AV Receiver
DTR-8.2
Instruction Manual
Thank you for purchasing the
Please read this manual thoroughly before making
connections and plugging in the unit. Following the
instructions in this manual will enable you to obtain
optimum performance and listening enjoyment
from your new AV Receiver. Please retain this
manual for future reference.
AV Receiver.
Contents
Before using
Facilities and connections
Setup and operation
Remote controller
Appendix
2
8
29
59
86

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTR-8.2 and is the answer not in the manual?

Questions and answers

Related Manuals for Integra DTR-8.2

Summary of Contents for Integra DTR-8.2

  • Page 1 Contents AV Receiver Before using DTR-8.2 Facilities and connections Instruction Manual Setup and operation Thank you for purchasing the AV Receiver. Please read this manual thoroughly before making Remote controller connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new AV Receiver.

  • Page 2: Before Using Important Safeguards

    WARNING: WARNING AVIS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE DO NOT OPEN NE PAS OUVRIR DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated CAUTION: “dangerous voltage”...

  • Page 3: Precautions

    The fuse is located inside the chassis and is not user-serviceable. If CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH power does not come on, contact your Integra/Onkyo authorized service station. WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. 3. Care Modèle pour les Canadien...

  • Page 4: Table Of Contents

    Contents Before using Setup and operation Important Safeguards ......... 2 Setup menus ............. 29 Navigating through the Setup menu ......30 Precautions ............3 Hardware Setup ..........31 Contents .............. 4 0. Hardware Setup menu ..........31 Features ............... 6 0-1.
  • Page 5 Contents Enjoying music in the remote zone ....56 Getting the Maximum out of it ......72 Playing music using the buttons on the DTR-8.2 ..56 1. Introduction .............. 72 Selecting an input source using the remote controller .. 56 Working with Modes ............

  • Page 6: Features

    Features I 7 Assignable Digital Inputs (4 optical/3 Amplifier Features Coaxial), 2 outputs, and 1 Digital Input I 110 Watts minimum of continuous RMS (optical) power to each of the seven channels into 8 Ω from 20 Hz to 20 kHz with no more than I Pre Out Terminals for Front L/R, Center, 0.08 %THD (FTC rated) Surround L/R, Surround back L/R or Zone 2...

  • Page 7: Before Using This Unit

    Before using this unit Insert batteries Using the remote controller Point the remote controller toward the remote control sensor. The 1. Slide the battery cover off the back of the remote STANDBY indicator lights up when the unit receives a signal from controller.

  • Page 8: Front Panel Facilities

    Front panel facilities Here is an explanation of the controls and displays on the front panel of the DTR-8.2. Front panel Standby/On Master Volume Standby Power O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape...
  • Page 9 Front panel facilities For operational instructions, see page indicated in brackets [ ]. Phones jack [51] This is a standard stereo jack for connecting stereo headphones. Power switch [28] Turns on and off the main power supply for the DTR-8.2. Zone 2 Level / buttons [56] Press to enter the mode for adjusting the volume in the remote zone...
  • Page 10 Front panel facilities Tuning buttons [49] Use these buttons to change the tuner frequency. The tuner frequency is displayed in the front display and it can be changed in 50 kHz increments for FM and 10 kHz increments for AM. When FM is selected, you can hold down one of the tuning buttons and then release it to activate the auto-search feature.

  • Page 11: Remote Controller

    Remote controller For details on how to use the remote controller, refer to “Using the remote controller” (page 59). – Select AV Amp in the Home menu to display the operation buttons. CONT MUTE LIGHT MUTE button Activates the mute function. [51] –...
  • Page 12 Remote controller Third operation menu (page 3/3) Setup button For displaying and quitting the setup menu. [30] (Page 3/3) Return button For entering the selected setting and returning to the previous menu. [30] Test button Outputs a test tone for setting speaker levels. Use this button in conjunction with the +/–and CH Sel buttons to calibrate the speakers levels without entering the Setup menu.
  • Page 13 Remote controller Select Zone 2 in the Home menu to display the Zone 2 operation buttons. [56] – CONT MUTE CH +/– button LIGHT For selecting a tuner preset channel in the remote zone (Zone 2). – buttons For adjusting the volume in the remote zone (Zone 2). ON button For disabling the function of the remote zone (Zone 2).

