Menus

DISPLAY SETUP

Display setup menu is where you will setup the desired parameters to be
displayed on the running screen. With a parameter highlighted you can then
use the ON soft key to have it show up on the running screen or select the
OFF soft key to turn off the parameter. Use PRIMARY soft key to have a
parameter show up on the running screen in a larger display. Only one
parameter can be selected as a primary, and up to 2 secondary parameters
can be selected at one time.

SETTINGS

Settings menu is where you can set the general settings. These include
Language, Beeper, Select Units, Time Constant, Contrast, Set Time, Set
Date, Time Format, Date Format, Number Format, Backlight and Auto Off.
Use the or soft keys to scroll through the settings for each option and
use the key to accept settings.

FLOW SET UP

In Flow Setup mode, there are 3 types: Round Duct, Rectangle Duct and
Duct Area. Use the
press the key to accept the desired type. To change the value, highlight the
Enter Settings option and press the

DATA LOGGING

Measurements

Measurements to be logged are independent of measurements on the
display, and must therefore be selected under DATA LOGGING
Measurements.

Log Mode/Log Settings

You can set Log Mode to Manual or Auto-save.
•
Manual mode does not automatically save data, but instead prompts
the user to save a sample.
•
In Auto-save mode, the user manually takes samples that are
automatically logged.
•
In Cont-key mode, the user starts taking readings and logging by
pressing the
measurements until the
6
or soft keys to scroll through the types and then
key.
key. The instrument will continue taking
key is pressed again.
Chapter 3
