Summary of Contents for Integra DTR-8.9

  • Page 1 AV Receiver DTR-8.9 DTR-9.9 Instruction Manual...

  • Page 2: Important Safety Instructions

    Thank you for purchasing an Integra AV Receiver. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new AV Receiver. Please retain this manual for future reference.

  • Page 3: Zone 2 And Zone

    Precautions For U.S. models 1. Recording Copyright—Unless it’s for personal use only, recording copyrighted material is illegal with- FCC Information for User out the permission of the copyright holder. CAUTION: 2. AC Fuse—The AC fuse inside the unit is not user- The user changes or modifications not expressly serviceable.

  • Page 4: Supplied Accessories

    Supplied Accessories Make sure you have the following accessories: Remote controller and three batteries (AA/R6) Speaker setup microphone Indoor FM antenna AM loop antenna Power cord (Power cord varies from country to country.) Speaker Cable Speaker cable labels In catalogs and on packaging, the letter at the end of the product name indicates the color.

  • Page 5: Table Of Contents

    Using Macros ............152 Basic Operations ..........66 Others Selecting the Input Source .........66 Setting the Display Brightness ........67 Troubleshooting ..........153 Adjusting Speaker Levels .......... 67 Specifications (DTR-8.9) ........159 Muting the AV Receiver ..........67 Specifications (DTR-9.9) ........160...

  • Page 6: Features

    Features ® Amplifier • Audyssey MultEQ to Correct Room Acoustic Problems • 140 watts minimum continuous power per channel, ™*12 • Audyssey Dynamic EQ Loudness Correction 8 ohm loads, 2 channels driven from 20 Hz to 20 kHz, ™*12 • Audyssey Dynamic Volume with a maximum total harmonic distortion of 0.05% (FTC) •...
  • Page 7 Features—Continued HDMI, the HDMI logo and High Definition Multimedia Inter- face are trademarks or registered trademarks of HDMI Licens- ing, LLC. *8 In Europe, using banana plugs to connect speakers to an audio amplifier is prohibited. ©2005 SIRIUS Satellite Radio Inc. “SIRIUS”, SiriusConnect, the SIRIUS dog logo, channel names and logos are trademarks of SIRIUS Satellite Radio Inc.

  • Page 8: Multiroom Capability

    Multiroom Capability You can use three speaker systems with this AV receiver—a surround-sound speaker system (up to 7.1 channels) in your main listening room, a stereo speaker system in a second room, or Zone 2, as we call it, and another stereo speaker system in a third room that we call Zone 3.

  • Page 9: Front & Rear Panels

    Front & Rear Panels Front Panel North American model bm bn bo bq br bs cnco *1 DTR-9.9 only Other models The actual front panel has various logos printed on it. They are not shown here for clarity. The page numbers in parentheses show where you can find the main explanation for each item. On/Standby button (47) Zone 2 indicator (144) Sets the AV receiver to On or Standby.
  • Page 10 Front & Rear Panels—Continued Stereo button (92) USB port (DTR-9.9 only) Selects the Stereo listening mode. A USB mass storage device, such as a USB flash drive or MP3 player, containing music files (MP3, Listening Mode [ ]/[ ] buttons (92) WMA, WAV, AAC) can be plugged in here and the Select the Onkyo original listening modes.

  • Page 11: Display

    Front & Rear Panels—Continued Display For detailed information, see the pages in parentheses. TUNED (69): Lights up when tuned to a radio sta- Speaker/channel indicators (99) tion. Indicate the speaker configuration and channels used by the current input source. FM STEREO (69): Lights up when tuned to a ste- : A box is displayed for each speaker that’s set reo FM station.

  • Page 12: Rear Panel

    Front & Rear Panels—Continued Rear Panel North American model bl bo ck cl co cp ct dk dm dn Other models...
  • Page 13 See “Component Video Setup” ETHERNET port on page 54. DTR-8.9: COMPONENT VIDEO MONITOR OUT This port is for connecting the AV receiver to home automation equipment and external controllers. Use This RCA component video output is for connect- only shielded Ethernet cables.
  • Page 14 Front & Rear Panels—Continued GND screw PRE OUT: FRONT L/R, CENTER, This screw is for connecting a turntable’s ground SUBWOOFER, SURR L/R, and SURR BACK wire. This 5.1/7.1 multichannel analog audio output can CD IN be connected to the analog audio input on a multi- This analog audio input is for connecting a CD channel power amplifier for when you want to use player’s analog audio output.

  • Page 15: Remote Controller

    Remote Controller Installing the Batteries Aiming the Remote Controller When using the remote controller, point it toward the AV To open the battery compartment, press receiver’s remote control sensor, as shown below. the small hollow and slide open the cover. Remote control sensor Standby indicator AV receiver...

  • Page 16: About The Remote Controller Modes

    Tuner ■ CD/CDR/MD Mode TV VOL Phono Net/USB D.TUN By default, you can control an Integra/Onkyo CD player Clear --/--- in this mode. By entering the appropriate remote control Input Selector Macro code, you can control a CD player, MD recorder, or CD Zone 3 recorder made by another manufacturer (see page 148).
  • Page 17 Remote Controller—Continued For detailed information, see the pages in parentheses. Audio Sel button (130) Selects the audio input: analog, digital, HDMI, or Standby button (47) multichannel. Sets the AV receiver to Standby. ■ TAPE mode On button (47) On twin cassette decks, only Deck B can be controlled. Turns on the AV receiver.

  • Page 18: Dvd Mode

    Remote Controller—Continued Standby button DVD Mode Sets the DVD player to Standby. To set the remote controller to DVD mode, press the On button [DVD] Remote Mode button. Turns on the DVD player. Number buttons Used to enter title, chapter, and track numbers, and to enter times for locating specific points.

  • Page 19: Cd/Cdr/Md Modes

    Remote Controller—Continued Standby button CD/CDR/MD Modes Sets the component to Standby. To control an Integra/Onkyo CD player, MD On button recorder, or CD recorder, or a CD or MD Set the component to On or Standby. player/recorder made by another manufacturer,...

  • Page 20: Dock Mode

    Turns on the iPod. To control an RI Dock, press the [CD] (DTR-9.9) or Top Menu button [Dock] (DTR-8.9) Remote Mode button to select the Works as a Mode button when used with a DS-A2 Dock remote controller mode. RI Dock.

  • Page 21: Net/Usb Mode (Dtr-9.9 Only)

    Remote Controller—Continued Number buttons Net/USB Mode (DTR-9.9 only) Used to enter track numbers. Net/USB mode is for playing music files on a networked Arrow [ ]/[ ]/[ ]/[ ] and Enter buttons computer, media server, or USB mass storage device, or Used to navigate menus and select items.