  • Page 14: Rear Panel Facilities

    Rear panel facilities Here is an explanation of the terminals found on the rear of the DTR- • Insert all plugs and connectors securely. Improper 8.2 and how they are used. Before connecting your audio and video connections can result in noise, poor performance, or components, be sure to read this section carefully and then proceed damage to the equipment.
  • Page 15 Rear panel facilities PRE OUT COMPONENT VIDEO INPUT/OUTPUT These jacks are for connecting auxiliary power amplifier. If your DVD player or other device has component video Using auxiliary power amplifiers allows you to listen at louder connectors, be sure to connect them to these component video volumes than with the DTR-8.2 alone.
  • Page 16 AC OUTLETS (RI) The DTR-8.2 is supplied with AC mains outlets for connecting the terminal on the DTR-8.2 is for connecting other Integra/ power cords from other devices so that their power is supplied Onkyo components equipped with the same terminal.
  • Page 17 Rear panel facilities IR IN/OUT If the DTR-8.2 is located inside a rack or cabinet that will not allow Use this GND terminal for connecting the ground (or earth) wire if a infrared beams to reach the IR sensor, you will need to connect a turntable is connected.

  • Page 18: Connections

    Connections Here is an explanation of how to connect the main components to the Audio connection cable DTR-8.2 in the standard manner. There are many ways that any one component can be connected, and it is up to you to decide which Left (white) method best fits your situation.

  • Page 19: Connecting Your Video Components

    Connections : Signal flow Video connection cable Component video connection cable Audio connection cable Left (white) S video connection cable Right (red) Digital audio input (optical) Digital audio output (coaxial) S Video input Digital audio output (coaxial) Video input R (red) Analog audio output L (white)
  • Page 20 Connections DIGITAL COMPONENT AUDIO VIDEO S VIDEO OUTPUT VIDEO TENNA 7. Settop box, video camera FRONT OUTPUT MONITOR (VIDEO 3) ZONE 2 R (red) S Video input COAX SURR SURR Analog audio BACK/ INPUT 1 Video input ZONE 2 output L (white) VIDEO 1 FRONT...
  • Page 21 Connections 9. TV monitor or projector (MONITOR OUT) Component video input Video input DIGITAL COMPONENT AUDIO VIDEO S VIDEO OUTPUT VIDEO TENNA FRONT OUTPUT MONITOR 8. Satellite tuner or television S Video input (VIDEO 4) ZONE 2 COAX SURR Digital audio output (optical) SURR BACK /...

  • Page 22: Connecting Speakers

    Connecting speakers Before connecting the speakers, place them correctly by consulting Surround back speakers the instruction manuals that came with them. • Place these speakers behind the listener so that the angle For surround playback, the configuration and placement of your between each speaker and the listener is approximately 30 speakers are very important.

  • Page 23: Connecting Speakers

    Connecting speakers Connecting speakers Connecting the speaker cable 1. Strip away 5/8 inch (15 mm) of wire insulation. Caution: Connect only speakers with an impedance between 4 and 16 Ω to 2. Twist wire ends very tight. the DTR-8.2. If the impedance of even one speaker is between 4 and 6 Ω, be sure to set the speaker impedance setting 3.

  • Page 24: Connecting The Remote Zone (Zone 2) Speakers

    Connecting the remote zone (Zone 2) speakers Outline Main Room Remote Zone (Zone 2) The DTR-8.2 allows you to connect another set of speakers and place them in a different room or separated area for listening to PRE OUT Zone 2 Zone 2 music.

