Troubleshooting Guide
Ascom i62 VoWiFi Handset
WLAN Connectivity Statistics
WLAN statistics are cumulative from boot or from the last time the statistics were reset. The
statistics return the following information about the number of transmitted and received
RTP packets:.
RX packets
RX bytes
RX dropped
TX packets
TX bytes
TX dropped
Performing a WLAN Test
The following example illustrate how to use the handset web interface to check various
statistics that might give an indication as to why WLAN problems are being experienced:
1 Start the handset web interface as described in steps 1 to 5 in the section
Handset Web Interface
2 Select the Statistics tab, WLAN option. The WLAN Connectivity Statistics pane is
displayed.
Note: The statistics display cumulative totals. To reset the values to zeros, click the
Reset button.
3 Connect a call from one handset to another. One of the handsets must be the handset
with the IP address used to open the handset browser.
4 Complete the call but do not hang up.
5 From the Voice Statistics pane click the Refresh button and make a note of the WLAN
statistics. You may now hang up.
6 Inspect the values of the statistics displayed in respect of the test you are
performing. The following table illustrates some tests and conclusions that you could
make from the values returned:
Test
Voice Packet Loss
5.4.3

Tools Tab

The Tools tab provides the Ping and Traceroute utilities
Ping
Ping is used to test whether or not a host on an IP network can be reached and to measure
the round-trip time for messages sent from the originating host to a destination such as an
IP PBX, Unite server, router or a handset.
To run Ping, select Ping from the Tools pane and enter the IP address of the destination. The
results of the ping is statistical summary of the response packet received and the round-trip
time taken for the packet in the message to be sent and received. For example:
Reply from ::ffff:10.30.32.166: bytes=32 time=28ms TTL=127
The destination IP is pinged ten times.
The following output indicates that the device has not been reached:
28 June 2012 / Ver. A
5. The VoWiFi Handset as
The number of RTP packets received.
The total number of bytes in the received RTP packets
The number of received RTP packets dropped.
The number of RTP packets sent.
The total number of bytes in the sent RTP packets
The number of sent RTP packets dropped.
on page 36.
Description
Verify that the Rx Voice Packet Loss statistic is reasonable, that
is, less than ~5% for a LAN.
TD 92685EN
5.4
38
