- Page 1 USER MANUAL NORTH AMERICA CR3600 MANUAL VERSION 03 RELEASE DATE: NOVEMBER 2015 www.codecorp.com Configuration Guide YouTube.com/codecorporation...
-
Page 2: Statement Of Agency Compliance
The CR3600 has been tested for compliance to CE standards and guidelines and was found to conform to applicable CE standards, specifically the EMC requirements EN 55024, ESD EN 61000-4-2, Radiated RF Immunity EN 61000-4-3, ENV 50204, EFT EN 61000-4-4, Conducted RF Immunity EN 61000-4-6, EN 55022, Class B Radiated Emissions, and Class B Conducted Emissions. - Page 3 The software described in this manual may only be used in accordance with the terms of its license agreement. No part of this publication may be reproduced in any form or by any means without written permission from Code Corporation. This includes electronic or mechanical means such as photocopying or recording in information storage and retrieval systems.
-
Page 4: Table Of Contents
19.0 - Symbologies Defaulted On ............... 16 20.0 - Symbologies Defaulted Off ............... 16 21.0 - Configuring a CR3600 ................16 22.0 - CR3600: Pre-Installed Applications Overview ..........16 22.1 - CR3600: Event Admissions Application ............ 17 22.2 - CR3600: Tradeshow Admissions Application ..........18 22.3 - CR3600: Inventory Application .............. -
Page 5: Included Items
1.0 - Included (if Ordered) USB 2.0 Cable RS232 Cable CR3600 (Model #: CR36XX) 5VDC Power Supply CodeXML M3 Modem ® Battery Cartridge Charging Station Charging Station with Embedded CodeXML Modem ® D013597_03 CR3600 User Manual... -
Page 6: Set Up
2.0 - Set Up 3.0 - Battery Installation 4.0 - Fuel Gauge Battery and Removal Status Indicator < 10% Completely charge before initial use. < 25% 25-50% 50-75% 75-100% D013597_03 CR3600 User Manual... -
Page 7: Charging
5.0 - Charging 4 Hrs. 2.5 Hrs. 6.0 - Powering On the Reader 1 Sec. D013597_03 CR3600 User Manual... -
Page 8: Keypad/Icon Overview
Additional Bluetooth Reliability Mode (previously Two Way Mode) – packetized communication between a Symbol – data entered manually on the keypad CR3600 and an application will be symbols USB Downloader mode Locked – buttons pushed on the reader’s keypad will be ignored* Keyboard mode –... -
Page 9: Scanning
At the Ready screen, use left/ se left/right arrow buttons to Use soft button to to highlight View Storage. Use right arrow buttons to scroll scroll through stored data. select Options. the soft button to Select. through stored data. D013597_03 CR3600 User Manual... -
Page 10: Deleting Stored Data
11.0 - Transferring Stored Data Ensure a Bluetooth connection Use soft button to Use the up/down arrow button Sent All confirmation will has been established. select Options. to highlight Send All. Use the be displayed. soft button to Select. D013597_03 CR3600 User Manual... -
Page 11: Manually Entering Data
When done, press Enter key to send data. Press any key multiple times to cycle available letters. Press ‘0’ to cycle through available symbols. Use soft button to Use soft button to select Options. select Enter Data. D013597_03 CR3600 User Manual... -
Page 12: Establishing A Bluetooth Connection
13.0 - Establishing a Bluetooth Connection D013597_03 CR3600 User Manual... -
Page 13: Transmitting Batch Data Via Bluetooth Communication
* Additional Batch Mode and Communication configuration options are available in the CR3600 Configuration Guide located at www.codecorp.com/files.php 15.0 - Transmitting Batch Data via USB Communication Scan the USB Keyboard Mode - Batch... -
Page 14: Wired Communication Via Usb Downloader Mode
Note: Data, in this mode, will not be scanned data to reader memory. deleted from memory. * Additional Batch Mode and Communication configuration options are available in the CR3600 Configuration Guide located at www.codecorp.com/files.php 16.0 - Wired Communication via USB Downloader Mode Open Scan USB Downloader Mode configuration barcode: CortexTools®... -
Page 15: Reader Feedback
Note: working ranges are a combination of both the wide and high density fields. All samples were high quality barcodes and were read along a physical center line at a 10° angle. Default AGC settings were used. Accuracy= +/- 10%. D013597_03 CR3600 User Manual... -
Page 16: Symbologies Defaulted On
22.0 - CR3600: Pre-Installed Applications Overview The CR3600 ships with two pre-installed applications: Admissions (Events and Tradeshows) and Inventory. These applications will appear during initial boot-up of the reader and can be accessed at a later time by selecting Settings > Applications > Pre-Installation > Run. For app customization, the CR3600 Software Development Kit (SDK) is available for download from www.codecorp.com. -
Page 17: Cr3600: Event Admissions Application
22.1 - CR3600: Event Admissions Application The Event Admissions application will read 1D barcodes that are 19 characters in length. It is recommended the format be set-up as follows: Example: 00001kurban10152013 Event ticket number Event name Event data (mmddyyyy) 00001 KURBAN 10152013... -