  • Page 25: Operating Components Not Reached By The Remote Controller Signals (Ir In/Out)

    Operating components not reached by the remote controller signals (IR IN/OUT) The following equipment (sold separately) is essential for Make connection as shown below. Do not plug the equipment into operation: the power source until the connection is complete. • Onkyo’s Multi-Room System kits (IR Remote Controller from connecting block Extension System), or Mini plug cable...

  • Page 26: Connecting Antennas

    Connecting antennas To use the tuner of DTR-8.2, it is necessary to prepare the supplied Connecting the included antennas FM and AM antennas. Connecting the FM indoor antenna: • Adjustment and placement of the FM and AM antennas for The FM indoor antenna is for indoor use only. During use, extend the better reception must be done while listening to a station antenna and move it in various directions until the clearest signal is broadcast.

  • Page 27: Connecting An Fm Outdoor Antenna

    Connecting antennas Connecting an FM outdoor antenna Directional linkage Please make sure that you follow the considerations: Do not use the same antenna for both FM and TV (or VCR) reception since the FM and TV (or VCR) signals can interfere with •...

  • Page 28: Connecting The Power

    “MD” appear when the Tape source button is pressed. step 2 below). By changing the display, if an Integra/Onkyo MD recorder z- • Before you plug in the DTR-8.2, confirm that all connections connected, the z system functions will become enabled.

  • Page 29: Setup Menus

    Setup menus When making the various settings required to configure your DTR-8.2 optimally, you can either use the OSD menu that appears on your television monitor or you can use the display on the front of the DTR-8.2. The OSD menu is a settings menu that is displayed on your TV monitor.

  • Page 30: Navigating Through The Setup Menu

    Setup menus Advanced Menu 0.Hardware Setup 1.Speaker Setup 1.Speaker Setup 2.Input Setup 3.Audio Adjust 4.Preference 1.Speaker Config 1-1.Speaker Config →Basic Menu 2.Speaker Distance 3.Level Calibration 4.Bass Peak Level a.Subwoofer :Yes |ENTER|Quit:|SETUP| b.Front :Small c.Center :Small d.Surround L/R:Small e.Surround Bk :Small |ENTER|Quit:|SETUP| Quit:|SETUP| f.Powered Zone2...

  • Page 31: Hardware Setup

    Hardware Setup 0. Hardware Setup menu 0-2. IR IN Setup sub-menu Advanced Menu Advanced Menu 0.Hardware Setup 0.Hardware Setup 0-2.IR IN Setup 1.Speaker Impedance 2.IR IN Setup a.Position :Main |ENTER|Quit:|SETUP| Quit:|SETUP| The Hardware Setup menu will need to be set before you use your This sub-menu allows you to set where you will be using the remote DTR-8.2 for the first time.

  • Page 32: Speaker Setup

    Speaker Setup 1. Speaker Setup menu 1-1. Speaker Config sub-menu After you have installed the DTR-8.2, connected all the components, Here you will enter which speakers are connected and the size of and determined the speaker layout, it is now time to perform the each speaker.

  • Page 33: Speaker Distance Sub-Menu

    Speaker Setup Note: a. Unit feet: Select if you will enter the distances in feet. The SURR BACK/ZONE 2 PRE OUT and SURR BACK/ZONE 2 SPEAKER terminals meters: Select if you will enter the distances in meters. In order to have 7.1-channel playback in the main room, you must set b.

  • Page 34: Level Calibration Sub-Menu

    Speaker Setup a. Left 1-3. Level Calibration sub-menu Sound comes from the front left speaker. Adjust the sound level between –12 and 12 decibels in 1-decibel intervals. Here you will set the volume for each speaker so that they are all heard by the listener at the same level.

  • Page 35: Bass Peak Level (Bass Peak Level Manager*) Sub-Menu

    Speaker Setup a. Bass Peak Level Limiter 1-4. Bass Peak Level (Bass Peak Level Manager*) sub-menu On: Select to set the bass peak level. When “On” is selected, the Peak Level setting appears below. Setting the bass peak level is important to keep your subwoofer from Off: Select to turn off the bass peak level limiting function.

