SECTION 6

6-1 PREPARATION

When adjusting IC-F4060 series, the optional CS-F3060 ADJ
(modifi ed OPC-966
CLONING CABLE
▄ REQUIRED TEST EQUIPMENS
EQUIPMENT
Frequency range
FM deviation meter
Measuring range
Frequency range
Frequency counter Frequency accuracy
Sensitivity
Measuring range
Frequency range
RF power meter
Impedance
SWR
▄ SYSTEM REQUIREMENTS
® ®
• Microsoft Windows 98/98SE/Me/2000/XP
• RS-232C serial port (D-sub 9 pin)
▄ ADJUSTMENYT SOFTWARE INSTALLATION
q Quit all applications when Windows is running.
w Insert the CD into the appropriate CD drive.
e Double-click the "Setup.exe" contained in the 'CS-F3060
ADJ' folder in the CD drive.
r The "Welcome to the InstallShield Wizard for CS-F3060
ADJ" will appear. Click [Next>].
t The "Choose Destination Location" will appear. Then click
[Next>] to install the software to the destination folder. (e.g.
C:\Program Files\Icom\CS-F3060 ADJ)
y After the installation is completed, the "InstallShield Wiz-
ard Complete" will appear. Then click [Finish].
u Eject the CD.
i Program group 'CS-F3060 ADJ' appears in the 'Programs'
folder of the start menu, and 'CS-F3060 ADJ' icon ap-
pears on the desk top screen.
▄ BEFORE STARTING SOFTWARE ADJUSTMENT
Clone the adjustment frequencies into the transceiver, and
set the configuration using the CS-F3060
before starting the software adjustment. Otherwise, the
WARE
software adjustment can not be started.
CAUTION!: BACK UP the originally programmed mem-
ory data in the transceiver before program-
ming the adjustment frequencies.
When program the adjustment frequencies into
the transceiver, the transceiver's memory data
will be overwritten and lose original memory
data at the same time.
Microsoft and Windows are registered trademarks of Micro-
soft Corporation in the U.S.A. and other countries.

ADJUSTMENT PROCEDURES

; see illustration page 5-2) and the following equipments are required.
GRADE AND RANGE
: DC–600 MHz
: 0 to ±10 kHz
: 0.1–600 MHz
: ±1 ppm or better
: 100 mV or better
: 0.1–10 W
: 100–600 MHz
: 50 Ω
: Better than 1.2 : 1
CLONING SOFT-
(Rev. 1.1 or later), OPC-966
ADJUSTMENT SOFTWARE
EQUIPMENT
Power attenuation
Attenuator
Capacity
Standard signal Frequency range
generator (SSG) Output level
Frequency rang
Oscilloscope
Measuring range
Input impedance
External speaker
Capacity
▄ STARTING SOFTWARE ADJUSTMENT
q Connect the transceiver and PC with OPC-966
w Turn the transceiver power ON.
e Boot up Windows, and click the program group 'CS-F3060
ADJ' in the 'Programs' folder of the [Start] menu, then
CS-F3060 series ADJ's window appears.
r Click 'Connect' on the CS-F3060 ADJ's window, then
appears transceiver's up-to-date condition.
t Set or modify adjustment data as specifi ed.
• ADJUSTMENT FREQUENCY LIST
FREQUENCY (MHz)
CH
Low band
1 400.000
2 435.000
3 470.000
4 434.950
5 435.000
6 435.000
7 435.000
8 400.000
9 470.000
10* 435.000
11* 400.000
12* 470.000
†
13 435.000
†
14 400.000
†
15 470.000
16 435.000
*; [EUR-01] only
†
; Necessary only when the optional UT-119S/H is installed.
6 - 1
GRADE AND RANGE
: 20 or 30 dB
: 10 W
: 0.1–600 MHz
: 0.1 µV to 32 mV
(–127 to –17 dBm)
: DC–20 MHz
: 0.01–20 V
: 8 Ω
: 1 W or more
ADJUSTMENT ITEM
High band
TX power : Low1
450.000
Mode : Wide
TX power : Low1
485.000
Mode : Wdie
TX power : Low1
520.000
Mode : Wide
TX power : Low1
484.950
Mode : Wide
TX power : High
485.000
Mode : Wide
TX power : Low2
485.000
Mode : Wide
TX power : Low1
485.000
Mode : Narrow
TX power : Low1
450.000
Mode : Narrow
TX power : Low1
520.000
Mode : Narrow
TX power : Low1
–
Mode : Middle
TX power : Low1
–
Mode : Middle
TX power : Low1
–
Mode : Middle
TX power : Low1
485.000
Mode : Digital
TX power : Low1
450.000
Mode : Digital
TX power : Low1
520.000
Mode : Digital
TX power : Low1
485.000 Mode : Wide
CTCSS : 151.4 Hz
JIG CABLE
.
JIG CABLE
