5. ADE-8001 DVI-D Short Range Receiver
1. DVI output (To monitor)
2. RJ-45 DVI input
6. ADE-8002 DVI-D Long Range Receiver
Auto : Auto EQ is selected
FOCUS : EQ adjust (Auto or manual)
Power Jack : Connect to power adapter
DVI OUT : Connect to monitor or projector
LINK LED : DVI activity
PWR LED : Power indicator
LINK IN : RJ-45 DVI input