  • Page 36: Input Setup

    Input Setup 2. Input Setup menu 2-1. Digital Setup sub-menu This menu allows you to setup the various input sources available The settings made in this sub-menu are valid for the input source that with the DTR-8.2. Each input source may have a great number of is currently selected with the input source buttons at the front panel settings that are difficult to keep track of, so we recommend making and, therefore, these settings are made separately for each digital...

  • Page 37: Multichannel Setup Sub-Menu

    Input Setup a. Digital Input • You may not be able to play some DTS source signals from This setting tells the DTR-8.2 which input source button on the front certain CD players and LD players even if you connect the panel is connected with which digital input jack on the rear panel.

  • Page 38: Video Setup Sub-Menu

    Input Setup b. Component Video 2-3. Video Setup sub-menu If a component is connected to the one of the COMPONENT VIDEO inputs (1 or 2), then that input must be set here. Advanced Menu The default settings are given below. 2.Input Setup Input source selected Component video input...

  • Page 39: Character Input Sub-Menu

    Input Setup Using the cursor buttons, select the desired character and press the 2-4. Character Input sub-menu Enter button. To change a character, move the cursor backward with the Return button or forward with the Enter button to the location of This sub-menu allows you to give names to the stations you have mistaken character and enter the desired character.

  • Page 40: Listening Mode Preset Sub-Menu

    Input Setup * The 5.1-channel digital surround format has a variety of versions 2-6. Listening Mode Preset sub-menu including Dolby Digital and DTS. The 5.1- channel digital surround format enables you to individually record and play five With the DTR-8.2, you can set a different listening mode for each full-range (20 Hz to 20 kHz) channels (left and right front, different signal type that comes from each input source.
  • Page 41 Input Setup Input source signals Listening Modes a. Analog/PCM Mono Analog sources consist of LP records, FM and AM broadcasts, This mode is for playing old movies whose sound is recorded in cassette tapes, and the such. PCM (Pulse Code Modulation) is one monaural or playing left and right channels separately in the movies form of digital audio signals and is recorded directly onto compact which contains the different language signals recorded into...

  • Page 42: Trigger Stetup Sub-Menu

    Input Setup DTS Neo:6 Mono Movie This mode is suitable for playing back monaural recording such as This mode is for 6.1 channel playback of 2 channel sources such as old movie soundtracks. The center channel delivers the unprocessed PCM or analog sources. All 6 channel outputs are wide frequency original sound, whereas the other channels deliver the center- range with a great separation between the different channels.

  • Page 43: Audio Adjust

    Audio Adjust 3-2. Surround Speakers 3. Audio Adjust Setup menu This setting allows you to decide which speakers to output to when Set the various parameters for the sound signals. surround back speakers are connected and you are playing back a 5.1-channel source.
  • Page 44 Audio Adjust 3-4. Delay 3-6. Mono Setup This sub-menu gives you various ways to adjust the timing of the The settings shown below are enabled when the listening mode is set audio output from the speakers to give certain soundfield effects or to “Mono.”...
  • Page 45 Audio Adjust a) Listening angle a) Surr Mode (Analog/PCM) The listening angle is the angle subtended by the front left and right Changes the surround mode for 2-channel analog/PCM input speakers as seen from the listener. The setting of 20 and 40 degrees signals.
  • Page 46 Audio Adjust 3-9. THX Setup Note: Select this Setup THX listening modes; the one that is currently set is THX Surround EX (Dolby D) will not appear if the Powered Zone 2 the one that is modified. The parameters that can be set are shown in setting of the Speaker Config sub-menu is set to “Activated.”...

  • Page 47: Preference

    Preference 4. Preference menu 4-1. Volume Setup sub-menu This sub-menu allows you to make various settings concerning the Advanced Menu volume control of the DTR-8.2. 4.Preference Advanced Menu 1.Volume Setup 4.Preference 2.Headphones Level 3.OSD Setup 4-1.Volume Setup 4.OSD Position a.Volume Display |ENTER|Quit:|SETUP| :Absolute b.Muting Level...

