6. Open the entrance with PIN Number

1. Opening the common entrance with Household Number
Note : The doors do not open by default password " 1234 "
Only after changing default Password to new one, can you use this function.
1) Press resident number" and "KEY
2) Press PIN number and the "KEY
The door opens with the "OPEN" message display on the LCD screen.
2. Opening the common entrance with PIN Number
1)Enter the number sequence, "9900".
2)Press the "KEY" button.
3)Enter the PIN number of a building.
4)Press the "KEY" button.
5)If the "OPEN" message appears, the common entrance will open.

7. Setting the ID for Multi-Entry Panel

First set the ID number sequence for the multi-entry unit to "0". After each multi-entry unit
has been installed, the user must program the building distributor's channels to
correspond with each multi-entry unit's ID number, 1 to 4.
(CH1 → ID:1, CH2 → ID:2, CH3 → ID:3, CH4 → ID:1)
If a multi-entry unit's ID is set to "0", then it is in household registration mode.
(If a multi-entry unit's ID is set to "0", it is not in normal operation)
1) Hold "Key
2) When "Password" message appears on the LCD, enter the password set for the
Building and press the "Key
3) When " ID : " message appear on the LCD, enter the number from 1 to 4 in order.
4) Then press the " Key
8
" button for 2 seconds and then release when the LCD stops blinking.
" button.
" button to complete ID setting.
button
button
