Attaching the Speaker to the Mounting Plate

NOTE: If a secondary attachment point is being used, see the

ATTENTION:

Position the rear mounting slot of the speaker above the catch tab of the mounting plate,

then slide the speaker down into the mounting plate until a click is heard indicating that

the speaker is secured in place (see figure below). When properly seated, the speaker

connections are automatically made. Horizontal mounting is similar with only the orientation

of the speaker being different.

Secondary Support

Cable" section on page

proceeding further.

By default, the SM 3 speaker is shipped unlocked. When mounting

the speaker to the mounting plate, be sure that the speaker is unlocked. Failure to

place the speaker in the unlocked position will result in damage to the speaker lock

mechanism should an attempt be made to mount a locked speaker (see

Using the Security Key to Lock and Unlock the

Catch Tab

"Attaching a

for installation details before

"Step 2:

Speaker" on page 10).

SM 3 User Guide • Installation