  • Page 48: Headphones Level Setup Sub-Menu

    Preference Hint: 4-2. Headphones Level Setup sub-menu If this is set to “Off,” the background color will not be displayed even when there is no video signal input. You can use this sub-menu to adjust the volume output from the headphones so that it matches the level output from the speakers.

  • Page 49: Listening To Radio Broadcasts

    Listening to Radio Broadcasts FM AM Standby/On Master Volume Standby Power O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape Phono Selector Pure Audio psampling Display Video /Video Cam Input Phones Zone Level...

  • Page 50: Presetting A Radio Station

    Listening to Radio Broadcasts – CONT FM AM MUTE LIGHT CH + / – – Standby/On Master Volume Standby Power O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape Phono Selector Display Pure Audio...

  • Page 51: Enjoying Music Or Videos With The Dtr-8.2

    Enjoying music or videos with the DTR-8.2 Input source buttons Master Volume – CONT MUTE MUTE LIGHT – Standby/On Master Volume Standby Input Power Selector O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape Phono...

  • Page 52: Changing The Listening Mode

    Enjoying music or videos with the DTR-8.2 Listening mode buttons Input source buttons – CONT MUTE LIGHT – Listening Standby/On Master Volume Standby mode Power buttons O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape...

  • Page 53: Switching The Display

    Enjoying music or videos with the DTR-8.2 Input source buttons – CONT MUTE LIGHT – Standby/On Master Volume Standby + / – Power O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape Phono Selector...

  • Page 54: Changing The Audio Mode

    Enjoying music or videos with the DTR-8.2 Master Volume Input source buttons – Direct/Pure Audio CONT MUTE LIGHT – Standby/On Master Volume Standby Power O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape Phono...

  • Page 55: Entering Names For Input Sources And Tuner Stations

    Enjoying music or videos with the DTR-8.2 Standby/On Master Volume Standby Power O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape Phono Selector Display Pure Audio psampling Video /Video Cam Input Phones Zone Level...

  • Page 56: Enjoying Music In The Remote Zone

    Enjoying music in the remote zone – ZONE 2 indicator CONT MUTE LIGHT CH + / – – Standby/On Master Volume Standby Power Input O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape Phono...

  • Page 57: Recording A Source

    Recording a source Input source buttons Standby/On Master Volume Standby Power O f f Direct/ Zone Pure Audio Audio Video 1 Video 2 Video 3 Video 4 Video 5 Tape Phono Selector Display Pure Audio psampling Video /Video Cam Input Phones Zone Level...

  • Page 58: Recording The Video From One Source And The Audio From Another

    Recording a source Recording the video from one source and the audio from another You can add the sound from one source to the video of another source to make your own video recordings. Below is an example of recording the sound from a compact disc player connected to CD IN and the video from a video camera connected to VIDEO 5 IN to video cassette tape in a video cassette recorder connected to the VIDEO 1 OUT jack.

  • Page 59: Remote Controller

    Fresh out of the box, the remote controller is already set up to work battery compartment. with popular components made by Integra/Onkyo. Programming the remote controller is easy: Add components to the Device menu as necessary. Then, program the commands to the remote controller for the components.

  • Page 60: Quick Reference

    Quick reference 8. Mode menu Customize the remote controller (see below). – CONT MUTE LIGHT – 9. Device menu Open a component’s control panels. 1. Sending eye (IR transmitter)/Learning eye Send commands to devices. 10. Scroll button For learning commands from other remote controllers. Display previous control panel.

  • Page 61: Introduction

    Introduction Sending eye/Learning eye Direct-access buttons Serial port Contrast dial Touchscreen Left/Right buttons Backlight button Reset button 1. Intelligent Remote Controller The intelligent remote controller can be used for all devices that understand infrared remote controller signals. Its easy-to-use touchscreen and its intuitive interface makes it a perfect remote controller for every user.

