    Settings and first flight REVOLUTION 500E Contents Introduction Wiring Mechanical Settings Programming ESC Settings General Safety Instructions Maiden Flight and Regular Flights Heli Professional 2013...

  • Page 2: Introduction

    Dear Customer This additional manual will guide you step by step through the mechanical settings and the programming of your Revolution 500E. In it, there are also some tips for the maiden flight and general flying. Please read this manual carefully before initial startup.
  • Page 3 WARNING: If you want to cancel the changes, it is not sufficient to remove the terminal. You must disconnect the power from the FBL-3X to cancel all unsaved settings. WARNING: The terminal must be removed before flying the helicopter! www.heli-professional.com...

  • Page 4: Programming

    German or French. Save the changes. Connect a receiver You can use the FBL-3X on your Revolution 500E with these receiver types: Standard-receiver, SingleLine, Serial Receiver, Futaba S-Bus, Multiplex SRXL, act SX and SPEKTRUM satellites. Serial Signal, SingleLine, Futaba S-Bus, Multiplex SRXL, act SX Ÿ...
  • Page 5 Every transmitter manufacturer uses different values for 100% servo way. Therefore it is very important to check the values in è the channel monitoring menu and not in the transmitters menu! Adjust the tail gain in your transmitter, to 120 in the channel monitoring menu (Letter: small t). www.heli-professional.com...
  • Page 6 The FBL-3X provides the opportunity to mix a tail input to the pitch input. This must be used, if the tail gyro doesn‘t hold the tail well while pitchpumping. Set this value to 0% on your Revolution 500E. è Stop Tuning Ÿ...
  • Page 7 WARNING: The given values are based on transmitters with curves from 0-100%. If the ranges in your transmitter reach from -100 to +100, -100 is equal to 0%, 0 is equal to 50% and +100 is equal to 100%. www.heli-professional.com...
  • Page 8 Misceallenous Settings These are optional settings which are not necessary for the basic set-up of your Revolution 500E. You can find more information about this menu in complete FBL-3X manual, which can be found in the download library on www.heli-professional.com SwPl.

  • Page 9: Esc Settings

    Maiden flight If the Revolution 500E is your first helicopter with collective pitch, we strongly recommend you to exercise with an RC flight simulator, an smaller coaxial helicopter or a small fixed pitch helicopter. We also suggest you to take an experienced RC helicopter pilot by your side or visit a rc flight school.
  • Page 10 Mount the canopy on your helicopter. Ÿ Put the Revolution 500E on a straight place on the ground. Make sure, the tail and main rotors can turn. Ÿ It is important that the rubber grommets on the landing skid are mounted.
  • Page 11 Expo / Dual Rate: If the steering of your Revolution 500E is to aggressive for you, use the Expo and Dual Rate setting in your transmitter to make it less aggressive.
