Front Unit - Icom IC-F3061S Service Manual

SECTION 7
• IC-F4061/F4062/F4063/T/S

[FRONT UNIT]

REF ORDER
NO. NO.
IC501 1180002401 S.REG S-812C30AMC-C2K-G
IC505 1110006440 S.IC M62320FP DF5J
IC506 1110006440 S.IC M62320FP DF5J
IC508 1110006770 S.IC TDA8547TS/N
IC509 1110005330 S.IC NJM12904V-TE1
Q501 1520000460 S.TR 2SB1132 T100 R
Q502 1590001190 S.TR XP6501-(TX) .AB
Q505 1590002230 S.TR UMG2N TL
Q506 1590003230 S.TR UNR9113J-(TX)
Q507 1590003290 S.TR UNR9213J-(TX)
Q508 1590001330 S.TR DTA114EUA T106
Q509 1590000980 S.TR DTB123EK T146
Q512 1590003290 S.TR UNR9213J-(TX)
Q513 1590003290 S.TR UNR9213J-(TX)
Q514 1590003230 S.TR UNR9113J-(TX)
Q515 1560001360 S.FET 2SK3019 TL
Q516 1590003290 S.TR UNR9213J-(TX)
D502 1790001250 S.DIO MA2S111-(TX)
D503 1790001250 S.DIO MA2S111-(TX)
D504 1790001250 S.DIO MA2S111-(TX)
D505 1160000140 S.DIO DAP222 TL
D506 1160000140 S.DIO DAP222 TL
D508 1160000060 S.DIO DAN202U T106
R503 7030009140 S.RES ERJ2GEJ 272 X (2.7 k)
R504 7030008290 S.RES ERJ2GEJ 183 X (18 k)
R505 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R506 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R508 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R509 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R510 7030005080 S.RES ERJ2GEJ 823 X (82 k)
R511 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R513 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R514 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R515 7030005080 S.RES ERJ2GEJ 823 X (82 k)
R516 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R517 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R518 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R519 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R520 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R521 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R522 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R523 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R524 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R525 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R526 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R527 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R528 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R529 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R530 7030009280 S.RES ERJ2GEJ 391 X (390)
R531 7030005000 S.RES ERJ2GEJ 471 X (470)
R532 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R533 7030007250 S.RES ERJ2GEJ 220 X (22)
R534 7030007250 S.RES ERJ2GEJ 220 X (22)
R535 7030004970 S.RES ERJ2GEJ 470 X (47)
R536 7030004970 S.RES ERJ2GEJ 470 X (47)
R537 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R538 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R539 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R540 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R541 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R542 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R543 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R544 7030004980 S.RES ERJ2GEJ 101 X (100)
R546 7030009280 S.RES ERJ2GEJ 391 X [10-key type] only B
R547 7030009280 S.RES ERJ2GEJ 391 X [10-key type] only B
R548 7030005230 S.RES ERJ2GEJ 334 X (330 k)
R552 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R553 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R554 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R555 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R557 7030004970 S.RES ERJ2GEJ 470 X (47)