  • Page 22: About Home Theater

    About Home Theater Enjoying Home Theater Thanks to the AV receiver’s superb capabilities, you can enjoy surround sound with a real sense of movement in your own home—just like being in a movie theater or concert hall. With DVDs you can enjoy DTS and Dolby Digital. With analog or digital TV, you can enjoy Dolby Pro Logic IIx, DTS Neo:6, or Onkyo’s original DSP listening modes.

  • Page 23: Connecting The Av Receiver

    Connecting the AV Receiver Connecting Your Speakers Connecting a Powered Subwoofer Using a suitable cable, connect the AV receiver’s PRE Speaker Configuration OUT: SUBWOOFER to the input on your powered sub- For 7.1-channel surround-sound playback, you need woofer. If your subwoofer is unpowered and you’re seven speakers and a powered subwoofer.

  • Page 24: Speaker Connection Precautions

    Connecting the AV Receiver—Continued Speaker Connection Precautions Connecting the Speaker Cables Read the following before connecting your speakers: • You can connect speakers with an impedance of Strip about 5/8" 5/8" (15 mm) (15 mm) of insulation between 4 and 16 ohms. If the impedance of any of the connected speakers is 4 ohms or more but less than 6, from the ends of the speaker cables, and...

  • Page 25: Bi-Amping Front Speakers

    Connecting the AV Receiver—Continued Bi-amping Speaker Hookup Bi-amping Front Speakers The FRONT L/R and SURR BACK L/R terminal posts Connect the AV receiver’s FRONT R positive (+) can be used with front speakers and surround back terminal to the right speaker’s positive (+) woofer speakers respectively, or bi-amped to provide separate (low) terminal.

  • Page 26: Bridging Front Speakers

    Connecting the AV Receiver—Continued Bridged Speaker Hookup Bridging Front Speakers The FRONT L/R and SURR BACK L/R terminal posts Connect the AV receiver’s FRONT R positive (+) can be used with front speakers and surround back terminal to the right speaker’s positive (+) ter- speakers respectively, or bridged together to provide minal.

  • Page 27: Connecting Antenna

    Connecting the AV Receiver—Continued Connecting Antenna Use thumbtacks or something similar to fix the FM antenna into position. This section explains how to connect the supplied indoor FM antenna and AM loop antenna, and how to connect commercially available outdoor FM and AM antennas. The AV receiver won’t pick up any radio signals without any antenna connected, so you must connect the antenna Thumbtacks, etc.
  • Page 28 Connecting the AV Receiver—Continued cumstances demand it, use a TV/FM antenna splitter, as ■ Other Models shown. Push Insert wire Release TV/FM antenna splitter To AV receiver To TV (or VCR) Connecting an Outdoor AM Antenna If good reception cannot be achieved using the supplied Once your AV receiver is ready for use, you’ll AM loop antenna, an outdoor AM antenna can be used need to tune into an AM radio station and adjust...

  • Page 29: About Av Connections

    Connecting the AV Receiver—Continued AV Connection Color Coding About AV Connections RCA-type AV connections are usually color coded: red, • Before making any AV connections, read the manuals white, and yellow. Use red plugs to connect right- supplied with your other AV components. channel audio inputs and outputs (typically labeled “R”).

  • Page 30: Connecting Both Audio & Video

    Connecting the AV Receiver—Continued Connecting Both Audio & Video By connecting both the audio and video outputs of your DVD player and other AV components to the AV receiver, you can switch the audio and video signals simultaneously simply by changing the input source on the AV receiver. : Signal Flow Video Video...
  • Page 31 Connecting the AV Receiver—Continued ■ “Monitor Out” Setting Set to “Analog” Video Signal Flow Chart With the “Monitor Out” setting set to “Analog” DVD player, etc. (see page 48), video input signals flow through the AV receiver as shown, with composite video and S-Video sources being upconverted for the component video output.

  • Page 32: Connecting A Tv Or Projector

    Connecting the AV Receiver—Continued Connecting a TV or Projector See “Connecting Components with HDMI” on page 38 for HDMI connection information. Step 1: Video Connection Choose a video connection that matches your TV ( , , or ), and then make the connection. Step 2: Audio Connection Choose an audio connection that matches your TV ( , , or...

  • Page 33: Connecting A Dvd Player

    Connecting the AV Receiver—Continued Connecting a DVD player Step 1: Video Connection Choose a video connection that matches your DVD player ( , , or , and then make the connection. If you use connection , you must connect the AV receiver to your TV with the same type of connection. Step 2: Audio Connection Choose an audio connection that matches your DVD player ( , , or...
  • Page 34 Connecting the AV Receiver—Continued Hooking Up the Multichannel Input If your DVD player supports multichannel audio formats such as DVD-Audio and SACD, and it has a multichannel analog audio output, you can connect it to the AV receiver’s multichannel input. Use a multichannel analog audio cable, or several normal audio cables, to connect the AV receiver’s MULTI CH: FRONT L/R, CENTER, SURR L/R, SURR BACK L/R, and SUBWOOFER jacks to the 7.1-channel analog audio output on your DVD player.

  • Page 35: Connecting A Vcr Or Dvd Recorder For Playback

    Connecting the AV Receiver—Continued Connecting a VCR or DVD Recorder for Playback With this hookup, you can use the tuner in your VCR or DVR to listen to your favorite TV programs Hint! via the AV receiver, which is useful if your TV has no audio outputs. Step 1: Video Connection Choose a video connection that matches your VCR or DVD recorder ( , , or...

  • Page 36: Connecting A Vcr Or Dvd Recorder For Recording

    Connecting the AV Receiver—Continued Connecting a VCR or DVD Recorder for Recording Step 1: Video Connection Choose a video connection that matches your VCR or DVD recorder ( ), and then make the connection. The video source to be recorded must be connected to the AV receiver via the same type of connection. Step 2: Audio Connection Choose an audio connection that matches your VCR or DVD recorder ( ), and then make the connection.

  • Page 37: Connecting A Satellite, Cable, Terrestrial Set-Top Box, Or Other Video Source

    Connecting the AV Receiver—Continued Connecting a Satellite, Cable, Terrestrial Set-top box, or Other Video Source With this hookup, you can use your satellite or cable receiver to listen to your favorite TV programs Hint! via the AV receiver, which is useful if your TV has no audio outputs. Step 1: Video Connection Choose a video connection that matches the video source ( , , or...

  • Page 38: Connecting Components With Hdmi

    Connecting the AV Receiver—Continued Connecting Components with HDMI About HDMI Designed to meet the increased demands of digital TV, HDMI (High Definition Multimedia Interface) is a new digital interface standard for connecting TVs, projectors, DVD players, set-top boxes, and other video components. Until now, several separate video and audio cables have been required to connect AV components.

  • Page 39: Audio Signals

    Connecting the AV Receiver—Continued Making HDMI Connections Step 1: Use HDMI cables to connect the AV receiver’s HDMI jacks to your HDMI-compatible Blu-ray player/DVD player, TV, projector, and so on. Step 2: Assign each HDMI IN to an input selector. See “Video Input Setup” on page 52. ■...

