6 Software user interface

6.4 The Crossfader rack

If you are using a DJ mixer connected to a multiple output audio interface, you will not need to use the MIXVIBES VFX
crossfader. You can use your mixer's crossfader for direct control. Note: The crossfader of your mixer does not work to control
VFX (except if it is used in MIDI and mapped in VFX).
1 Crossfader: this component's function is identical to the traditional crossfader on an analog DJ mixe. It is used to
balance the mix (audio, video or audio+video) of the 2 media files.
2 Match: matches the BPM of one Player to the other. Click on the right-hand match button to match the BPM of Player B
with Player A. Alternately click on the left-hand match button and this will match the BPM of Player A with Player B.
main_volume1.pdf 09/11/2010 14:49:04
3 Sync: synchronizes the BPM and beat of one Player to the other. Click on the right-hand sync button to sync the Player
C
B with Player A. Alternatively click on the left-hand match button and this will sync the Player A with Player B. This tool
M
gives access in one click to two of the DJs usual tasks. It combines beat matching and synchronization of 2 media files.
Y
4 Channel: assigns a channel to either right or left side of the crossfader.
CM
5 Sync Mode: selects and synchronizes the crossfader and players faders mode (audio, video or audio+video). To not
synchronize the crossfader mode with the players' mode, go to [Options/Preferences/Video] and uncheck 'Synchronize
MY
crossfader AV mode with players'.
CY
6 Audio CF: selects the audio crossfader curve. Linear is especially practical for long mixes. Cut is especially practical
CMY
for scratching and cutting.
K
7 Type: selects the crossfader video transition mode.

6.5 The Main Volume / Record rack

The screenshot above shows how the Main volume / Record rack looks with two stereo outputs.
6.5.1 Stand alone setup / External audio interface setup
With two stereo outputs, this rack controls the master and the monitor volume.
1 Master: the master rack is a tool used to master your audio signal. To avoid saturation, check the audio signal view. If
C
the signal is saturated you must change your settings in the Master volume section or Equalizer/mixer section.
M
2 Monitor: the monitor rack is a tool used to preview your audio signal.
Y
3 Recording: records your mix in WAV format. Click the button in the volume rack of your choice and designate the
CM
name and directory for the recording. The recording is active at once! Click again to stop the recording. Keep an eye on
MY
the Record output vu-meter to make sure the recording does not saturate!
CY
CMY
K
