17: Mechanical Drawings
ATTENTION: Mounting nuts must be tightened to a torque of 24 inch-pounds to provide panel seal and avoid potential damage. Vartech Systems assumes no responsibility for water or chemical damage to the monitor or other equipment within the enclosure due to improper installation. - Page 18 Section SPECIFICATIONS SPECIFICATIONS ENGINEERING SPECIFICATIONS Panel Size 6.4” Type Active Matrix Color Thin Film Transistor (TFT) Resolution Capabilities Pixel Pitch .203 mm Active Display Area 5.14” x 3.82” 211mm x 159mm Pixel Format 640 x 480 Viewing Angle (Left/Right) 55/55 deg. Viewing Angle (Up/Down) 35/35 deg.
- Page 19 VARTECH SYSTEMS INC. HEADQUARTERS 11529 Sun Belt Ct. Baton Rouge, Louisiana 70809 Toll-Free: 800.223.8050 International Phone: 001.225.298.0300 Fax: 225.297.2440 E-mail: sales@vartechsystems.com www.vartechsystems.com 150-025-005 8.23.04 VT064 DiamondVue User Guide 150-025...