  • Page 62: Left And Right Buttons

    Introduction 1. Home: to go to the Home menu Left and Right buttons 2. Macro menu: to open stored list of commands The Left and Right buttons change function depending on the device the remote controller is controlling. Labels displayed above them on the touchscreen show their current function.

  • Page 63: Charging The Remote Controller

    Introduction 2. Charging the Remote Controller Optional recharging dock AA batteries 1. Slide the battery cover off the back of the remote Warning: controller. Use the recharging dock only with the NiMH rechargeable battery pack of BCC-5. 1. Slide the battery cover off the back of the remote controller.
  • Page 64 Introduction 4. Slide the battery cover back on. After a few seconds, the remote controller starts up automatically and beeps twice to indicate that it has finished starting up. 5. Plug the power adapter into a wallet outlet and connect it to the recharging dock. 6.

  • Page 65: Getting Started

    You can use the preset RC codes The remote controller has different “modes.” When you activate the only when the Integra/Onkyo’s device you selected and Integra/ remote controller for the first time, it starts up in Use mode allowing Onkyo’s amplifier or receiver are connected using...

  • Page 66: Define The Brand Of Your Device

    Getting Started Defining brands by selecting 2. Select “Yes” to define the brand of the device to operate. A list of brands and their corresponding RC codes are pre-installed The remote controller switches to Brand mode. Follow the in the remote controller’s memory. instructions as described below.
  • Page 67 Getting Started To enter a space, tap the lower left corner of the keyboard. When Notes: the keyboard is zoomed in, tap the empty key. • The code sets are ranked. The first code set in the list is used After you have typed the character, the keyboard is zoomed out.

  • Page 68: Defining Brands By Searching

    Getting Started Defining brands by searching 6. Tap OK when the device reacts. You can use Search mode to find the matching RC codes for your Notes: device when • Even when the device is responding to the current code set, it is •...

  • Page 69: Select A Device

    These buttons are preprogrammed to work with popular devices made by Integra/Onkyo. If you have devices of The Device menu pops up. You can scroll through this menu other manufacturers that do not respond to your remote controller,...

  • Page 70: Operate A Device

    Getting Started 4. Operate a Device Using the Left and Right button You operate devices using three kinds of buttons: The Left and Right buttons change function depending on the device the remote controller is operating. The current function is displayed I Touchscreen buttons on the touchscreen right above the button.
  • Page 71 Getting Started First setup panel Setting Function Adjusting Battery Shows the battery level. Clock Turns the clock display on or off and lets Tap the clock repeatedly. you set 12 or 24h time display. Time Sets the clock. Tap the time button and use the Left and Right button.

  • Page 72: Getting The Maximum Out Of It

    2. Programming Buttons The remote controller is preprogrammed to work with all equipment You can program the remote controller commands by transmitting that recognizes NEC infrared codes. This includes all Integra/Onkyo infrared signals from your existing remote controls to the remote devices.

  • Page 73: Programming Control Panel Buttons

    Getting the Maximum out of it Programming control panel buttons Programming direct-access and Left/Right Buttons 1. Navigate to the control panel buttons you want to program. Direct-access and Left/Right buttons can be programmed with a global function or with functions per device. Buttons with global 2.

  • Page 74: Labeling Buttons And Menu Items

    Getting the Maximum out of it Note: 3. Labeling Buttons and Menu Items You can zoom out again without tapping a character by pressing the Right button (labeled Zoom). The following elements can be labeled: control panel buttons, Device menu items, macros, macro groups and Left/Right buttons. •...

  • Page 75: Adding And Moving Devices

    Getting the Maximum out of it 4. Adding and Moving Devices Moving menu items You can change the order of Device menu items and Macro menu Adding devices items. Changes you make in the Device menu are automatically updated in the Home menu. If you have a device that is not provided in the Device menu, you can 1.