R558 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R559 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R560 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R561 7030005000 S.RES ERJ2GEJ 471 X (470)
[L]=Low band [H]=High band
PARTS LIST
DESCRIPTION M.
LOCATION
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
[4-key type] only B
[10-key type] only B
B
B
B
B
B
B
[FRONT UNIT]
REF ORDER
NO. NO.
H/V
R562 7030005000 S.RES ERJ2GEJ 471 X (470)
R563 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R564 7030005050 S.RES ERJ2GEJ 103 X (10 k)
66.7/35.7
R566 7030010040 S.RES ERJ2GEJ-JPW
74/36.8
R567 7030005090 S.RES ERJ2GEJ 104 X (100 k)
56.8/24.5
79.6/11.9
79.8/24.9
C501 4550006760 S.TAN TEESVB21A336M8R
C502 4550006760 S.TAN TEESVB21A336M8R
C506 4550006250 S.TAN TEESVA 1A 106M8R
75.2/25
C507 4550006250 S.TAN TEESVA 1A 106M8R
75.8/20.8
C508 4550006250 S.TAN TEESVA 1A 106M8R
71.5/22
C509 4030017460 S.CER ECJ0EB1E102K
83.3/41
C510 4030016930 S.CER ECJ0EB1A104K
72.3/6.1
C511 4030017460 S.CER ECJ0EB1E102K
72.2/9
C514 4550006250 S.TAN TEESVA 1A 106M8R
72.4/12.3
C515 4030016930 S.CER ECJ0EB1A104K
72/18
C517 4030016930 S.CER ECJ0EB1A104K
74.9/15.6
C518 4030017460 S.CER ECJ0EB1E102K
67.6/26.8
C520 4030017460 S.CER ECJ0EB1E102K
81/32.2
C522 4030016930 S.CER ECJ0EB1A104K
80.9/36
C523 4030016930 S.CER ECJ0EB1A104K
C524 4030017460 S.CER ECJ0EB1E102K
C525 4030016930 S.CER ECJ0EB1A104K
71/23.9
C526 4030017460 S.CER ECJ0EB1E102K
66.8/21.1
C527 4030017460 S.CER ECJ0EB1E102K
71/25.1
C528 4030016930 S.CER ECJ0EB1A104K
63.6/21.9
C529 4030016930 S.CER ECJ0EB1A104K
63.6/26
C530 4030017460 S.CER ECJ0EB1E102K
75.1/5.7
C531 4030017460 S.CER ECJ0EB1E102K
C532 4550007090 S.TAN TEESVA 1A 226M8R
74/20 C534 4030016930 S.CER ECJ0EB1A104K
74.8/18.4
C535 4030016790 S.CER ECJ0EB1C103K
76.6/18.4
C536 4550005980 S.TAN TEESVA 1A 475M8R
75.2/13.7 C537 4030016930 S.CER ECJ0EB1A104K
81.8/18.2
C538 4550000460 S.TAN TEESVA 1C 105M8R
79.1/18.2 C539 4030016930 S.CER ECJ0EB1A104K
81.7/16.6 C540 4030018140 S.CER ECJ0EB1H391K
78.3/16.6
C541 4030016930 S.CER ECJ0EB1A104K
85.2/41.1 C542 4030017440 S.CER ECJ0EC1H221J
87.5/38.8
C543 4550006250 S.TAN TEESVA 1A 106M8R
81.8/34 C544 4030017460 S.CER ECJ0EB1E102K
79.4/32.4 C559 4030016790 S.CER ECJ0EB1C103K
67.4/24.8
C560 4030017770 S.CER ECJ0EB1E332K
66.2/22.5 C561 4030016930 S.CER ECJ0EB1A104K
69.4/22.3
69.4/20.7
68.3/24.8
J501 6510025240 S.CNR IMSA-9631S-20Y912
53.6/18.8
J502 6510025250 S.CNR IMSA-9631S-08Y912
54.6/18.8
J503 6510025260 S.CNR IMSA-9631S-10Y912
55.6/18.8
56.6/18.8
65.2/22.1
DS501 5040002960 S.LED SML-A12MT T86
63.6/23.5
DS502 5040002960 S.LED SML-A12MT T86
63.6/24.4
DS503 5040002960 S.LED SML-A12MT T86
65/24.7
DS504 5040002420 S.LED SML-310MT T86
71.6/14.4
DS505 5040002420 S.LED SML-310MT T86
82.7/33
DS506 5040002420 S.LED SML-310MT T86 [10-key type] only T
65.2/28
DS507 5040002420 S.LED SML-310MT T86 [10-key type] only T
63.6/27.6
DS508 5040002420 S.LED SML-310MT T86 [10-key type] only T
63.6/28.6
DS509 5040002420 S.LED SML-310MT T86 [10-key type] only T
69.7/3.4
DS510 5030002830 LCD
69.7/5.4
69.7/4.4
72/3.1
MC501 7700002480 MIC
69.7/2.4
80.3/20.2
79.4/20.2
W501 9028930010 WIR
81.7/28.3
W502 9014506004 WIR
82.6/27.1
82.6/29.9
71.6/15.3
71.6/16.2
74.4/8.5
79.8/30.4
71/42
72.6/42
74.4/9.4
87/34.7
73.9/18.4
77.4/16.6
77.5/18.4
82.7/22.7
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