  • Page 40: Connecting A Game Console

    Connecting the AV Receiver—Continued Connecting a Game Console Step 1: Video Connection Choose a video connection that matches your game console ( , , or , and then make the connection. If you use connection , you must connect the AV receiver to your TV with the same type of connection. Step 2: Audio Connection Choose an audio connection that matches your DVD player ( , , or...

  • Page 41: Connecting A Camcorder Or Other Device

    Connecting the AV Receiver—Continued Connecting a Camcorder or Other Device Step 1: Video Connection Choose a video connection that matches your camcorder ( ), and then make the connection. Step 2: Audio Connection Choose an audio connection that matches your camcorder ( ), and then make the connection.

  • Page 42: Connecting A Cd Player Or Turntable

    Connecting the AV Receiver—Continued Connecting a CD Player or Turntable ■ CD Player or Turntable (MM) with Built-in Phono Preamp Step 1: Choose a connection that matches your CD player ( , , or ). Use connection for a turntable with a built-in phono preamp.

  • Page 43: Connecting A Cassette, Cdr, Minidisc, Or Dat Recorder

    Connecting the AV Receiver—Continued Connecting a Cassette, CDR, MiniDisc, or DAT Recorder Step 1: Choose a connection that matches your recorder ( , , or ), and then make the connection. COAXIAL IN 2 (VCR/DVR) TAPE OPTICAL IN 2 (CD) OPTICAL TAPE Connect one or the other...

  • Page 44: Connecting A Power Amplifier

    Connecting the AV Receiver—Continued Connecting a Power Amplifier If you want to use a more powerful power amplifier and use the AV receiver solely as a preamp, connect the amp to the PRE OUT jacks, and connect all speakers and the subwoofer to the power amplifier. If you have a powered subwoofer, connect it to the AV receiver’s PRE OUT: SUBWOOFER jack.

  • Page 45: Connecting An Ri Dock

    • Set the AV receiver’s Input Display to “DOCK” (see page 59). • By using the [CD] (DTR-9.9) or [Dock] (DTR-8.9) Remote Mode button on the remote controller of the AV receiver to change the remote mode to “DOCK”, you can operate your iPod in the RI Dock (see page 20).

  • Page 46: Connecting Integra/Onkyo Components

    Connecting the AV Receiver—Continued Connecting Integra/Onkyo Components Step 1: Make sure that each Integra/Onkyo component is connected to the AV receiver with an analog audio cable (RCA). Step 2: Make the necessary connections (see illustration below). Step 3: If you’re using an MD, CDR, or RI DOCK component, change the Input Display (see page 59).

  • Page 47: Turning On The Av Receiver

    Setup” on page 54, or “Digital Audio Input Setup” on page 55 OPTICAL respectively. ■ Did you connect an Integra/Onkyo MD recorder, CD recorder, or RI Dock? If you did, see “Changing the Input Display” on page 59. MD recorder, CD recorder,...

  • Page 48: First Time Setup

    First Time Setup This section explains the settings that you need to make before using the AV receiver for the very first time. Monitor Setup Press the [HDMI Out] button. The current setting is displayed. On the “Monitor Out” settings, you can select whether or not to have the video sources’...

  • Page 49: Selecting The Language Used For The Onscreen Setup Menus

    First Time Setup—Continued In this Instruction Manual, illustrations from the onscreen menu or explanations referring to the menu will be in the same language as the Instruction Manual. The default Language setting for the onscreen menu is English. If your Instruction Manual is in a language other than English, first follow the instructions below to change the Language.

  • Page 50: Using The Onscreen Setup Menus

    First Time Setup—Continued ■ Menus for First Time Setup Input Selector Macro Zone 3 Remote Mode Submenus Zone 2 CDR/MD/Dock Cable Net/USB Receiver p. 51 1. Input/Output Assign Tape/AMP 1. Monitor Out Dimmer Sleep 2. HDMI Input 3. Component Video Input p.

  • Page 51: Monitor Out Setup

    First Time Setup—Continued Monitor Out Setup Use the Up and Down [ ]/[ ] but- tons to select “1. Input/Output Assign”, and then press [Enter]. The “Input/Output Assign” menu Enter appears. Standby Input 1. Input/Output Assign 1. Monitor Out TV CH AUX 1 AUX 2 Game...

  • Page 52: Video Input Setup

    First Time Setup—Continued Notes: Use the Up and Down [ ]/[ ] but- • If the video source contains information that restricts tons to select “Resolution”, and output at high-resolutions, 720p or 1080i content will use the Left and Right [ ]/[ ] not be converted.
  • Page 53 First Time Setup—Continued page 51), and the “HDMI Input” setting must be set to Use the Up and Down [ ]/[ ] but- “- - -”. See page 30 for more information on video sig- tons to select “2. HDMI Input”, nal flow and upconversion.

  • Page 54: Component Video Setup

    First Time Setup—Continued Component Video Setup Use the Up and Down [ ]/[ ] but- tons to select “3. Component If you connect a video component to a COMPONENT Video Input”, and then press VIDEO IN, you must assign that input to an input [Enter].

  • Page 55: Digital Audio Input Setup

    First Time Setup—Continued Digital Audio Input Setup Use the Up and Down [ ]/[ ] but- tons to select an input selector, If you connect a component to a digital audio input, you and then use the Left and Right must assign that input to an input selector.

  • Page 56: Analog Audio Input Setup

    First Time Setup—Continued Analog Audio Input Setup Use the Up and Down [ ]/[ ] but- tons to select “5. Analog Audio Input”, and then press [Enter]. The “Analog Audio Input” menu Enter appears. Standby Input 1–5. Analog Audio Input TV CH Game AUX 1...

  • Page 57: Speaker Settings

    First Time Setup—Continued Speaker Settings Use the Up and Down [ ]/[ ] but- tons to select “1. Speaker Set- tings”, and then press [Enter]. Tape Tuner If you change these settings, you must run the auto- The “Speaker Settings” menu appears. TV VOL D.TUN matic speaker setup again (see page 60).

  • Page 58: Tv Format Setup (Not North American Models)

    First Time Setup—Continued TV Format Setup Use the Up and Down [ ]/[ ] but- (not North American models) tons to select “TV Format”, and then use the Left and Right For the onscreen setup menus to display properly, you [ ]/[ ] buttons to select: Enter must specify the TV system used in your area.

  • Page 59: Am Frequency Step Setup (On Some Models)

    First Time Setup—Continued AM Frequency Step Setup Press the [Setup] button. (on some models) Setup closes. For AM tuning to work properly, you must specify the AM frequency step used in your area. Note that when this setting is changed, all radio presets are deleted. Note: Press the [Receiver] button, fol- This procedure can also be performed on the AV receiver...