Page 18: Cr3600: Tradeshow Admissions Application
22.2 - CR3600: Tradeshow Admissions Application The Tradeshow Admissions application will read barcodes in the following format: Badge Number (Must start with A (Attendee) or E (Exhibitor) followed by a 5 digit number, First Name, Last Name, Title, Company, City, State, Phone, Email. -
Page 19: Cr3600: Inventory Application
22.3 - CR3600: Inventory Application The Inventory application will read UPC barcodes. CR3600 Apps Invent. Options Admissions Scan products CR3600 Inventory Check quantity Inventory Check location Application Last edit date Upload file Options Quit Cancel Use the up/down arrow buttons... -
Page 20: Cr3600Dpm: Overview
Dot Peen barcode reading. This will also read common 1D/2D printed barcodes. To reset a CR3600DPM reader to standard CR3600 settings, scan the DPM (All) Off DPM (All) Off configuration barcode. This will disable all DPM reading. To return to DPM reading functionality, scan the preferred DPM On configuration barcode. -
Page 21: Cr3600Av Overview
Use the soft select Options. to highlight Set Type/Age. Use to highlight the Type. Use the button to select and toggle the soft button to Select. soft button to Select. between active and inactive. D013597_03 CR3600 User Manual... -
Page 22: Cr3600Av: Changing An Active Product Age Limit
Back Cancel Use the up/down arrow buttons Delete the pre-set age by to highlight Age. Use the soft hitting the Clear button. Enter button to Select. the preferred age. Use the soft button to select OK. D013597_03 CR3600 User Manual... -
Page 23: Cr3600Av: Adding Custom Age Restricted Product Types
Change Name, press and enter the new name to highlight Age. Use the soft the soft button to select OK. the soft button to select (example: Lottery). Use the button to Select. soft button to select OK. D013597_03 CR3600 User Manual... -
Page 24: Cr3600Av: Data Storage Overview
Use arrow buttons to scroll to Use the arrow buttons to highlight highlight Data Storage. Use the Active. Use the soft button to soft button to Select. Select and toggle between active and inactive. (* indicates Data Storage is active) D013597_03 CR3600 User Manual... -
Page 25: Cr3600Av: Enabling Blacklist Data Storage
Use the up/down arrow buttons Use the soft button to select Use the up/down arrow buttons Active. to highlight Passback. Use the to highlight Data Storage. Use soft button to Select. the soft button to Select. D013597_03 CR3600 User Manual... -
Page 26: Cr3600Av: Enabling Retention Data Storage
Retention. Use the Auto/Man Del. to highlight ether Auto Delete to highlight Data Storage. Use soft button to Select. or Manual Delete. Use the soft the soft button to Select. button to Select. (next page) D013597_03 CR3600 User Manual... -
Page 27: Cr3600Av: Selecting Retention Data Fields
Use the soft button to Select. Fields. Use the soft button to soft button to Select. button to Select. Select. * indicates the data field has been selected. Use the soft button to select Back to save selections. D013597_03 CR3600 User Manual... -
Page 28: Cr3600Av: Setting The Retention Data Storage Store Type
Set Date/Time. Use highlight Set Passcode. Use the the soft button to select Ok. to the next data field, enter new the soft button to Select. soft button to Select. passcode again. Use soft button to select Ok. D013597_03 CR3600 User Manual... -
Page 29: Cr3600Av: Reset To Defaults
ID is expired “ID Expired” Flashing Red Long Drone Age cannot be determined; Expiration date is not “INCOMPLETE DATA-CHECK ID” available; ID data incorrectly formatted Appears when scanning immediately after the reader “MEMORY FULL-DELETE DATA” memory is full D013597_03 CR3600 User Manual... -
Page 30: Cr3600Av: Data Storage File Formats
CR3600 is version version version 0010 Note: Code will periodically release new firmware for CR3600 readers. For information on latest firmware visit our website at www.codecorp.com/codesupport.php. D013597_03 CR3600 User Manual... -
Page 31: Dimensions
26.0 - Dimensions 5.13" (130 mm) 2.02" 1.39" (51 mm) (35 mm) 5.13" (130 mm) 2.02" (51 mm) 5.54" (141 mm) D013597_03 CR3600 User Manual... -
Page 32: Charging Station Dimensions
Cleaning the CR3600 Window CR3600 window should be clean to allow the best performance of the device. The window is the clear plastic piece inside the head of the reader. Do not touch the window. Your CR3600 uses CMOS technology that is much like a digital camera. A dirty window may stop the CR3600 from reading barcodes. -
Page 33: Warranty
Code’s maximum liability related to its performance, or failure to perform, as described herein shall be limited to the amount paid by Customer for the Code product that is subject to the claim. In no event will either party be liable for any lost profits, lost savings, incidental damage, or other economic consequential damages.
