10 SMOOTH CE 5.5 ELLIPTICAL
COMPLETE PARTS LIST
Item No.
Washer ∮35*∮12*Ｔ2.0
94
Washer ∮35*∮6*Ｔ2.0
95
96 Bearing 6001
97A Toggle switch left
97B Toggle switch right
98 Square moving arms (L)
99 Square moving arms (R)
100 Long connecting bar
101 Swinging axle plate
102 Second step tube left
103 Second step tube right
104 Step foot cover-Top
105
106 Pedal tube cover top (L)
107 Pedal tube cover bottom ( L )
108 Pedal tube cover top ( R )
109 Pedal tube cover bottom ( R )
110 Roller cover
111 Screw M5*8
112 Bearing 6002
113 Alum rail
114 Axle for inner adjustor
115 Base for inner adjustor
116 Outer adjustor
117 Connecting axle for lift motor
118 Holder for lift motor
119 Adjustor connector
120 Hex head screw M10×70mm
121 Lift motor
122 Screw 5/32*5/8
123 Arm cover front
124 Arm cover rear
125 Base bracket for lift motor
126 Hex head screw M10×40mm
127 Bottle holder
128 VST control board
129 380 Pulley rim
130A Upright post cover
130B Upright post cover
131 Console base
132A Left upper upright post cover
132B Right upper upright post cover
133 Front console cover
134 Front cover
135 Screw M4*16mm
Description
Step foot cover-Bottom
Qty. Part No.
1 CE55-94
1 CE55-95
6 CE55-96
1 CE55-97A
1 CE55-97B
1 CE55-98
1 CE55-99
2 CE55-100
2 CE55-101
1 CE55-102
1 CE55-103
2 CE55-104
2 CE55-105
1 CE55-106
1 CE55-107
1 CE55-108
1 CE55-109
2 CE55-110
3 CE55-111
4 CE55-112
2 CE55-113
1 CE55-114
1 CE55-115
1 CE55-116
1 CE55-117
2 CE55-118
2 CE55-119
1 CE55-120
1 CE55-121
24 CE55-122
2 CE55-123
2 CE55-124
1 CE55-125
1 CE55-126
1 CE55-127
1 CE55-128
2 CE55-129
1 CE55-130A
1 CE55-130B
1 CE55-131
1 CE55-132A
1 CE55-132B
1 CE55-133
1 CE55-134
11 CE55-135