  • Page 60: Automatic Speaker Setup (Audyssey Multeq ® Xt)

    First Time Setup—Continued Measurement Positions Automatic Speaker Setup ® To create a listening environment in your home theater (Audyssey MultEQ ® that all listeners will enjoy, Audysssey MultEQ takes measurements at up to eight positions within the lis- With the supplied calibrated microphone, Audyssey tening area.
  • Page 61 First Time Setup—Continued ® Using Audyssey MultEQ The onscreen menus shown in this manual may be slightly different from what you see on your TV. Turn on the AV receiver and the connected TV. On the TV, select the input to which the AV receiver is connected.
  • Page 62 First Time Setup—Continued Press [Enter]. The following screen appears. The automatic speaker setup starts. Auto Speaker Setup Enter Auto Speaker Setup Next Do not unplug Setup Mic. Please keep quiet. Now measuring. . . Please place microphone at next position at ear height. ENTER ENTER Test tones are played through each...
  • Page 63 First Time Setup—Continued Disconnect the setup Mic. When the measurements are complete, the following screen appears. Auto Speaker Setup Auto Speaker Setup Please, unplug Setup Mic. Calculating... Notes: • When the automatic speaker setup is complete, the When the calculations are com- “Equalizer Settings”...

  • Page 64: Error Messages

    First Time Setup—Continued Error Messages Auto Speaker Setup While the automatic speaker setup is in progress, one of Next the following error messages may appear: Cancel ❑ Ambient noise is too high :Yes :--- :Error Auto Speaker Setup Speaker Detect Error MOVE ENTER ENTER...
  • Page 65 First Time Setup—Continued Reviewing the Results Changing the Speaker Settings Manually In rare situations, proper measurements taken may not be obtainable by the by the automatic speaker setup. For Use the Up and Down [ ]/[ ] but- example, there may be too much noise in the room. If tons to select the settings that running the speaker setup a second time is still unsuc- Enter...

  • Page 66: Basic Operations

    Basic Operations Selecting the Input Source Standby Input TV CH AUX z AUX 2 Game Tape Tuner TV VOL Phono Net/USB D.TUN Clear --/--- 10 Input Selector Macro Zone 3 Remote Mode Zone 2 CDR/MD/Dock Cable Net/USB Receiver Tape/AMP Dimmer Sleep Enter Disc...

  • Page 67: Setting The Display Brightness

    Basic Operations—Continued This section explains functions that can be used with any Adjusting Speaker Levels input source. You can adjust the volume of each speaker while listen- Tape Tuner ing to an input source. These temporary adjustments are TV VOL D.TUN Phono Net/USB...

  • Page 68: Using The Sleep Timer

    Basic Operations—Continued Using the Sleep Timer Adjusting the Bass & Treble With the sleep timer, you can set the AV receiver to turn You can adjust the bass and treble for the front speakers, except when the Direct or THX listening mode is off automatically after a specified period.

  • Page 69: Listening To The Radio

    Listening to the Radio Listening to AM/FM Stations TUNED AUTO Tuning Mode Tuning FM STEREO ■ Manual Tuning Mode Press the [Tuning Mode] button so that the AUTO indicator disap- pears from the display. Tuner With the built-in tuner, you can enjoy AM and FM radio stations and store your favorite stations as presets for Press and hold the Tuning Up or easy selection.
  • Page 70 Listening to the Radio—Continued ■ Tuning into Stations by Frequency Displaying AM/FM Radio Information You can tune into AM and FM stations directly by enter- ing the appropriate frequency. Display Standby Input Number buttons AUX 1 AUX 2 TV CH Game Tape Tuner...

  • Page 71: Presetting Am, Fm, Xm, And Sirius Stations

    Listening to the Radio—Continued Selecting Presets Presetting AM, FM, XM, and SIRIUS Stations Preset Standby 2, 4 Input TV CH Game AUX 1 AUX 2 Tape Tuner TV VOL Phono Net/USB D.TUN Clear --/--- 10 Input Selector Macro Zone 3 Remote Mode Zone 2 CDR/MD/Dock...

  • Page 72: Listening To Hd Radio™ Stations (North American Model Only)

    Listening to the Radio—Continued AUX 1 AUX 2 TV CH Game Listening to HD Radio™ Stations Tape Tuner (North American model only) TV VOL D.TUN Phono Net/USB Clear HD Radio technology brings digital radio to conven- --/--- 10 Input Selector Macro tional analog AM and FM radio stations, with improved Zone 3...
  • Page 73 Listening to the Radio—Continued Selecting Multicast Channels Note: Multicast channels 2 through 8 only carry a digital sig- FM HD Radio stations can transmit multiple programs nal, so to select an audio format, you must select multi- on the same frequency by using what are called multicast cast channel #1 first.

  • Page 74: Using Rds

    Listening to the Radio—Continued RDS Program Types (PTY) Using RDS Type Display RDS only works in areas where RDS broadcasts are available. When tuned to an RDS station, the RDS indi- None NONE cator appears. News reports NEWS Current affairs AFFAIRS RDS indicator Information...
  • Page 75 Listening to the Radio—Continued Displaying Radio Text (RT) Use the Preset [ ]/[ ] buttons to select the type of program you RT/PTY/TP want. See the table on page 74. To start the search, press [Enter]. The AV receiver searches until it finds a station of the type you specified, at which point it stops briefly before con- tinuing with the search.

  • Page 76: Listening To Xm Satellite Radio (North American Model Only)

    Listening to the Radio—Continued Activate your XM Satellite Radio service in the U.S. ® Listening to XM Satellite Radio online at http://activate.xmradio.com or call 1-800- (North American Model Only) XMRADIO (1-800-967- 2346). Activate your XM Sat- ellite Radio service in Canada online at https://acti- About XM Radio vate.xmradio.ca or call 1-877-GET-XMSR (1-877-438- 9677).
  • Page 77 Listening to the Radio—Continued --/--- Input Selector Use the Left and Right [ ]/[ ] Macro Zone 3 buttons to select “XM”. Remote Mode Zone 2 If there are 2 items on the Tuner CDR/MD/Dock Receiver Cable Net/USB Receiver Enter screen, use Up and Down [ ]/[ ] Tape/AMP Dimmer...
  • Page 78 Listening to the Radio—Continued Signing Up for XM Satellite Radio Selecting XM Radio Channels Once you have installed the XM Mini-Tuner and Home There are three ways to select XM radio channels: Dock, you are ready to subscribe to XM Satellite Radio. 1.
  • Page 79 Listening to the Radio—Continued ■ Category Search Mode Selecting Channels on the AV receiver: Press the [Receiver] Remote Press the [Tuning Mode] button Mode button, and then press the Remote repeatedly to select Channel [Enter] button repeatedly to controller AV receiver Search mode or Category Search select Category Search mode.
  • Page 80 Listening to the Radio—Continued Displaying XM Radio Information --/--- 10 Input Selector Macro Zone 3 Remote Mode Zone 2 Press the [Display] button AV receiver CDR/MD/Dock Receiver Cable Net/USB Receiver repeatedly to cycle through the Tape/AMP Dimmer Sleep available information. Enter Enter Disc...
  • Page 81 Listening to the Radio—Continued ❑ UPDATING XM is updating your Mini-Tuner with the latest Use the Up and Down [ ]/[ ] but- encryption code. Wait a few seconds until the update tons to select “5. Satellite is done. Alternatively, you may be attempting to tune Radio”, and then press [Enter].

