  • Page 1 Gas Ranges Installation Guide...
  • Page 2 GAS RANGES Contents Important Note Safety Precautions To ensure the safe and efficient installation of Wolf equip- ment, please take note of the following types of highlighted Specifications information throughout this guide: Installation highlights information that is especially IMPORTANT NOTE Troubleshooting relevant to a problem-free installation.
  • Page 3: Important Instructions

    Verify the anti-tip device has been properly to the illustration below. installed and engaged. Ensure the anti-tip device If service is necessary, contact Wolf factory certified service is re-engaged when this appliance is moved. Refer with the model and serial number. For the name of the...
  • Page 4 A ground fault circuit interrupter (GFCI) is not recommended and may cause interruption of operation. ELECTRICAL REQUIREMENTS GAS RANGE Electrical Supply grounded, 110/120 V AC, 60 Hz Service 15 amp dedicated circuit Receptacle 3-prong grounding-type Power Cord (1.8 m) Wolf Customer Care 800.222.7820...
  • Page 5: Gas Supply

    3. If this information does not agree with the type of with natural or LP gas should be used. gas available, check with the local gas supplier. Wolf natural and LP gas ranges will function up to 10,250' GAS SUPPLY REQUIREMENTS in altitude without adjustment. If the installation...
  • Page 6 NOTE: For island installations, 12" min clearance from back of range to combustible rear wall above countertop. (305) GAS RANGE WIDTH OPENING WIDTH 30" Range 30" (762) 36" Range 36" (914) 48" Range 48" (1219) 60" Range " (1530) Wolf Customer Care 800.222.7820...
  • Page 7 INSTALLATION Preparation Before moving the range, protect any finished flooring and OVEN DOOR REMOVAL secure oven door(s) closed to prevent damage. Insert the hinge pin into the appropriate hinge. To lighten the load or to fit through a door way, the oven Remove the lower kickplate assembly to access the door(s) can be removed.
  • Page 8 3" (76) from the left side of the opening. Refer to the If a riser has been specified, refer to the installation instruc- illustration below. tions packaged with the riser. The riser must be installed before the range is installed. ANTI-TIP BRACKET 3" (76) Anti-tip bracket location. Wolf Customer Care 800.222.7820...
  • Page 9 INSTALLATION Anti-Tip Bracket INSTALL BRACKET ANTI-TIP BOLT ADJUSTMENT Drywall application After properly positioning the anti-tip Once the bracket is secure, adjust the anti-tip bolt so the bracket, mark holes, then use a Philips screwdriver or a low top of the washer is "...
  • Page 10: Gas Supply Connection

    Bubbles • If the range does not operate properly, contact Wolf around connections indicate a gas leak. If a leak appears, factory certified service. Do not attempt to repair the close the shut-off valve and adjust connections.
  • Page 11 Wolf, Wolf & Design, Wolf Gourmet, W & Design and the color red as applied to knobs are registered trademarks and service marks of Wolf Appliance, Inc. Sub-Zero, Sub-Zero & Design, Dual Refrigeration, Constant Care, The Living Kitchen, Great American Kitchens The Fine Art of Kitchen Design, and Ingredients are registered trademarks and service marks...
  • Page 12 WOLF APPLIANCE, INC. P.O. BOX 44848 MADISON, WI 53744 WOLFAPPLIANCE.COM 800.222.7820 819488 REV-C 12 / 2012...
