LevelOne ADE-8001 User Manual page 15

Model
Function
Input
Output
Max Distance and
Resolution
Signal Type
Power Consumption
Remarks
1. Before operating this splitter, please read operation manual carefully.
2. Please use high quality DVI, audio cable for optimum operation.
3. To prevent potential power damage, please don't use 2-wire extension cord and ensure
AC outlets at PCs and monitors are on the same phase and have correct grounding.
ADE-8001
Short range DVI
Receiver
RJ-45 x 1
DVI Female x 1
Transmitting over
Cat5/5e/6 cable,
DVI resolution
800x600@20m,
1024x768@15m,
1280x1024@10m.
DVI-D
ADE-8002
DVI Video Receiver
RJ-45 x 1
DVI Female x 1
Transmitting over
Cat5/5e/6 cable,
DVI resolution
800x600@80m,
1024x768@70m,
1280x1024@60m,
1920x1200@35m
DC 9V, 500mA
ADE-8011
Audio Transmitter/Receiver
RJ-11 x 1 Audio Jack x 1
Audio Jack x 1 RJ-11 x 1
Transmitting over 4-wire phone
cable, stereo audio over 100m
Stereo