  • Page 82: Listening To Sirius Satellite Radio (North American Models Only)

    Listening to the Radio—Continued Setting Up the SiriusConnect™ Home ® Listening to SIRIUS Satellite Radio Tuner (North American Models Only) The optional SiriusConnect Home tuner kit includes everything for easy home installation, including the Sir- Important SIRIUS Satellite Radio Information iusConnect receiver, indoor/outdoor antenna with 21- SIRIUS is available in the US for subscribers with foot cable, 8-pin mini DIN connector cable, and an AC...
  • Page 83 Listening to the Radio—Continued Positioning the Antenna Use the Up and Down [ ]/[ ] but- For a consistent satellite signal, the antenna must be posi- tons to select “7. Hardware tioned correctly. Use the following map to determine which Setup”, and then press [Enter].
  • Page 84 Listening to the Radio—Continued Selecting SIRIUS Satellite Radio Channels Tuning There are three ways to select SIRIUS Satellite Radio channels: 1. Channel Search mode: select any channel. 2. Category Search mode: select channels by category. 3. Direct tuning: enter channel number. Standby Input Tuner...
  • Page 85 Listening to the Radio—Continued ■ Category Search Mode Selecting Channels on the AV receiver: Press the [Receiver] Remote Press the [Tuning Mode] button Mode button, and then press the repeatedly to select Channel Remote AV receiver [Enter] button repeatedly to Search mode or Category Search controller select Category Search mode.

  • Page 86: Parental Lock

    Listening to the Radio—Continued TV VOL Phono Net/USB D.TUN Use the Up and Down [ ]/[ ] but- Clear --/--- 10 tons to select “6. SIRIUS Parental Input Selector Macro Zone 3 Lock”, and then press [Enter]. Remote Mode The “SIRIUS Parental Lock” screen Zone 2 Enter CDR/MD/Dock...
  • Page 87 Listening to the Radio—Continued Use the Up and Down [ ]/[ ] but- Use the Up and Down [ ]/[ ] but- tons to select a channel, and use tons to select “6. SIRIUS Parental Lock”, and then press [Enter]. the Left and Right [ ]/[ ] but- tons to select Locked or The “SIRIUS Parental Lock”...
  • Page 88 Listening to the Radio—Continued Input Selector Macro Zone 3 Press the [D.TUN] button, and Remote Mode then use the number buttons to Zone 2 CDR/MD/Dock D.TUN enter the new 4-digit PIN number. Receiver Cable Net/USB Receiver Clear Tape/AMP Dimmer Sleep Enter Enter Disc...
  • Page 89 Listening to the Radio—Continued Clear Use the Up and Down [ ]/[ ] but- --/--- 10 Input Selector Macro tons to select “5. Satellite Zone 3 Radio”, and then press [Enter]. Remote Mode Zone 2 CDR/MD/Dock The Satellite Radio screen appears. Enter Receiver Cable...
  • Page 90 Listening to the Radio—Continued SIRIUS Satellite Radio Messages The following messages may appear while using SIRIUS Satellite Radio. ❑ ACQUIRING The SiriusConnect receiver is acquiring the signal or no signal is present. Make sure the SiriusConnect Home tuner is connected properly and that there are no obstacles close by.

  • Page 91: Recording

    Recording This section explains how to record the input source and Recording from Different AV Sources how to record audio and video from separate sources. You can overdub audio onto your video recordings by Notes: simultaneously recording audio and video from two sep- •...

  • Page 92: Using The Listening Modes

    Using the Listening Modes Selecting with the Remote Controller Selecting the Listening Modes For a description of each listening mode, see “About the Listening Modes” on page 99. Enter Disc Album • The Dolby Digital and DTS listening modes Prev can only be selected if your DVD player is Display Muting...

  • Page 93: Listening Modes Available For Each Source Format

    Using the Listening Modes—Continued Listening Modes Available for Each Source Format Analog and PCM Sources ✔: Available Listening Modes Analog/PCM Multichannel PCM Multi 32–96 kHz 176.4/192 kHz 32–96 176.4/ Source format channel Multi Mono/Mul Multi Mono/Mul Analog 192kHz channel tiplex channel tiplex Media...
  • Page 94 Using the Listening Modes—Continued Dolby Digital, and Dolby Digital Plus Sources ✔: Available Listening Modes Dolby Digital Dolby Digital Plus Source format Multichannel Mono/Multiplex Multichannel Mono/Multiplex Media DVD, DTV, etc. Blu-ray, HD DVD Listening Mode ✔ ✔ ✔ ✔ ✔ ✔...
  • Page 95 Using the Listening Modes—Continued DTS Sources ✔: Available Listening Modes DTS, DTS96/24 DTS-ES Source format Discrete/Matrix Multichannel Mono Media DVD, CD, etc. DVD, CD, etc. Listening Mode ✔ ✔ ✔ ✔ Direct ✔ ✔ ✔ ✔ Stereo ✔ ✔ ✔ ✔...
  • Page 96 Using the Listening Modes—Continued TrueHD Sources ✔: Available Listening Modes TrueHD TrueHD 192kHz Source format Multichannel Mono/Multiplex Multichannel Mono/Multiplex Media Blu-ray, HD DVD Blu-ray, HD DVD Listening Mode ✔ ✔ ✔ ✔ ✔ Direct ✔ ✔ ✔ ✔ ✔ Stereo ✔...
  • Page 97 Using the Listening Modes—Continued DTS-HD Sources ✔: Available Listening Modes DTS-HD High Resolution DTS-HD Master Audio DTS-HD Master Audio 192kHz Source format Multi Multi Multi Mono Mono Mono channel channel channel Media Blu-ray, HD DVD Blu-ray, HD DVD Blu-ray, HD DVD Listening Mode ✔...
  • Page 98 Using the Listening Modes—Continued DTS Express and DSD Sources ✔: Available Listening Modes DTS Express Source format Multichannel Multichannel Mono (3/2.1) Media Blu-ray, HD DVD SACD Listening Mode ✔ ✔ ✔ ✔ ✔ Direct ✔ ✔ ✔ ✔ ✔ Stereo ✔...

