The DMI Event Log

Security Settings

007-5536-001
PEF Startup Delay -This sets the pre-determined time to delay PEF after system power-ups and
resets. Refer to Table 24.6 of the IPMI 1.5 Specification for more information at www.intel.com.
The options are No Delay, 30 sec, 60 sec, 1.5 min, 2.0 min.
Event Message for PEF Action - This enables of disables Event Messages for PEF action. Refer
to Table 24.6 of the IPMI 1.5 Specification for more information at www.intel.com. The options
are Disabled and Enabled.
BMC Watch Dog Timer Action
Allows the BMC to reset or power down the system if the operating system hangs or crashes. The
options are Disabled, Reset System, Power Down, Power Cycle.
BMC Watch Dog TimeOut [Min:Sec]
This option appears if BMC Watch Dog Timer Action (above) is enabled. This is a timed delay in
minutes or seconds, before a system power down or reset after an operating system failure is
detected. The options are [5 Min], [1 Min], [30 Sec], and [10 Sec].
View Event Log
Use this option to view the System Event Log.
Mark all events as read
This option marks all events as read. The options are OK and Cancel.
Clear event log
This option clears the Event Log memory of all messages. The options are OK and Cancel.
The AMI BIOS provides a Supervisor and a User password. If you use both passwords, the
Supervisor password must be set first.
Supervisor Password
How To Change the Configuration Data
53