  • Page 76: Delete And Restore

    Getting the Maximum out of it 5. Delete and restore Restore After you deleted a control panel button or a menu item, the button or Delete item is no longer visible in Use mode but remains in the remote controller’s memory. This allows you to restore it in Edit mode. You can delete control panel buttons and functions associated with a Actions associated with direct-access or a Left/Right buttons cannot direct-access or a Left/Right button.

  • Page 77: Recording Macros And Setting Timers

    Getting the Maximum out of it 6. Recording Macros and Setting Timers Editing macros A macro enables you to send a sequence of IR commands using one You can edit any macro you have recorded. single button. 1. Open the macro group that contains the macro. By setting a time, you can activate a device at the time you prefer.

  • Page 78: Setting Timers

    Getting the Maximum out of it Setting timers Editing timers To activate a device at the time you set. You can edit any timer you have set. 1. Tap the Macro menu button. 1. Open the timer group that contains the timer. 2.

  • Page 79: Using The Remote Controller With Radio Frequency

    Getting the Maximum out of it 7. Using the remote controller with Radio Changing the remote controller’s RF IR Settings Frequency All devices are set up by default to work with IR signals. To be able to operate one or more devices with RF signals, you have to change Warning: the remote controller’s RF IR settings for those devices.

  • Page 80: Choosing Another Channel

    Getting the Maximum out of it Choosing Another Channel Changing the Extender ID 1. Make sure the Extender ID button is active. When you notice RF interference, for instance from your neighbors, The button is active when the button label is white. you have to choose another channel to operate your devices.

  • Page 81: Chadedit

    Getting the Maximum out of it 8. ChadEdit System requirements If you want to personalize your remote controller even more, beyond I PC its standard programming features, ChadEdit is the tool for you to I Windows 95/98/Me, Windows NT 4.0/2000, Windows XP use.

  • Page 82: Troubleshooting

    • Use ChadEdit to update the Remote controller’s software Remote controller error messages (ChadEdit > Tools > Update) • If one of the following error messages occurs, please contact your dealer or the Integra/Onkyo customer service: • Can not open configuration file Programming Problems • Configuration file error •...

  • Page 83: Faq

    Can I program a button to execute more than one How do I revert to the original configuration? command? Reverting to the original configuration restores the remote No, you can not. However, you can create a macro to execute a controller’s devices and commands to its state when you purchased it.

  • Page 84: Overview Of Symbols

    Overview of Symbols :Pause :Page number up :Stop :Page number down :Normal run; normal speed :Page enlargement :Normal run; normal speed :TV and text mixed :Fast run; fast speed :1st or 2nd language :Fast run; fast speed :Last view; previous program :Slow run;...

  • Page 85: Specifications

    Specifications Hardware High-resolution (320 x 240) liquid crystal display (LCD) with contrast control Large touchscreen Seven programmable direct-access buttons Backlighting for LCD and direct-access buttons Infrared sending and learning eyes 3-wire (RS232) serial port connector Software Dynamic, animated interface Editable macros (up to 255 commands per macro) Total number of devices and macros limited only by memory Database with RC codes to operate different brands Infrared (IR)

  • Page 86: Troubleshooting Guide

    © Turn the power button off and then on again or remove the power cord from the outlet and then plug it in again. • Internal fuse is blown. FM/AM TUNER © Contact your Integra/Onkyo Service Center. Power turns on but no sound. AM stations cannot be received. • “Muting” is displayed.

  • Page 87: Video And Audio

    Troubleshooting guide VIDEO and AUDIO If one of the messages shown below appears “Not available with headphones use” Desired picture does not appear. The operation is not allowed because headphones are plugged into • Improper connection. the DTR-8.2. © Check the connection again. Insert the plugs and connectors completely.

  • Page 88: Specifications

    Phono: 80 dB (IHF A, 5 mV input) CD/Tape: 110 dB (IHF A, 0.5 V input) Integra Division of ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www. integrahometheater.com Integra Division of ONKYO CORPORATION Sales &...
