Parts List; Front Unit - Icom IC-F2610 Service Manual

SECTION 6

[FRONT UNIT]

REF ORDER
NO. NO.
IC1 1130009120 S.IC
IC2 1140007631 S.IC
IC3 1110003500 S.IC
IC4 1130005720 S.IC
IC5 1110003390 S.IC
Q1 1530002060 S.TRANSISTOR
Q2 1590001330 S.TRANSISTOR
Q3 1590000680 S.TRANSISTOR
Q4 1590001330 S.TRANSISTOR
Q5 1590000680 S.TRANSISTOR
Q6 1590000440 S.TRANSISTOR
Q7 1590000440 S.TRANSISTOR
Q8 1590000440 S.TRANSISTOR
Q9 1590000440 S.TRANSISTOR
Q10 1590000680 S.TRANSISTOR
Q11 1590000680 S.TRANSISTOR
D1 1790001280 S.DIODE
D2 1790001280 S.DIODE
D3 1790001280 S.DIODE
D4 1790001280 S.DIODE
D5 1750000130 S.DIODE
D6 1750000130 S.DIODE
D7 1750000130 S.DIODE
D8 1750000130 S.DIODE
D9 1750000130 S.DIODE
X1 6050009870 S.XTAL
L1 6200001720 S.COIL
R1 7030003810 S.RESISTOR
R2 7310002820 S.TRIMMER
R3 7030003800 S.RESISTOR
R4 7030003440 S.RESISTOR
R5 7030003680 S.RESISTOR
R6 7030003760 S.RESISTOR
R7 7030003560 S.RESISTOR
R8 7030003720 S.RESISTOR
R9 7030003720 S.RESISTOR
R10 7030003680 S.RESISTOR
R11 7030003800 S.RESISTOR
R12 7030003680 S.RESISTOR
R13 7030003680 S.RESISTOR
R15 7030003560 S.RESISTOR
R16 7030003500 S.RESISTOR
R17 7030003680 S.RESISTOR
R18 7030003680 S.RESISTOR
R19 7030003680 S.RESISTOR
R20 7030003680 S.RESISTOR
R21 7030003680 S.RESISTOR
R22 7030003680 S.RESISTOR
R23 7030003500 S.RESISTOR
R24 7030003440 S.RESISTOR
R25 7030003440 S.RESISTOR
R26 7210002830 VARIABLE
R27 7030003340 S.RESISTOR
R28 7030003340 S.RESISTOR
R29 7030003370 S.RESISTOR
R30 7030003440 S.RESISTOR
R31 7030003440 S.RESISTOR
R32 7030003390 S.RESISTOR
R34 7030003360 S.RESISTOR
R35 7030003680 S.RESISTOR
R36 7030003680 S.RESISTOR
R37 7030003680 S.RESISTOR
R38 7030003680 S.RESISTOR
R39 7030003680 S.RESISTOR
R40 7030003680 S.RESISTOR
R41 7030003680 S.RESISTOR

PARTS LIST

DESCRIPTION
SED1526F0A
HD6433640A33H
S-80742SL-A6-T1
TC7W04F (TE12L)
AN8005M-(E1)
2SC4081 T107 R
DTA114EUA T106
DTC114EUA T106
DTA114EUA T106
DTC114EUA T106
DTA143ZUA T106
DTA143ZUA T106
DTA143ZUA T106
DTA143ZUA T106
DTC114EUA T106
DTC114EUA T106
MA111 (TX)
MA111 (TX)
MA111 (TX)
MA111 (TX)
DA204U T107
DA204U T107
DA204U T107
DA204U T107
DA204U T107
CR-567 (9.8304 MHz)
NL 322522T-1R0J
ERJ3GEYJ 125 V (1.2 MΩ)
RV-158 (RH03A3AS5) 474
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
EVU-F2JFK4 B14
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
[FRONT UNIT]
REF ORDER
NO. NO.
R42 7030003680 S.RESISTOR
R43 7030003680 S.RESISTOR
R44 7030003680 S.RESISTOR
R45 7030003680 S.RESISTOR
R46 7030003440 S.RESISTOR
R47 7030003440 S.RESISTOR
R48 7030003440 S.RESISTOR
R49 7030003600 S.RESISTOR
C1 4030011600 S.CERAMIC
C2 4030011600 S.CERAMIC
C3 4030011600 S.CERAMIC
C4 4030011600 S.CERAMIC
C5 4030011600 S.CERAMIC
C6 4030012600 S.CERAMIC
C7 4030012600 S.CERAMIC
C8 4030008630 S.CERAMIC
C9 4030006860 S.CERAMIC
C10 4030009000 S.CERAMIC
C11 4030006900 S.CERAMIC
C13 4030007030 S.CERAMIC
C14 4030007030 S.CERAMIC
C15 4030006860 S.CERAMIC
C16 4030006900 S.CERAMIC
C17 4030008630 S.CERAMIC
C18 4030008630 S.CERAMIC
C19 4030006850 S.CERAMIC
C20 4550006250 S.TANTALUM
C21 4550003220 S.TANTALUM
C22 4030008630 S.CERAMIC
C23 4030006850 S.CERAMIC
C24 4030006850 S.CERAMIC
C25 4030006850 S.CERAMIC
C26 4030008630 S.CERAMIC
C27 4030006860 S.CERAMIC
C28 4030007090 S.CERAMIC
C29 4030007090 S.CERAMIC
C30 4030006860 S.CERAMIC
C31 4030006860 S.CERAMIC
C32 4030007090 S.CERAMIC
C33 4030007090 S.CERAMIC
C34 4030007090 S.CERAMIC
C35 4030007090 S.CERAMIC
C36 4030007090 S.CERAMIC
C37 4030007090 S.CERAMIC
C38 4030007090 S.CERAMIC
C39 4030007090 S.CERAMIC
C40 4030007090 S.CERAMIC
C41 4030007090 S.CERAMIC
C42 4030007090 S.CERAMIC
C43 4030007090 S.CERAMIC
C44 4030007090 S.CERAMIC
C45 4030007090 S.CERAMIC
C46 4030007090 S.CERAMIC
C47 4030007090 S.CERAMIC
C48 4030007090 S.CERAMIC
C49 4030007090 S.CERAMIC
C50 4030007090 S.CERAMIC
C51 4030007090 S.CERAMIC
C52 4030007090 S.CERAMIC
J1 6450001470 CONNECTOR
J2 6510018030 S.CONNECTOR
DS1 5030001650 LCD
DS2 5040002470 S.LED
DS3 5040002470 S.LED
DS4 5040002470 S.LED
DS5 5040002470 S.LED
DS6 5040002470 S.LED
DS7 5040002030 S.LED
DS8 5040002030 S.LED
DS10 5040002030 S.LED
6 - 1
DESCRIPTION
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C2012 JB 1A 105M-T-A
C2012 JB 1A 105M-T-A
C1608 JF 1C 104Z-T-A
C1608 JB 1H 102K-T-A
C2012 JB 1C 224K-T-A
C1608 JB 1E 103K-T-A
C1608 CH 1H 150J-T-A
C1608 CH 1H 150J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JB 1H 471K-T-A
TEMSVA 1A 106M-8L
TEMSVA 1E 105M-8L
C1608 JF 1C 104Z-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 471K-T-A
C1608 JF 1C 104Z-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
95003-2881
53248-1217
LD-NU10377E
FY1112H
FY1112H
FY1112H
FY1112H
FY1112H
CL-170Y-CD-T
CL-170Y-CD-T
CL-170Y-CD-T
S.=Surface mount