  • Page 99: About The Listening Modes

    Using the Listening Modes—Continued Dolby Pro Logic IIx About the Listening Modes Dolby Pro Logic II The AV receiver’s listening modes can transform your Dolby Pro Logic IIx expands any 2-channel source for listening room into a movie theater or concert hall, with 7.1-channel playback.
  • Page 100 Using the Listening Modes—Continued Dolby TrueHD DTS Neo:6 Designed to take full advantage of the additional storage This mode expands any 2-channel source for up to 7.1- space offered by the new Blu-ray and HD DVD disc for- channel playback. It uses seven full-bandwidth channels mats, this new Dolby format offers up to 7.1 discrete of matrix decoding for matrix-encoded material, provid- channels of digital audio with 48/96 kHz, up to 5.1-chan-...
  • Page 101 Using the Listening Modes—Continued Neural THX 5.1/7.1 • THX Games Neural-THX Surround employs psychoacoustic fre- THX Games mode is meant for spatially accurate quency domain processing, which allows delivery of a playback of game audio, which is often mixed simi- more detailed sound stage, with superior channel separa- larly to movies but in a smaller environment.
  • Page 102 Using the Listening Modes—Continued Onkyo Original DSP Modes Mono Movie This mode is suitable for old movies and other mono sources. The center speaker outputs the sound as it is, while reverb is applied to the sound output by the other speakers, giving presence to even mono material.

  • Page 103: Advanced Setup

    Advanced Setup The onscreen setup menus appear on the connected TV and provide a convenient way MENU to change the AV receiver’s various settings. Settings are organized into eight catego- 1. Input/Output Assign ries on the main menu, most containing a submenu. 2.

  • Page 104: Monitor Out Setup

    Advanced Setup—Continued Monitor Out Setup Use the Up and Down [ ]/[ ] but- tons to select an item, and then This section explains items on the “Input/Output press [Enter]. Assign” menu. The screen for that item appears. Enter Standby Enter Input AUX 1...
  • Page 105 Advanced Setup—Continued Monitor Out R Brightness With this setting you can adjust the picture red bright- Resolution ness. You can specify the output resolution for the HDMI out- Can be adjusted from –50 to +50 in steps of 1 (default is puts and have the AV receiver upconvert the picture res- olution as necessary to match the resolution supported “–50”...

  • Page 106: Speaker Setup

    Advanced Setup—Continued Speaker Setup Press the [Receiver] Remote Mode button, followed by the This section explains items on the “Speaker Setup” Receiver [Setup] button. menu. The main menu appears onscreen. Some of the speaker settings are set automatically by the If the main menu doesn’t appear, make Automatic Speaker Setup function (see page 60).
  • Page 107 Advanced Setup—Continued Use the Up and Down [ ]/[ ] but- Use the Up and Down [ ]/[ ] but- tons to select “Subwoofer”, and tons to select “SurrBack”, and then use the Left and Right then use the Left and Right [ ]/[ ] buttons to select: [ ]/[ ] buttons to select a cross- Enter...
  • Page 108 Advanced Setup—Continued Low-Pass Filter for the LFE Channel Double Bass This setting is not set automatically by the Automatic This setting is not set automatically by the Automatic Speaker Setup function (see page 60). Speaker Setup function (see page 60). With this setting, you can specify the cutoff frequency of With this setting, you can boost bass output by feeding the LFE channel’s low-pass filter (LPF), which can be...

  • Page 109: Speaker Distance

    Advanced Setup—Continued Speaker Distance Use the Up and Down [ ]/[ ] but- tons to select “3. Speaker Dis- These settings are set automatically by the Automatic tance”, and then press [Enter]. Speaker Setup function (see page 60). The “Speaker Distance” screen Enter appears.
  • Page 110 Advanced Setup—Continued Speaker Level Calibration Use the Up and Down [ ]/[ ] but- tons to select a speaker, and use the Left and Right [ ]/[ ] but- These settings are set automatically by the Automatic tons to specify the distance. Speaker Setup function (see page 60).
  • Page 111 Advanced Setup—Continued Use the Up and Down [ ]/[ ] but- Repeat step 4 until the volume of tons to select “2. Speaker the test tone from each speaker Setup”, and then press [Enter]. is the same. The “Speaker Setup” menu appears. If you’re using a handheld sound level Enter meter, adjust the level of each speaker...

  • Page 112: Equalizer Settings

    Advanced Setup—Continued Equalizer Settings 2–5. Equalizer Settings 630Hz 1000Hz These settings are set automatically by the Automatic 1600Hz 2500Hz Speaker Setup function (see page 60). 4000Hz 6300Hz 10000Hz With the Equalizer settings, you can adjust the tone of 16000Hz speakers individually with a 7-band equalizer. The vol- ume of each speaker can be set on page 110.
  • Page 113 Advanced Setup—Continued ■ MultEQ XT Use the Up and Down [ ]/[ ] but- Audyssey MultEQ XT correction is active (see page 60). tons to select a frequency, and then use the Left and Right ■ Dynamic EQ [ ]/[ ] buttons to adjust the “Audyssey MultEQ XT”...

  • Page 114: Thx Audio Setup

    Advanced Setup—Continued THX Audio Setup Use the Up and Down [ ]/[ ] but- tons to select “SurrBack Sp Spacing”, and use the Left and These settings are not set automatically by the Auto- Right [ ]/[ ] buttons to specify matic Speaker Setup function (see page 60).

  • Page 115: Audio Adjust

    Advanced Setup—Continued Use the Up and Down [ ]/[ ] but- Audio Adjust tons to select “Loudness Plus”, Here you can set listening mode-related settings and and use the Left and Right Enter functions. [ ]/[ ] buttons to select: Off: Select this to turn off Loud- Press the [Receiver] Remote ness Plus.
  • Page 116 Advanced Setup—Continued Multiplex/Mono Settings When you’ve finished, press the [Setup] button. Multiplex The setup menu closes. ■ Input Ch(Mux) This setting determines which channel of a stereo multi- plex source is output. Use it to select audio channels or languages with multiplex sources, multilingual TV Note: broadcasts, and so on.

  • Page 117: Dolby Digital

    Advanced Setup—Continued ■ Dimension Theater-Dimensional (T–D) Setting With this setting, you can move the sound field forward ■ Listening Angle or backward when using the Dolby Pro Logic IIx Music listening mode. It can be adjusted from –3 to +3. The With this setting, you can optimize the Theater-Dimen- default value is 0.

  • Page 118: Using The Music Optimizer

    Advanced Setup—Continued Optimizer The Music Optimizer function enhances the sound qual- ity of compressed music files. Use it with music files that Standby use “lossy” compression, such as MP3. Input Off: Music Optimizer off (default). TV CH AUX 1 AUX 2 On: Music Optimizer on.

  • Page 119: Using The Late Night Function

    Advanced Setup—Continued Using the Late Night Function Source Setup With the Late Night function, you can reduce the This section explains items on the “Source Setup” menu. dynamic range of Dolby Digital material so that you can Items can be set individually for each input selector. still hear quiet parts even when listening at low volume levels—ideal for watching movies late at night when you Press the [Receiver] Remote...

