8.2.2 Logic Board (Installation)

1. Align Main Logic Board so that the four mounting holes are above the four
fasteners.
2. Press logic board straight down onto the fasteners.
3. Attach connectors going to the main logic board.
4. Secure the heat sink to the cabinet.

8.3 General Cleaning

The interior of the printer should be cleaned whenever there is a visible accumulation of dust. Use a
small vacuum for cleaning. Be careful not to jar any of the printer's parts loose.
9.0

Spare Parts List

Refer to the BOCA Systems website at www.bocasystems.com,
most current Spare Parts List.
PART #
P19-1000
P31-1000
P31-1001
P49-1010
P62-1000
P62-1001
P62-1002
P62-1003
Printer dependent
423226-20
423123
423124
422557-16
422557-18
422558-16
422558-25
432020
421671-1
422560-5
420880 MI
420880 MIP
P19-1004
421682-**
P50-1011
P50-1003
P50-1012
P50-1008
P50-1002
P51-1007
P51-1014
P51-1010
P51-1015
P51-1011
DESCRIPTION
AC CORD
AC FILTER
AC FILTER/POWER SWITCH
ADJUSTABLE PAPER GUIDE SLIDER (complete)
ANTI STATIC BRUSH ONLY (2")
ANTI STATIC BRUSH ONLY (3.25")
ANTI STATIC BRUSH WITH MTG. BRACKET (2")
ANTI STATIC BRUSH WITH MTG. BRACKET (3.25")
CABINET, MICRO PLUS
CABLE RIBBON, CONTROL PANEL 20" (FLG 22 & 42)
CABLE RIBBON, DATA CABLE PARALLEL (for FGL 22 & 42)
CABLE RIBBON, DATA CABLE SERIAL (for FGL 22 & 42)
CABLE RIBBON, THERMAL HEAD (3.25" & 4.0") 16"
CABLE RIBBON, THERMAL HEAD (3.25" & 4.0") 18"
CABLE RIBBON, THERMAL HEAD (BS2002 & BS3002) 16"
CABLE RIBBON, THERMAL HEAD (BS2002 & BS3002) 25"
CAM LEVER, PAPER GUIDE
CONTROL PANEL, FGL 22 & 42
CONTROL PANEL DECAL, FGL 22 & 44
COVER MTG. HARDWARE (SCREW, FL,LW)
COVER, MICRO CABINET
COVER, MICRO PLUS CABINET
DC HARNESS, MICRO (FGL 20 & 40)
DEFLECTOR, PAPER GUIDE (** Printer Dependent )
DRIVE BELT, 100T
DRIVE BELT, 102T
DRIVE BELT, 105T
DRIVE BELT, 110T
DRIVE BELT, 89T
DRIVE PULLEY, 20T (Large ID .25")
DRIVE PULLEY, 20T (small ID 5mm) Used on printers with LCD displays
DRIVE PULLEY, 22T (Large ID )
DRIVE PULLEY, 22T (small ID 5mm) Used on printers with LCD displays
DRIVE PULLEY, 30T
