Wolf Ranges Technical & Service Manual page 58

R R A A N N G G E E S S & & R R A A N N G G E E T T O O P P S S
LIGHT
SWITCH
BLACK (23)
RED (32)
BLACK (38)
LEFT
REAR
BROWN (39)
19-09-1129 RCPT
1 2 3 4 5 6 7 8 9 10 11 12 MOLEX G-2
19-09-2128 PLUG 1 2 3 4 5 6 7 8 9 10 11 12 MOLEX G-1
BROWN (13)
BLUE (5)
WHITE (3)
DOOR
SWITCH
WHITE (2)
OVEN SECTION
MANIFOLD COVER SECTION
WHITE (29)
BLUE (30)
WHITE (24)
PURPLE (34)
BLACK (21)
C BR BA
THERMOSTAT
L1 L2
BLACK (41)
BLACK (37)
LEFT
FRONT
BLUE (28)
YELLOW (33)
BLACK (35)
RED (40)
MANIFOLD PIPE SECTION
OVEN
SAFETY
OVEN IGNITOR
BLACK (1)
BLUE (30A)
WHITE (26)
INDICATOR
LIGHT
BLACK (22)
BLACK (36)
WHITE (25)
RIGHT RIGHT
REAR FRONT
WHITE (6)
LIGHT
YELLOW (7)
PURPLE (10)
S3 S4
S1 S2
4 POINT SPARK MODULE
MOLEX 10-17-3111 PLUG
GROUND
11 10 9 8 7 6 5 3 2 1
4
YELLOW (9)
GREEN (17)
RED (14)
WHITE
J - BOX
BLACK
WHITE (18)
GROUND
BLACK (12)
BACK PANEL SECTION
7-2
R304/R304-LP
FAN 1 2 19-09-1029 RCPT
SWITCH
1 2 19-09-2028 PLUG
BROILER
IGNITOR
WHITE (19)
BROILER
SAFETY
BLUE (30B)
8
2 4 6
7
1 3 5
FAN RELAY
MOTOR
115V
60 HZ
PLUG
GREEN
Wiring Diagrams
1
19-09-1019 RCPT
1 19-09-2019 PLUG
