Adjustment Procedure

3.3
OSD Display Menu
Press Menu and the automatic adjustment will be the first item to appear on the OSD.
Hit Select and then press the Up/Down button to navigate to Geometry.
Press Select again and the display will automatically adjust the geometry.
Automatic
Press the Up/Down button to Color Balance.
Adjustment
Hit Select again and the display will automatically preset the color balance to a
factory preset value.
Press Menu. Press the Up button to the second icon which is Horz. Pos
Hit Select and then press the Up/Down button to achieve the desired position.
Horizontal
The desired value will be graphically illustrated along with a digital value.
Position
When complete press Select and you are ready to move to the next adjustment.
Press Menu. Press the Up button to the third icon which is Vertical Position.
Hit Select and then press the Up/Down button to achieve the desired position.
Vertical
The desired value will be graphically illustrated along with a digital value.
Position
When complete press Select and you are ready to move to the next adjustment.
Press Menu. Press the Up button to the fourth icon which is Horizontal Size.
Hit Select and then press the Up/Down button to achieve the desired size.
Horizontal
The desired value will be graphically illustrated along with a digital value.
Size
When complete press Select and you are ready to move to the next adjustment.
Press Menu. Press the Up button to the fifth icon which is Phase.
Hit Select and then press the Up/Down button to achieve the desired phase.
Phase
The phase should be adjusted until the screen image is sharp and there is no
When complete press Select and you are ready to move to the next adjustment.
Press Menu. Press the Up button to the sixth icon which is Brightness.
Hit Select and then press the Up/Down button to achieve the desired brightness
level.
Brightness
The desired value will be graphically illustrated along with a digital value.
When complete press Select and you are ready to move to the next adjustment.
Press Menu. Press the Up button to the seventh icon which is Contrast.
Hit Select and then press the Up/Down button to achieve the desired contrast level.
Contrast
The desired value will be graphically illustrated along with a digital value.
When complete press Select and you are ready to move to the next adjustment.
8.4' DiamondVue User Guide
