Connecting Your Components—Continued
Connecting Integra/Onkyo
Step 1: Make sure that each Integra/Onkyo component is connected to the AV receiver with an analog audio cable
(RCA).
Step 2: Make the necessary
Step 3: If you're using an MD, CDR, or RI DOCK component, change the Input Display (see page 52).
With (Remote Interactive), you can use the following special functions:
Auto Power On/Standby
When you start playback on a component connected via
on and select that component as the input source. Similarly, when the AV receiver is set to Standby, all components
connected via will also go on Standby. This function will not work with components that are connected to an AC
OUTLET on the AV receiver.
Direct Change
When playback is started on a component connected via
the input source. If your DVD player is connected to the AV receiver's multichannel input, you'll need to press the
[Audio Selector] button repeatedly and select Multich to hear all channels (see page 85), as the Direct Change
function selects the DVD IN L/R jacks.
Remote Control
You can use the AV receiver's remote controller to control your other
enter the appropriate remote control code first (see page 133). And remember to point the remote controller at the AV
receiver and not the other component.
Notes:
• Use only cables for
are supplied with Integra/Onkyo players (DVD, CD,
etc.).
• Some components have two
nect either one to the AV receiver. The other jack is
for connecting additional
• Connect only Integra/Onkyo components to
jacks. Connecting other manufacturer's components
may cause a malfunction.
• Some components may not support all
Refer to the manuals supplied with your other Inte-
gra/Onkyo components.
• While Zone 2 or Zone 3 is on, the Auto Power
On/Standby and Direct Change
work.

Connecting the Power Cord

• Before connecting the power cord, connect all your speakers and AV components.
• Connect the power cord to the AV receiver's AC INLET.
• Plug the other end of the power cord into a suitable wall outlet.
• Turning on the AV receiver may cause a momentary power surge that might interfere with other electrical equipment
on the same circuit. If this is a problem, plug the AV receiver into a different branch circuit.
Components
connections (see illustration below).