  • Page 120: Name Edit

    Advanced Setup—Continued Name Edit Use the Up and Down [ ]/[ ] but- You can enter a custom name for each individual input tons to select an option, and use selector and radio preset for easy identification. When the Left and Right [ ]/[ ] but- entered, the custom name will appear on the display.
  • Page 121 Advanced Setup—Continued Picture Adjust Zoom: The new “4-4. Picture Adjust” item has been added to the “1. Input/Output Assign” menu. This menu and its settings can be accessed just like the other menus. The settings are explained below. ■ Game Mode If video signal delay occurs during play on a video com- ponent, such as a Game console, connected to the AV receiver, select “Game Mode”...
  • Page 122 Advanced Setup—Continued Resolution Picture Mode You can specify the output resolution for the HDMI out- DVD-Video disc content originates from either film puts and have the AV receiver upconvert the picture res- (recorded at 24 frames per second) or video intended for olution as necessary to match the resolution supported TV (recorded at 30 frames per second).
  • Page 123 Advanced Setup—Continued R Brightness: With this setting you can adjust the picture red bright- ness. Can be adjusted from –50 to +50 in steps of 1 (default is “–50” is the darkest. “+50” is the brightest. R Contrast: With this setting you can adjust red Contrast. Can be adjusted from –50 to +50 in steps of 1 (default is “–50”...

  • Page 124: Listening Mode Presets

    Advanced Setup—Continued Listening Mode Presets Use the Up and Down [ ]/[ ] but- tons to select an audio format, On the “Listening Mode Preset” menu, you can specify and use the Left and Right a default listening mode for each of the audio formats [ ]/[ ] buttons to select a listen- Enter supported by each input selector.

  • Page 125: Miscellaneous Setup

    Advanced Setup—Continued Miscellaneous Setup Use the Up and Down [ ]/[ ] but- tons to select an item, and use This section explains items on the “Miscellaneous” the Left and Right [ ]/[ ] but- menu. tons to change it. Enter Clear The items are explained below.

  • Page 126: Display Position

    Advanced Setup—Continued ■ Power On Volume OSD Setup This setting determines what the volume will be each ■ Immediate Display time the AV receiver is turned on. This setting determines whether operation details are When the “Volume Display” preference is set to “Abso- displayed onscreen immediately after an AV receiver lute”, the range is “Last”, “Min”, 1 to “Max”.

  • Page 127: Hardware Setup

    Setup Prev Display Muting ■ Remote ID When several Integra/Onkyo components are used in the Playlist Random same room, their remote ID codes may overlap. To dif- ferentiate the AV receiver from the other components, you can change its remote ID from 1, the default, to 2 or...
  • Page 128 Advanced Setup—Continued ■ Lip Sync Tuner The Lip Sync function can automatically synchronize ■ AM Freq Step (on some models) HDMI audio and video that’s gotten out of sync due to the complex digital video processing being performed by See “AM Frequency Step Setup (on some models)” on your HDMI-compatible TV.

  • Page 129: Lock Setup

    When linking to a TV that conforms to the CEC standard, the “Monitor Out” setting must be set to “HDMI Main”. Network DTR-8.9: These settings are for use with home automation equip- ment and external controllers. DTR-9.9: See “Network Settings” on page 138.

  • Page 130: Selecting Audio Inputs

    Advanced Setup—Continued Selecting Audio Inputs Specifying the Digital Signal Format Playlist Random Listening Mode Surround Stereo Repeat Audio Subtitle Play Mode Direct All ST Test Tone CH Sel Level- Level+ Open/Close Video Off Audio Sel Audio Sel L Night Re-EQ RC- 688 M Normally, the AV receiver detects the format of digital If you connect a component to more than one audio...

  • Page 131: Net/Usb (Dtr-9.9 Only)

    Net/USB (DTR-9.9 only) Supported Audio File Formats About Net/USB For server and USB mass storage device playback, the The AV receiver is network-ready, which means you can AV receiver supports the following music file formats: hook it up to your home network with a standard Ether- MP3, WMA, WAV, and AAC.
  • Page 132 Net/USB (DTR-9.9 only)—Continued USB Mass Storage Device Requirements Network Requirements • The AV receiver supports USB devices that support ■ Ethernet Network the USB mass storage device class. The AV receiver’s Ethernet port supports 10Base-T. For • Playback may not be possible with some USB devices best results, a 100Base-TX switched Ethernet network is even if they conform to the USB mass storage device recommended.

  • Page 133: Connecting The Av Receiver

    Net/USB (DTR-9.9 only)—Continued Connecting the AV Receiver Playing Music Files on a Server To connect the AV receiver to your home network, plug This section explains how to play music files on a com- one end of a shielded CAT5 Ethernet cable into the AV puter or media server through the AV receiver.

  • Page 134: Windows Media Player 11 Setup

    Net/USB (DTR-9.9 only)—Continued Windows Media Player 11 Setup Use the Up and Down [ ]/[ ] but- tons to select a music file, and press This section explains how to configure Windows Media the [Enter] or Play [ ] button to Player 11 so that the AV receiver can play the music files start playback.

  • Page 135: Playing Music Files On A Usb Device

    Net/USB (DTR-9.9 only)—Continued Playing Music Files on a USB Device Use the Up and Down [ ]/[ ] but- tons to select a USB mass stor- This section explains how to play music files on a USB age device, and then press mass storage device.
  • Page 136 Net/USB (DTR-9.9 only)—Continued Random Playback To play songs in random order, while the list of songs is displayed, press the [Random] button. All of the songs in the current folder will be played in random order. When all of the songs in the folder have been played once, they’ll all be played again in a different random order.

  • Page 137: Listening To Internet Radio

    Net/USB (DTR-9.9 only)—Continued Listening to Internet Radio Press the [Net/USB] Remote Mode button to select the To receive Internet radio, you must connect the AV Net/USB Net/USB remote controller mode. receiver to a network with Internet access (see page 133). You can select Internet radio stations by entering the appropriate URL with the remote controller, or by con- Use the Up and Down [ ]/[ ] but-...

  • Page 138: Network Settings

    Net/USB (DTR-9.9 only)—Continued Once you’ve added a station to the list, simply select it Network Settings on the Internet Radio screen, and then press [Enter] to start playback. Note: When modifying network settings, after modifying it is Notes: necessary to execute Save Settings.
  • Page 139 Net/USB (DTR-9.9 only)—Continued Control Use the Up and Down [ ]/[ ] but- This setting enables or disables control over the network. tons to select “6. Network”, and then press [Enter]. Enable: Control over the network enabled. The “Network” screen appears. Disable: Control over the network disabled.

  • Page 140: Zone 2 And Zone 3

    Zone 2 and Zone 3 In addition to your main listening room, you can also enjoy playback in two other rooms, or as we call them, Zone 2 and Zone 3. And, you can select a different source for each room. Connecting Your Zone 2 Speakers to an Connecting Zone 2 Amp in Zone 2...

