SUPPLIED COMPONENTS
This list identifies the major components you will use to assemble this product.
Pedal Support Tube (L)
Pedal Support Tube (R)
Action Handlebar (R)
Action Handlebar (L)
Console Base
Power pack
Lower Upright Post Cover(L)
Base Frame
Pedal Support Tube Top (L/R)
Pedal Support Tube Bottom (L/R)
Upright Tube
Long Connecting Bar
Rear Stabilizer
Front Stabilizer
Pedal Support Tube (L)
Pedal Support Tube (R)
www.smoothfitness.com
Console
Pedal (L)
Pedal (R)
Fixed Handlebar
Tablet Shelf
Upper Upright Post Cover(L)
Upper Upright Post Cover(R)
Action Arm Cover Front
5
