Specification

Model
Function
Input
Output
RJ-45 to DVI-D
Receiver and RJ-11 to
Audio Receiver
DVI
Input
DVI
Max
Output
Distance
and
Resolution
RJ45
Output
Signal Type
Power Consumption
Housing
Dimension (LxWxH)
mm
ADE-8201
Single-Port DVI
Transmitter
DVI Male x 1
RJ-45 x 1
One RJ-45 to
DVI-D Receiver
(ADE-8001 or
ADE-8002)
Transmitting over standard DVI cable up to 10 meters
-
Transmitting over Cat5/5e/6 cable,
DVI resolution for ADE-8001 is 800x600@20m, 1024x768@15m, 1280x1024@10m;
for ADE-8002 is 800x600@80m, 1024x768@70m, 1280x1024@60m, 1920x1200@35m
DC 9V, 250mA
Plastic
Compact
ADE-8202
2-Port DVI
Broadcaster with
Audio
DVI Female x 1, Audio x 1
DVI Female x 1
Audio x 1
RJ-45 x 2
RJ-11 x 2
2 sets
Transmitting over standard DVI cable, DVI resolution
1920x1200@10m.
DVI-D
DC 5V, 800mA
1U Height
ADE-8204
4-Port DVI
Broadcaster with
Audio
DVI Female x 1
Audio x 1
RJ-45 x 4
RJ-11 x 4
4 sets
DC 5V, 3200mA
Metal
1U Height
ADE-8208
8-Port DVI
Broadcaster with
Audio
DVI Female x 1
Audio x 1
RJ-45 x 8
RJ-11 x 8
8 sets
DC 5V, 3200mA
1U Height