  • Page 141: Connecting Zone 3

    Zone 2 and Zone 3—Continued Zone 2 Video Output Connecting Zone 3 The AV receiver features a composite video output for Zone 3 speakers must be connected to an amp in Zone 3. connection to a TV in Zone 2, so you can enjoy both audio and video in that zone.

  • Page 142: Powered Zone2 Setting

    Zone 2 and Zone 3—Continued Powered Zone2 Setting Use the Up and Down [ ]/[ ] but- tons to select “2. Zone2/Zone3”, If you’ve connected your Zone 2 speakers to the AV and then press [Enter]. receiver, as explained in “Connecting Your Zone 2 The “Zone2/Zone3”...

  • Page 143: Zone 2/Zone 3 Out Settings

    Zone 2 and Zone 3—Continued Zone 2/Zone 3 Out Settings Press the [Setup] button. Setup closes. If you’ve connected your Zone 2 or Zone 3 speakers to an amp with no volume control, set the “Zone2 Out” or “Zone3 Out” setting, respectively, to “Variable” so that you can set the zone’s volume, balance, and tone on the AV receiver.
  • Page 144 Zone 2 and Zone 3—Continued Selecting an Input Source for Zones Turning Off Zones On the remote controller, press On the remote controller, press the [Zone2] or [Zone 3] Remote the [Zone2] or [Zone 3] Remote Remote Remote Mode button. Mode button.
  • Page 145 Zone 2 and Zone 3—Continued Adjusting the Volume of Zones Adjusting the Tone and Balance of Zones On the remote controller, press On the AV receiver, press the the [Zone2] or [Zone 3] Remote [Zone 2] or [Zone 3] button. Remote AV receiver Mode button.

  • Page 146: Using The 12V Triggers

    Zone 2 and Zone 3—Continued Using the 12V Triggers Use the Up and Down [ ]/[ ] but- tons to select “12V Trigger A, B, The 12V triggers A, B, and C can be used to turn on 12V or C,” and then press [Enter]. trigger-capable components automatically when they are The “12V Trigger A/B/C Setup”...

  • Page 147: Using The Remote Controller In Zone 2/3 And Multiroom Control Kits

    Zone 2 and Zone 3—Continued Using a Multiroom Kit with a Cabinet Using the Remote Controller in Zone 2/3 and Multiroom Control Kits In this setup, the IR receiver picks up the infrared signals from the remote controller and feeds them to the AV To control the AV receiver with the remote controller receiver located in the cabinet via the connecting block.

  • Page 148: Controlling Other Components

    • The [DVD] and [CD] Remote Mode buttons are Audio Sel L Night Re-EQ preprogrammed for use with Integra/Onkyo DVD RC- 688 M players and CD players, respectively. • To control another manufacturer’s CD recorder, MD recorder or Onkyo RI Dock, enter the appro- priate remote control code to the [CD] Remote Look up the component’s remote...

  • Page 149: Resetting The Remote Controller

    AV receiver, and operate the component. Resetting the Remote Controller If you want to control an Integra/Onkyo component by You can reset the remote controller to its default settings. pointing the remote controller directly at it, or you want to control an Integra/Onkyo component that’s not con-...
  • Page 150 Controlling Other Components—Continued To control another component, point the remote controller at it and use the buttons explained below. (You must select the appropriate remote controller mode with the Remote Mode buttons first.) With some components, certain buttons may not work as expected, and some may not work at all. ■...

  • Page 151: Learning Commands

    • Remote controller buttons such as Play, Stop, Pause, and so on are preprogrammed with commands for controlling Integra/Onkyo CD players, cassette decks, and DVD players. However, they can learn new com- Press the button you want to mands, and you can restore the preprogrammed com- learn the new command.

  • Page 152: Using Macros

    Controlling Other Components—Continued Using Macros Press the buttons whose actions you want to program into the You can program the remote controller’s Macro buttons macro in the order you want them to perform a sequence of remote control actions. performed. Example: For the CD example in the left column, To play a CD you typically need to perform the follow-...

  • Page 153: Troubleshooting

    Troubleshooting If you have any trouble using the AV receiver, look for a designed for home theater enjoyment. It has a wide solution in this section. If you can’t resolve the issue volume range, allowing precise adjustment. yourself, contact the dealer from whom you purchased •...
  • Page 154 Troubleshooting—Continued The surround back speakers produce no sound • Make sure that the multichannel input is selected • The surround back speakers are not used with all lis- (page 130). • Make sure that the “Speaker Type” is not set to tening modes.
  • Page 155 Reception is noisy, FM stereo reception is work as expected, and some may not work at all. noisy, or the FM STEREO indicator doesn’t • To control an Integra/Onkyo component that’s con- appear nected via , point the remote controller at the AV •...
  • Page 156 Troubleshooting—Continued • To control an Integra/Onkyo component that’s not Music Server and Internet Radio connected via , or another manufacturer’s compo- (DTR-9.9 only) nent, point the remote controller at that component. Be Can’t access the server or Internet radio sure to enter the appropriate remote control code first (page 148).
  • Page 157 Troubleshooting—Continued Others The sound changes when I connect my head- phones • When a pair of headphones is connected, the listening mode is set to Stereo, unless it’s already set to Stereo, Mono, or Direct. The speaker volume cannot be set as required •...

  • Page 158: Video Resolution Chart

    Video Resolution Chart The following tables show how video signals at different resolutions are output by the AV receiver. ✔: Output NTSC Output COMPONENT S-VIDEO COMPOSITE HDMI Input 1080p 1080i 720p 480p 480i 1080i 720p 480p 480i 480i 480i ✔ ✔...

  • Page 159: Specifications (Dtr-8.9)

    Specifications (DTR-8.9) Amplifier Section General Rated Output Power Power Supply North American: AC 120 V, 60 Hz All channels: Australian: AC 220 - 240 V, 50/60 Hz North American: Power Consumption North American: 9.5 A 140 watts minimum continuous power...

  • Page 160: Specifications (Dtr-9.9)

    Specifications (DTR-9.9) Amplifier Section General Rated Output Power Power Supply North American: AC 120 V, 60 Hz All channels: Australian: AC 220 - 240 V, 50/60 Hz North American: Power Consumption North American: 9.8 A 145 watts minimum continuous power Australian: 1000 W per channel, 8 ohm loads, 2 channels ×...
  • Page 161 Memo...
  • Page 162 Integra Division of ONKYO U.S.A. CORPORATION 18 park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-818-9200 Fax: 201-785-2650 http://www.integrahometheater.com Integra Division of ONKYO CORPORATION Y0811-2 Sales & Product Planning Div.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8163 SN 29344763A (C) Copyright 2008 ONKYO CORPORATION Japan.

This manual is also suitable for:

Dtr-9.9

Table of Contents

Save PDF
