INTRODUCTION
This service manual describes the latest service information
for the IC-F3061T/S, IC-F3062T/S and IC-F3063T/S VHF
TRANSCEIVER at the time of publication.
MODEL
VERSION SYMBOL CHANNEL SPACING KEY PAD
IC-F3061T
U.S.A
[USA-01]
IC-F3061S
IC-F3062T
EURO
[EUR-01]
IC-F3062S
IC-F3063T
GENERAL [GEN-01]
IC-F3063S
To upgrade quality, all electrical or mechanical parts and internal
circuits are subject to change without notice or obligation.
DANGER
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than 7.2 V. Such a connection
could cause a fire or electric hazard.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the trans-
ceiver's front end.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom parts number
2. Component name and informations
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
5030002830 LCD
M4-0078TAY-2
8810009220 Screw PH B0 M2×8 ZK (BT) IC-F3061T
Addresses are provided on the inside back cover for your
convenience.
1. Make sure the problem is internal before disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the transceiver is defective.
6. DO NOT transmit power into a signal generator or a sweep generator.
7. ALWAYS connect a 30 dB to 40 dB attenuator between the transceiver and a deviation meter or spectrum analyzer when
using such test equipment.
8. READ the instructions of test equipment thoroughly before connecting equipment to the transceiver.
Icom, Icom Inc. and
Kingdom, Germany, France, Spain, Russia and/or other countries.
10-key
15.0 kHz/30.0 kHz
4-key
10-key
12.5 kHz/25.0 kHz
4-key
12.5 kHz/20.0 kHz
10-key
/25.0 kHz
4-key
IC-F3061T
Front unit 5 pieces
Chassis 10 pieces
REPAIR NOTES
logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United
