Manual xelaris 80A Brushless ESC

Thanks for purchasing a Xelaris Brushless Electronic Speed Controller (ESC). High power system for RC model is very dangerous,
please read this manual carefully. In that we have no control over the correct use, installation, application, or maintenance of
our products, no liability shall be assumed nor accepted for any damages, losses or costs resulting from the use of the product.
Any claims arising from the operating, failure or malfunctioning etc. will be denied. We assume no liability for personal injury,
property damage or consequential damages resulting from our product or our workmanship. As far as is legally permitted, the
obligation to compensation is limited to the invoice amount of the affected product.
Specifications:
Current: 80A
Peaks: 100A
BEC: Switch BEC
BEC output: 5V – 4A
Cells: 2 – 4 LiPo Cells / 5 – 12 NiMH Cells
Weight: 82g
Size (L x W x H) 86x38x12
Programmable Items (The option written in bold font is the default setting):
1. Brake Setting Enabled / Disabled
2. Battery Type Lipo / NiMH
3. Low Voltage Protection Mode(Cut-Off Mode): Soft Cut-Off (Gradually reduce the output power) /Cut-Off (Immediately stop
the output power)
4. Low Voltage Protection Threshold(Cut-Off Threshold) Low / Medium / High
1) For lithium battery, the battery cell number is calculated automatically. Low / medium / high cutoff voltage for
each cell is: 2.85V/3.15V/3.3V. For example: For a 3S Lipo, when "Medium" cutoff threshold is set, the cut-off
voltage will be: 3.15*3=9.45V
2) For NiMH battery, low / medium / high cutoff voltages are 0%/50%/65% of the startup voltage (i.e. the initial
voltage of battery pack), and 0% means the low voltage cut-off function is disabled. For example: For a 10 cells
NiMH battery, fully charged voltage is 1.44*6=8.64V, when "Medium" cut-off threshold is set, the cut-off voltage
will be:8.64*50%=4.32V
5. Startup Mode Normal /Soft /Super-Soft (300ms / 1.5s / 3s)
Normal mode is suitable for fixed-wing aircraft. Soft or Super-soft modes are suitable for helicopters. The initial acceleration of
the Soft and Super-Soft modes are slower, it takes 1.5 second for Soft startup or 3 seconds for Super-Soft startup from initial
throttle advance to full throttle. If the throttle is completely closed (throttle stick moved to bottom position) and opened again
(throttle stick moved to top position) within 3 seconds after the first startup, the re-startup will be temporarily changed to
normal mode to get rid of the chance of a crash caused by slow throttle response. This special design is suitable for aerobatic
flight when quick throttle response is needed.
6. Timing Low / Medium / High,( 3.75°/15°/26.25°)
Usually, low timing is suitable for most motors. To get higher speed, High timing value can be chosen.
Begin to use your ESC
IMPORTANT! Because different transmitter has different throttle range, please calibrate throttle range before flying.
Throttle range setting: (Throttle range should be reset whenever a new transmitter is being used)
Switch on the Connect battery
transmitter, pack to the ESC,
move throttle and wait for
stick to the top about 2 seconds
position
Normal startup procedure:
Move throttle stick Connect battery pack to
to bottom position ESC, special tone like
and then switch on " 123" means power
transmitter. supply is OK
Protection Function
1. Start up failure protection: If the motor fails to start within 2 seconds of throttle application, the ESC will cut-off the output
power. In this case, the throttle stick MUST be moved to the bottom again to restart the motor. (Such a situation happens in
the following cases: The connection between ESC and motor is not reliable, the propeller or the motor is blocked, the gearbox
is damaged, etc.)
2. Over-heat protection: When the temperature of the ESC is over about 110 Celsius degrees, the ESC will reduce the output
power.
3. Throttle signal loss protection: The ESC will reduce the output power if throttle signal is lost for 1 second, further loss for 2
seconds will cause the output to be cut-off completely.
www.heli-professional.com
The "Beep-Beep-" tone
should be emitted,
means the top point of
throttle range has been
confirmed
Several "beep-" tones
should be emitted to
present the amount of
lithium battery cells
Move throttle stick to the
bottom position, several
"beep-" tones should be
emitted to present the
amount of battery cells
When self-test is
finished, a long
"beep-----" tone
should be emitted
A long "Beep-" tone
should be emitted,
means the lowest point
of throttle range has
been correctly confirmed
Move throttle stick
upwards to go flying
